Sharp AR-6020V

AR-6020V ELECTRICAL SECTION 12 – 14
MIRM_A/ Scanner motor Scanner (reading) section - - CN115 1 MCU
MIRM_A Scanner motor Scanner (reading) section - - CN115 2 MCU
MIRM_B/ Scanner motor Scanner (reading) section - - CN115 3 MCU
MIRM_B Scanner motor Scanner (reading) section - - CN115 4 MCU
/MM_CLK
Main motor CLK (frequency
dividing output)
Main motor CLK signal - - CN131 4 MCU
/MMD Main motor ON signal Main motor ON signal Motor ON Motor OFF CN131 5 MCU
/MM_LD Main M_LD signal
Main motor lock detection
signal
Normal rotation
state
- CN131 7 MCU
MPED Manual feed empty sensor Paper empty detection -
Paper
provided
CN123 1 MCU
/MPFC Manual feed clutch Clutch drive signal Clutch ON - CN128 2 MCU
MPWD
Manual feed paper width
detection
Manual feed paper width
detection
- - CN141 2 MCU Analog
nCNCT_NB
Option NNB installation
detection
Option NNB installation
detection signal
Installed Not installed CN107 6 MCU
nMCU_POFF
Power interruption detection
signal
Power interruption detection
signal
AC power OFF - CN107 9 MCU
nMCU_RDY MCU ready detection signal MCU ready detection sinal - - CN107 3 MCU
nPSL Power saving light Power saving light LED lighting - CN107 4MCU
nPSW Energy saving switch signal
Shifts to the energy save
mode
Detection - CN110 3 MCU
nPOF_NB
Power interruption detection
signal
Power interruption detection
signal
AC power OFF - CN107 8 MCU
nNNB_RESET NNB reset signal NNB reset signal - - CN107 7 MCU
nNNB_RDY# NNB ready detection signal NNB ready detection signal - - CN107 5 MCU
OPCASSEL Desk motor switch
Desk motor operation is
switched by the current.
-
Motor
rotation
CN142 26 MCU
OZFM_LD Ozone Fan Motor LD signal
Ozone Fan Motor lock
detection signal
- - CN120 3
PIN Paper entry detection_1CS Paper transport detection Paper provided - CN119 7 MCU
/PMCLK
Polygon motor CLK
(frequency dividing output)
Polygon motor CLK signal - - CN111 16 MCU
/PMD Polygon motor ON signal Polygon motor ON signal Motor ON Motor OFF CN111 14 MCU
/PM_LD Polygon M_LD signal
Polygon motor lock detection
signal
Normal rotation
state
- CN111 15 MCU
POD Paper exit sensor Paper transport detection -
Paper
provided
CN121 5 MCU
POSD PaperOutputSect sensor
Paper transport detection
(Paper exit reverse section)
Paper provided - CN121 8 MCU
PSFM_LD Power FAN_LD signal FAN lock detection signal
Normal rotation
state
- CN109 2 MCU
PSL Power saving LED signal
Checks that the machine is
shifted to the energy save
mode
- ON CN110 4 MCU
PTRC1 Vertical transport clutch 3CS Clutch drive signal Clutch OFF Clutch ON CN142 16 MCU
PTRC2 Vertical transport clutch 2CS Clutch drive signal Clutch OFF Clutch ON CN142 7 MCU
/RRC PS clutch Clutch drive signal Clutch ON - CN127 2 MCU
SOCD SPF open/close detection SPF open/close detection Close - CN114 28 MCU
SPED Document sensor Document detection Detection - CN114 27 MCU
SPFMA# SFP transport motor SPF transport motor drive - - CN114 3 MCU
SPFMA/# SFP transport motor SPF transport motor drive - - CN1144MCU
SPFMB# SFP transport motor SPF transport motor drive - - CN114 5 MCU
SPFMB/# SFP transport motor SPF transport motor drive - - CN1146MCU
SPPD1 SPF transport sensor 1 Detects paper pass. Detection - CN114 1 MCU
SPPD2 SPF transport sensor 2 Detects paper pass. Detection - CN114 2 MCU
SPPD3 SPF transport sensor 3 Detects paper pass. Detection - CN114 24 MCU
SPPD4 SPF transport sensor 4 Detects paper pass. Detection - CN114 22 MCU
SPRS Pressure release solenoid
Controls the pressure
release solenoid.
OFF ON CN114 13 MCU
SPUC SPF pickup clutch SPF paper pickup clutch - - CN114 25 MCU
SPWS Document width sensor Detects document width. - - CN114 17 MCU
SRRC PS clutch Controls the PS clutch. OFF ON CN114 15MCU
/SYNC HSYNC signal of BD
Detects the synchronization
of main scanning direction
Detection CN111 1 MCU
TCDA#
Transfer output adjustment
analog output
Transfer output adjustment
analog output signal
- - CN112 8 MCU Analog
TCS
Toner sensor density
detection
Toner sensor density
detection
- - CN132 3 MCU Analog
TH_RA
Temperature analog sensor
signal input
Temperature detection signal - - CN135 4 MCU Analog
Signal name Name [Type] Function/Operation
Connector level
Connec
tor No.
Pin
No.
PWB
name
N OT E
"L" "H"
