26
COPY FUNCTIONS
BYPASS FEED (special paper)
The bypass tray must be used to feed special papers such as transparency film and labels. The bypass tray can also
be used to feed standard copy paper.
1
Place the original(s). (p.22, p.23)
2
Insert the paper (print face down) all
the way into the bypass tray.
For paper that can be
used in the bypass tray,
see "PAPER" (p.15).
To load paper, see
"Loading paper in the
bypass tray" (p.18).
3
Touch the [PAPER SELECT] key or
the tray in the image of the machine in
the touch panel, and select the bypass
tray.
Set the type of paper that
you loaded in the bypass
tray. (p.20)
4
Select the number of copies and any
other desired copy settings, and then
press the [START] key ( ).
Shifting the starting position of copying
When copying on a special size of paper in the bypass tray, the starting position of printing can be shifted vertically
for fine adjustment of the image position. To adjust the starting position of printing, follow the steps below. This
function can only be used when feeding special sizes of paper from the bypass tray.
1 Touch the [PAPER SELECT] key and then touch the [EXTRA
IMAGE ADJUST] key on the bypass tray.
2 Use the key or key to adjust the printing position, and
then touch the [OK] key.
• The position can be adjusted from -10 mm to +10 mm in 0.5 mm
increments (-0.5 inch to +0.5 inch in 0.02 inch increments).
• When a setting from -10 mm to -0.5 mm (-0.5 inch to -0.02 inch) is
selected, the starting position of printing is moved to front from the
standard position. When a setting from +0.5 mm to +10 mm
(+0.02 inch to +0.5 inch) is selected, the starting position of printing is moved to rear.
EXPOSURE
AUTO A4
PAPER SELECT
100%
READY TO COPY.
EXTRA IMAGE ADJUST
TO FRONT TO REAR
OK
0
(-10 10)
mm
0.0
