26 MFP Control PWB (ARM350/M450/350M/450M/ARM11)
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
RANK
DESCRIPTION
1
PCAPH0010GCZZ AD
D Jumper (JM-2W-96) [JP2,3,4,5,6,7]
2
PCOVP1468FCZZ AD
D FAX battery cover
3
QCNCM0041QSZZ AP
C Connector (TX25-100P12) [CN2,9,12]
4
QCNCM1146FCZZ AE
N C Connector (9A12-1034) [CN14]
5
QCNCM1148FCZZ AP
N C Connector (TX25100P6ST) [CN16]
6
QCNCW0946FCZZ AH
C Connector (36pin) [CN1]
7
QCNCW1147FCZZ AL
N C Connector (TX2450RLTH1) [CN13]
8
QCNCW1149FCZZ AN
N C Connector (8AL068S305C) [CN8]
9
QFS-D132CQCZZ AG
A Fuse (1.25/250T) [F1]
10
QFSHB0028FCZZ AC
C Fuse holder (TP00351-31) [F1]
11
QPIN-0003GCZZ AC
C Pin (T3B-SQ) [JP2,3,4,5,6,7,]
12
QSOCZ0001QSZZ AL
C Socket (DMM168-FLAA2-3A133) [CN3]
13
QSOCZ0073FCZZ AL
C Connector (72pin) [CN4,5,6]
14
QSOCZ0079FCZZ AN
C Connector (100pin) [AR350M/450M][CN7]
15
QSOCZ6428ACZZ AE
C IC socket (28pin) [IC36]
16
RCRSP6676RCZZ AG
B Crystal (32.768KHz) [X6]
17
RCRUA0005FCZZ AP
B Crystal (14.745) [X7]
18
RCRUA0007FCZZ AP
B Crystal (31.554) [X4]
19
RCRUA0008FCZZ AP
B Crystal (40.57M) [X2]
20
RCRUA0009FCZZ AP
B Crystal (66.666MHZ) [X3,5]
21
RCRUA0012FCZZ AP
B Crystal (66M) [X1]
22
RFILN0048FCZZ AC
C Coil (BLM10B121SB) [L2,3]
23
RFILN0051FCZZ AC
N C Coil (MMZ1608D121B) [L25∼30,33,34]
24
RMPTR4100ACZZ AB
B Block resistor (10Ω×4) [BR6∼13,15∼25,28,29]
RMPTR4100ACZZ AB
B Block resistor (10Ω×4) [BR33∼44,46,48,53∼72]
25
RMPTR4103ACZZ AB
B Block resistor (10KΩ×4) [BR1∼5,14,26,27,30,31,32]
RMPTR4103ACZZ AB
B Block resistor (10KΩ×4) [BR74,76,78,80∼102]
26
RMPTR4330ACZZ AB
B Block resistor (33Ω×4) [BR47,49,50,51,73,75,77,79]
27
RMPTR4472ACZZ AB
B Block resistor (4.7KΩ×4) [BR52,45]
28
UBATI0014FCZZ AN
B Battery (CR2477-H01) [BT1]
29
VCCCCZ1HH101J AA
C Capacitor (50WV 100pF) [C7,8,10,17,18,20,22,30,33]
VCCCCZ1HH101J AA
C Capacitor (50WV 100pF) [C35,38,39,40,43,47,48,51]
30
VCCCCZ1HH220J AA
C Capacitor (50WV 22pF) [C61]
31
VCEAPH1HC105M AC
C Capacitor (50WV 1µF) [C181,188,205,206]
32
VCEAPS1AC227M AD
C Capacitor (10WV 220µF) [C309,310]
33
VCEAPS1CC106M AC
C Capacitor (16WV 10µF) [C1,6,21,75,94,111,125,165]
VCEAPS1CC106M AC
C Capacitor (16WV 10µF) [C166,169,178,179,223,224]
34
VCEAPS1CC226M AC
C Capacitor (16WV 22µF) [C57,64,90,114,115,136,170,176]
35
VCEAPS1CC476M AC
C Capacitor (16WV 47µF) [C95,167,168,180]
36
VCKYCZ1CF104Z AB
C Capacitor (16WV 0.10µF) [C3,9,11,12,13,14,23∼29]
VCKYCZ1CF104Z AB
C Capacitor (16WV 0.10µF) [C31,32,34,36,37,41,42,44,45]
VCKYCZ1CF104Z AB
C Capacitor (16WV 0.10µF) [C46,49,50,52,53,54,55,56]
VCKYCZ1CF104Z AB
C Capacitor (16WV 0.10µF) [C58,59,60,62,63,65,66,67]
VCKYCZ1CF104Z AB
C Capacitor (16WV 0.10µF) [C68,70,71,72,73,74,76∼82]
VCKYCZ1CF104Z AB
C Capacitor (16WV 0.10µF) [C85,86,87,88,89,91,92,93]
VCKYCZ1CF104Z AB
C Capacitor (16WV 0.10µF) [C96,97,98,99,100,102∼108]
VCKYCZ1CF104Z AB
C Capacitor (16WV 0.10µF) [C110,112,113,116∼124,126]
VCKYCZ1CF104Z AB
C Capacitor (16WV 0.10µF) [C127,128,130,131,132,133]
VCKYCZ1CF104Z AB
C Capacitor (16WV 0.10µF) [C134,135,137,139,140∼145]
VCKYCZ1CF104Z AB
C Capacitor (16WV 0.10µF) [C149,151,153∼164,172,173]
VCKYCZ1CF104Z AB
C Capacitor (16WV 0.10µF) [C177,182,183,185,186,187]
VCKYCZ1CF104Z AB
C Capacitor (16WV 0.10µF) [C189∼199,201,202,204]
VCKYCZ1CF104Z AB
C Capacitor (16WV 0.10µF) [C208∼222,235∼262]
VCKYCZ1CF104Z AB
C Capacitor (16WV 0.10µF) [C264∼279,292∼303]
37
VCKYCZ1HB102K AA
C Capacitor (50WV 1000pF) [C129]
38
VCKYCZ1HF103Z AA
C Capacitor (50WV 0.01µF) [C69,109]
39
VHDDAP202U/-1 AB
B Diode (DAP202U) [D7,10]
40
VHDRB451F//-1 AD
B Diode (RB451F) [D12,14,20,21]
41
VHDRLS73///-1 AA
B Diode (RLS73) [D8,9]
42
VHI65946P07-1 BA
B IC (65946P07) [IC32]
43
VHI74LCX08MTC AE
B IC (74LCX08MTC) [IC46,26]
44
VHI74LCX14MTC AE
B IC (74LCX14MTC) [IC43]
45
VHI74LCX244MT AG
B IC (74LCX244MT) [IC12]
46
VHI74LCX32MTC AE
B IC (74LCX32MTC) [IC11]
47
VHI74LVX16128 AP
B IC (74LVX16128) [IC15]
48
VHI90LV17AW-1 AP
B IC (90LV17AW) [IC18]
49
VHIDS14C238// AT
B IC (DS14C238) [IC42]
50
VHIEEP64-120P AW
B IC (EEP64-120P) [IC36]
51
VHIHG73C095-1 AY
B IC (HG73C095) [IC53]
52
VHIKS0U1347-1 BN
B IC (KS0U1347) [IC19]
53
VHILCX157MT-1 AG
B IC (LCX157MT) [IC14]
54
VHILCX16244-1 AM
B IC (LCX16244) [IC21,49,50]
55
VHILCX16245-1 AM
B IC (LCX16245) [IC16,24,31,51,52]
56
VHILCX16373-1 AM
B IC (LCX16373) [IC34]
57
VHILCX74MTC-1 AE
B IC (LCX74MTC) [IC10]
58
VHILM393D++-1 AE
B IC (LM393D) [IC39]
59
VHILVT240MT-1 AL
B IC (LVT240MT) [IC8]
60
VHIM87J4810-1 BK
B IC (M87J4810) [IC25]
61
VHIN2370R04-1 AF
B IC (N2370R04) [IC23]
62
VHIN2370R33-1 AF
B IC (N2370R33) [IC54]
– 3 –
