26 MFP Control PWB (ARM350/M450/350M/450M/ARM11)
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
RANK
DESCRIPTION
63
VHIN2391D25-1 AG
B IC (N2391D25) [IC35,33]
64
VHINJM317DL-1 AK
B IC (NJM317DL) [IC2]
65
VHINJU6356E-1 AK
B IC (NJU6356E) [IC40]
66
VHIPI6C2309-1 AR
B IC (PI6C2309) [IC9,29]
67
VHIPM2500++-1 BP
B IC (PM2500) [IC13]
68
VHIPST598DN-1 AF
B IC (PST598DN) [IC47]
69
VHIPST598IN-1 AF
B IC (PST598I) [IC48]
70
VHISD4M16L1-1 AZ
B IC (SD4M16L1) [IC22]
71
VHISD8M16L1-1 BB
B IC (SD8M16L1) [IC4,5,6,7,27]
72
VHISR1024-7LL AU
B IC (SR1024-7LL) [IC55,56]
73
VHIT4955A20-1 BF
B IC (T4955A20) [IC20]
74
VHITD62503F-1 AF
B IC (TD62503F) [IC38,41,44,45]
75
VHP1LHEE-002A AC
B LED (Red) (1LHEE-002A) [D13]
76
VHV1608C080-1 AC
B Varistor (1608C080) [RV1∼6]
77
VHVICPS1.2/-1 AF
B IC protecrot (ICPS1.2) [Q1]
78
VRS-CZ1JD000J AA
C Resistor (1/16W 0Ω ±5%) [R1,3,32,33,49,77,94,97,106]
VRS-CZ1JD000J AA
C Resistor (1/16W 0Ω ±5%) [R108,120,141,166,198,220,222]
VRS-CZ1JD000J AA
C Resistor (1/16W 0Ω ±5%) [R225,229,232,233,290∼307]
VRS-CZ1JD000J AA
C Resistor (1/16W 0Ω ±5%) [R310∼348,399,400,406]
VRS-CZ1JD000J AA
C Resistor (1/16W 0Ω ±5%) [R407,409,410,413,414]
79
VRS-CZ1JD100J AA
C Resistor (1/16W 10Ω ±5%) [R36,59,64,65,96,116,118,126]
VRS-CZ1JD100J AA
C Resistor (1/16W 10Ω ±5%) [R127,136,137,149,161,170,177,185]
80
VRS-CZ1JD101J AA
C Resistor (1/16W 100Ω ±5%) [R9,10,101,102,109,180]
VRS-CZ1JD101J AA
C Resistor (1/16W 100Ω ±5%) [R181,183,235,236]
81
VRS-CZ1JD102J AA
C Resistor (1/16W 1.0KΩ ±5%) [R11,129,130,134,151,204]
VRS-CZ1JD102J AA
C Resistor (1/16W 1.0KΩ ±5%) [R205,243,244,253,268,279]
82
VRS-CZ1JD103J AA
C Resistor (1/16W 10KΩ ±5%) [R12,13,15,16,18,20,44,45]
VRS-CZ1JD103J AA
C Resistor (1/16W 10KΩ ±5%) [R60,61,62,70,72,73,86,91]
VRS-CZ1JD103J AA
C Resistor (1/16W 10KΩ ±5%) [R93,112,115,123,131,139]
VRS-CZ1JD103J AA
C Resistor (1/16W 10KΩ ±5%) [R144,154,158,159,160,163]
VRS-CZ1JD103J AA
C Resistor (1/16W 10KΩ ±5%) [R165,167,168,203,207,208]
VRS-CZ1JD103J AA
C Resistor (1/16W 10KΩ ±5%) [R213,216,217,230,237,238]
VRS-CZ1JD103J AA
C Resistor (1/16W 10KΩ ±5%) [R239,240,241,242,245,246]
VRS-CZ1JD103J AA
C Resistor (1/16W 10KΩ ±5%) [R249,254,259,260,261,263]
VRS-CZ1JD103J AA
C Resistor (1/16W 10KΩ ±5%) [R264,267,269,271,272,273]
VRS-CZ1JD103J AA
C Resistor (1/16W 10KΩ ±5%) [R274,282,283,284,285]
83
VRS-CZ1JD183J AA
C Resistor (1/16W 18KΩ ±5%) [R275,280]
84
VRS-CZ1JD220J AA
C Resistor (1/16W 22Ω ±5%) [R14,17,19,24,27,30,31,34]
VRS-CZ1JD220J AA
C Resistor (1/16W 22Ω ±5%) [R35,37,39,40,43,46,51,54]
VRS-CZ1JD220J AA
C Resistor (1/16W 22Ω ±5%) [R57,247,252]
85
VRS-CZ1JD221J AA
C Resistor (1/16W 220Ω ±5%) [R403,404]
86
VRS-CZ1JD222J AA
C Resistor (1/16W 2.2KΩ ±5%) [R199,200,209,210,211,212]
VRS-CZ1JD222J AA
C Resistor (1/16W 2.2KΩ ±5%) [R218,223,248,265,266,276]
87
VRS-CZ1JD330J AA
C Resistor (1/16W 33Ω ±5%) [R25,38,41,47,48,52,56,58,66]
VRS-CZ1JD330J AA
C Resistor (1/16W 33Ω ±5%) [R67,68,69,92,117,138,142]
VRS-CZ1JD330J AA
C Resistor (1/16W 33Ω ±5%) [R143,147,148,152,153,173]
VRS-CZ1JD330J AA
C Resistor (1/16W 33Ω ±5%) [R174,175,176,187,188,]
VRS-CZ1JD330J AA
C Resistor (1/16W 33Ω ±5%) [R214,288,289]
88
VRS-CZ1JD332J AA
C Resistor (1/16W 3.3KΩ ±5%) [R215,119]
89
VRS-CZ1JD333J AA
C Resistor (1/16W 33KΩ ±5%) [R179,107]
90
VRS-CZ1JD470J AA
C Resistor (1/16W 47Ω ±5%) [R53,55,308,309]
91
VRS-CZ1JD472J AA
C Resistor (1/16W 4.7KΩ ±5%) [R63,71,74,76,87,100,111,121]
VRS-CZ1JD472J AA
C Resistor (1/16W 4.7KΩ ±5%) [R122,124,128,133,146,162,164]
VRS-CZ1JD472J AA
C Resistor (1/16W 4.7KΩ ±5%) [R184,206,221,224,226,227,228]
VRS-CZ1JD472J AA
C Resistor (1/16W 4.7KΩ ±5%) [R231,250,251,262,270,277]
92
VRS-CZ1JD511J AA
C Resistor (1/16W 510Ω ±5%) [R278]
93
VRS-CZ1JD750J AA
C Resistor (1/16W 75Ω ±5%) [R114,145]
94
VRS-CZ1JD823J AA
C Resistor (1/16W 82KΩ ±5%) [R202]
95
VSDTC114EK/-1 AB
B Transistor (DTC114EK) [Q3]
96
VSDTC114YK/-1 AC
B Transistor (DTC114YK) [Q4]
97
VSUPA502T//-1 AD
B Transistor (UPA502T) [Q5,6,7]
– 4 –
