31 Optical unit 2[AR-EF1]
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
RANK
DESCRIPTION
1
! CDAIU0619DS51 BF
N E Lamp unit
2
LHLDZ1505FCZZ AC
N C Wire holder
3
XBBSD40P06000 AA
CScrew (4×6)
4
LBSHC0161FCZZ AB
C Bushing
5
CCOVP1541FC02 AT
N D Dark box Assy
6
XHBSD30P04000 AA
CScrew (3×4)
7
PCUSU0203FCZZ AE
C Protection cushion
8
PGIDM1890FCZZ AC
N C CL guide
9
NPLYZ0399FCZZ AG
N C W pulley T
10
XBPSD40P06KS0 AA
CScrew (4×6KS)
12
LFIX-0284FCZZ AC
C 2nd,3rd mirror fixing plate F
13
PMIR-0165FCZZ AP
N B 2nd,3rd mirror
15
MSLI-0138FCZZ AC
C Slider
16
PWIR-0192FCZZ AQ
N B MB wire F
17
PWIR-0191FCZZ AQ
N B MB wire R
18
NBLTH0329FCZZ AG
N B Winding drive belt
19
LX-BZ0049FCZZ AB
CScrew
20
NPLYZ0338FCZZ AN
C Pulley (36T)
21
XRESP70-08000 AA
C E type ring
22
LX-BZ0324FCZZ AA
CScrew
23
NPLYZ0013QSZZ AL
C Winding pully PAN
24
NPLYZ0005QSZZ AG
C Pulley
25
NSFTZ2586FCZZ AS
N C Winding drive shaft
26
NPLYZ0006QSZZ AD
C L pulley
27
RMOTS0857FCZZ AZ
N B Scanner motor
28
XBPSD30P05K00 AA
CScrew (3×5K)
29
XBPSD40P16KS0 AA
CScrew (4×16KS)
30
MSPRT2846FCZZ AC
N C Belt tenshion spring
31
CPLTM5719FC01 AG
N C Mirror motor fixing plate
32
PGUMS0002QSZZ AL
C Protection rubber
33
NGERH0027QSZZ AH
C Mirror motor idle gear
34
XRESP70-08000 AA
C E type ring
35
LX-WZ0119FCZZ AA
C Washer
36
VHPGP3A38//-1 AH
B Photo transistor (GP3A38)
37
XBBSD40P14000 AA
CScrew (4×14)
38
VHPGP1A22LC-1 AK
B Photo interupter (GP1A22LC)
39
XBBSD40P10000 AA
CScrew (4×10)
40
DHAI-3150FCZZ AD
N C MHPS interface harness
41
CPLTM0031RS51 BS
N E CCD unit
42
NBRGC0133FCZ1 AC
C PF bearing (M8)
43
XRESP40-05000 AA
C E type ring
44
LHLDZ1381FCZZ AL
C ORS PWB holder
45
CPWBF1454FCE1 BN
N E ORS PD PWB
46
XHBSD40P06000 AA
CScrew (4×6)
47
XEPSD40P06000 AA
CScrew (4×6)
48
XHBSD30P06000 AA
CScrew (3×6)
49
MSPRD3020FCZ1 AG
N C Wire stopper spring
50
PGIDM1964FCZZ AC
N C Rack adjusting guide
501
CHLDZ1446FC31 BC
N E 2,3 Mirror unit
502
CSFTZ2586FC31 AZ
N E Winder drive shaft unit
