Sharp AY-AP9FHR Service Manual

AYAP7FHR
5
[5] OUTDOOR UNIT PARTS
2-1
2-7
2-2
2-8
1-1
1-7
4-6
4-5
1-2
1-14
1-17
1-23
1-10
1-11
1-13
1-12
1-28
1-27
3-15
3-14
3-10
3-11
3-12
1-18
1-19
1-14
1-3
1-16
1-15
1-20
3-13
1-29
1-24
1-25
2-5
2-3
1-9
4-6
1-4
3-6
3-8
3-9
2-4
3-1
3-2
4-3
3-5
3-3
3-4
4-2
3-7
3-1-1
3-1-2
3-1-3
2-6
1-5
4-1
4-7
4-1
4-1
1-8
4-4
1-21
1-21
1-22

Sharp AY-AP9FHR Specifications

General

AC input voltage	220-240 V
AC input frequency	50 Hz
Design load (cooling)	- kW
Energy efficiency class (cooling)	A
Annual energy consumption (cooling)	410 kWh
Hourly energy consumption (cooling)	3.8 kWh
Energy efficiency class (heating) (Warmer heating season)	-
Annual energy consumption (heating) (Warmer heating season)	- kWh
Type	Split system
Multi-split	Yes
Product color	White
Hose length (max)	10 m
Refrigerating medium	R410A
Air conditioner functions	Cooling, Heating
Cooling capacity in watts (nominal)	820 W
Cooling energy efficiency (EER, W/W)	3.21
Heating energy efficiency (COP, W/W)	3.61
Heating capacity in watts (nominal) (Warmer heating season)	- W
Heating capacity in watts (nominal) (Average heating season)	855 W
Indoor unit depth	184 mm
Indoor unit width	810 mm
Indoor unit height	270 mm
Indoor unit weight	9000 g
Indoor units quantity	1
Indoor unit noise level (high speed)	55 dB
Outdoor unit depth	250 mm
Outdoor unit width	730 mm
Outdoor unit height	540 mm
Outdoor unit weight	32000 g
Outdoor unit noise level	61 dB
