AY-M09AE
AE-M18AE
ITEMS INDOOR UNIT OUTDOOR UNIT
AY-M09AE AE-M18AE
Cooling capacity kW [1 unit] 2.7 [2 units] 2.5 x 2
Heatpump kW [1 unit] 3.3 [2 units] 3.2 x 2
Heating capacity
Moisture removal Liters/h 1.1 x 2
Electrical data
Phase - Single
Rated frequency Hz 50
Rated voltage range V 198 to 264
Rated voltage V 220 - 240
Rated current Cool A [1 unit] 4.8 - 5.1 [2 units] 9.6 - 9.8
Heat A [1 unit] 5.2 - 5.5 [2 units] 9.2 - 9.5
Rated input Cool W [1 unit] 1000 - 1080 [2 units] 2000 - 2100
Heat W [1 unit] 1080 - 1170 [2 units] 1920 - 2060
Power factor Cool % [1 unit] 95 - 88 [2 units] 95 - 89
Heat % [1 unit] 94 - 89 [2 units] 95 - 90
Compressor Type Hermetically sealed rotary type
Model 2PS192D3AA02
Oil charge 350cc (SUNISO 4GDID)
Refrigerant Evaporator Louver fin and Grooved tube type(7mm tube)
system Condenser Corrugate Fin and Grooved tube type
Control Capillary tube
Refrigerant volume 680 g x 2
De-ice system Micro computer controlled reverse system
NOise level High dB(A) 38 50
(at cooling) Med. dB(A) 31 -
Low dB(A) 28 -
Fan system
Drive Direct drive Direct drive
Air flow quantity High m
3
/min. 6.5 36
(at cooling) Med. m
3
/min. 5.2 -
Low m
3
/min. 4.5 -
Fan Cross flow fan Propeller fan
Connections
Refrigerant coupling Flare type
Refrigerant tube size Gas, Liquid 3/8", 1/4"
Refrigerant pipe sets No. AZ-24H5E; 5m, AZ-24H7E; 7m
Drain piping mm O.D ø 18
Others
Safety device Compressor: Overload protector(MRA98533)
Fan motors: Thermal fuse Thermal Protector
Fuse, Micro computer control
Air filters Polypropylene net (Washable)
Net dimensions Width mm 790 890
Height mm 270 637
Depth mm 155 297
Net weight kg 7 61
Note: The condition of (
) marked item are ‘ISO 5151 : 1994(E), Condition T1'
SPECIFICATIONS
