REPLACEMENT PARTS LIST [AY-M09AE]
REF. NO. PART NO. DESCRIPTION Q'TY CODE
CABINET AND UNIT PARTS
1- 1 CMOT-A273JBK0 Fan motor sub ass’y 1 BN
1- 2 NFANCA042JBE0 Cross flow fan 1 BC
1- 3 CSRA-A488JBKZ Drain pan ass’y 1 BM
1- 4 MJNTPA040JBFF Louver link 3 AC
1- 5 MLOV-A135JBFF Vertical louver A 9 AC
1- 6 MLOV-A136JBFF Vertical louver B 3 AC
1- 7 MLOV-A133JBFE Horizontal louver A 1 AK
1- 8 MLOV-A134JBFE Horizontal louver B 1 AK
1- 9 PPACGA002JBE0 O ring 1 AA
1-10 RMOT-A050JBE0 Louver motor 1 AY
1-11 PGUMMA071JBE0 Motor cushion 1 AN
1-12 LHLD-A197JBFP Louver holder 4 AC
1-13 PGUMMA086JBE0 Motor cushion 1 AG
1-14 PCOV-A190JBE0 Drain cover 1 AE
1-15 CHLD-A053JBK0 Bearing ass’y 1 AL
1-16 LHLD-A187JBFB Tube holder 1 AC
1-17 PSHE-A099JBE0 Evaporator sheet 1 AH
1-18 LSPR-A006JBE0 Sheet spring 2 AB
1-19 DCHS-A386JBKZ Cabinet ass’y 1 BA
1-20 DWAK-A797JBKZ Panel ass’y 1 BE
1-21 PFILMA077JBEB Air filter 2 AN
1-22 HDEC-B084JBEA Display cover 1 AF
1-23 HBDG-A059JBEA Badge 1 AH
1-24 LHLD-A209JBFA Front panel hinge R 1 AF
1-25 MARMPA012JBFA Open panel hinge L 1 AD
1-26 MARMPA013JBFA Open panel hinge R 1 AD
1-27 LHLD-A208JBFA Front panel hinge L 1 AD
1-28 PBOX-A120JBK0 Louver gear ass’y 1 AZ
1-29 NBRG-A026JBFA Louver bushing 2 AB
1-30 PSHE-A098JBE0 Evaporator seal 1 AC
1-31 TLABPA175JBR0 Louver label 1 AB
1-32 TSPC-D397JBRA Name label 1 AE
1-33 PGUMSA046JBE0 Damper rubber 1 AD
1-34 HPNL-A097JBFC Open panel 1 AW
1-35 PFPFPB074JBE0 Thermistor insulator 1 AB
1-36 PHOS-A015JBE0 Drain hose 1 AL
1-37 LHLD-A204JBF0 Motor holder 1 AE
1-38 PSEL-B417JBE0 Aluminum tape 1 AC
1-39 PSEL-B418JBE0 Aluminum tape 1 AD
1-40 PSEL-B494JBE0 Aluminum sheet 1 AD
1-41 PSEL-B492JBE0 Box-sheet 1 AC
1-42 TLAB-B722JBEZ Label 1 AE
CONTROL BOX PARTS
2- 1 FSGY-A072JBK0 Display unit 1 AX
2- 2 FPWBFA024JBK0 Switch board unit 1 AM
2- 3 QTAN-A327JBZZ Terminal board 1 AS
2- 4 RFIL-A096JBE0 Coil 1 AS
2- 5 DPWBFA187JBKZ Control board unit 1 BM
2- 6 QFS-GA027JBEZ Fuse 1 AD
2- 7 RH-VZA037JBE0 Varistor 1 AE
2- 8 RTRN-A182JBE0 Transformer 1 AY
2- 9 RC-HZA195JBE0 Fan motor capacitor 1 AL
2-10 RTHM-A296JBE0 Thermistor 1 AN
2-11 LHLD-A190JBF0 Thermistor holder 1 AG
2-12 DBOX-A026JBK0 Control box ass'y 1 AT
2-13 HPNLCA497JBF0 Control box cover 1 AF
2-14 HPNLCA616JBE0 Control panel 1 AE
2-15 VHRPC111LY2-6 Photo coupler(PC1, PC2) 2 AK
2-16 LHLD-A266JBFB Cord clamp 1 AF
2-17 TLABCB302JBR0 Wiring diagram 1 AD
2-18 PSHE-A076JBE0 Protection cover 1 AC
2-19 PGUMMA095JBE0 Wire cushion 1 AA
2-20 PCOV-A191JBE0 LED holder 1 AC
2-21 RH-IXA592JBZZ Micro computer 1 AC
2-22 RH-IZA149JBE0 Integrated circuit 1 AE
2-23 RIC—-A022BDE0 Integrated circuit 1 AE
2-24 VHIIR2411//-6 Integrated circuit 1 AE
2-25 VHIPST591D/-3 Integrated circuit 1 AE
2-26 VHIBR24C01A-6 Integrated circuit 1 AF
2-27 RH-SZA007JBE0 Triac 1 AK
2-28 QFS-TA037JBE0 Thermal fuse(TC) 1 AF
2-29 RC-QZA096JBE0 Film capacitor 1 AE
