37
AY-M09AE
AE-M18AE
REPLACEMENT PARTS LIST [AE-M18AE]
REF. NO. PART NO. DESCRIPTION Q'TY CODE
CABINET AND UNIT PARTS
1- 1 LSUB-A010JBP0 Motor stay sub angle 2 AG
1- 2 CMOTLA868JBEZ Fan motor 1 BP
1- 3 NFANPA037JBFA Propeller fan 1 AZ
1- 4 LANGKA045JBP0 Motor stay angle 1 AU
1- 5 PSKR-A101JBW0 Bulkhead 1 AQ
1- 6 GPLTMA051JBTA Side cover R 1 AW
1- 7 CFTA-A250JBK0 Cont.box cover ass’y 1 AW
1- 8 GPLTMA047JBTA Side cover L 1 AR
1- 9 GCAB-A124JBTA Cabinet 1 BD
1-10 GGADFA028JBTA Fan guard 1 AZ
1-11 PSEL-A792JBE0 Bulkhead insulator 1 AD
1-12 PSPF-A739JBEZ Compressor cover 1 AY
1-13 PSEL-0617JBE0 Cabinet seal 3 AA
1-14 TSPC-D413JBRZ Name label 1 AF
1-15 TLABBA100JBRA Sharp badge 1 AE
1-16 CCHS-A645JBT0 Base pan ass’y 1 BR
1-17 PSEL-0625JBE0 Angle seal 3 AA
1-18 PSEL-B721JBE0 Insulator 1 AM
1-19 LBSHCA022JBF0 Bushing 1 AE
1-21 PSEL-A959JBE0 Flare C. insulator 1 AC
1-22 PSEL-A942JBE0 Flare coup. insulator 2 AC
1-23 PSEL-B941JBE0 Cabinet seal 2 1 AD
1-24 PCOV-A588JBEZ Box cover 1 AK
1-25 LSUB-A012JBP0 Motor stay sub angle 2 AG
1-26 PSEL-C004JBEZ Insulator 1 AF
1-27 PSEL-C005JBEZ Insulator 1 AD
CONTROL BOX PARTS
2- 1 CW-VZA297JBKZ Comp cord A1 ass'y 1 BD
2- 2 CW-VZA298JBKZ Comp cord A2 ass'y 1 BD
2- 3 RC-HZA316JBE0 Running capacitor 2 AY
2- 4 RC-HZA248JBE0 Fan motor capacitor 1 AP
2- 5 QFS-TA037JBE0 Thermal fuse(TC) 1 AF
2- 6 QTAN-A326JBZZ Terminal board 1 AT
2- 7 LHLD-0261JBM0 Cord holder 3 AB
2- 8 PBOX-A195JBW0 Control box 1 AN
2- 9 LBNDKA017JBW0 Capacitor clamp 1 AC
2-10 TLABCB303JBR0 Wiring diagram 1 AD
2-11 DPWBFA174JBK0 Control board unit 1 BR
2-12 VHRPC111LY2-6 Photo coupler 4 AK
2-13 RTRN-A181JBE0 Transformer(CT1) 1 AN
2-14 RH-VZA020JBE0 Varistor(CNR1 - CNR4) 4 AE
2-15 QFS-GA027JBE0 Fuse 1 AD
2-16 RH-IXA267JBE0 Microcomputer(IC1) 1 AV
2-17 VHIIR2411//-6 Integrated circuit(IC2) 1 AE
2-18 RH-IZA149JBE0 Integrated circuit(IC3) 1 AE
2-19 RIC—-A022BDE0 Integrated circuit(IC4) 1 AE
2-20 RRLYJA032JBE0 Relay(RY1, RY2) 2 AU
2-21 RRLYJA060JBE0 Relay(RY3,RY4) 2 AK
2-22 RC-HZA248JBE0 Capacitor(C1) 1 AP
2-23 RH-VZA044JBE0 Surge absorber(SA1) 1 AG
2-24 RTRN-A182JBE0 Transformer(TR) 1 AY
2-25 RH-VZA037JBE0 Varistor(NR1,NR2) 2 AE
2-26 RTHM-A350JBZZ Thermistor 1 AT
2-27 PPLT-A191JBEZ Insulating plate 1 AM
CYCLE PARTS
3- 1 PCMPRA183JBE0 Compressor 1 CK
3- 2 PCON-A432JBP0 Condenser 1 CF
3- 3 DVLV-A369JBK0 2way valve unit 2 BC
3- 4 LX-NZ0133JBE0 Flare nut 2 AE
3- 5 LX-NZA081JBE0 Bonnet 4 AG
3- 6 PCAP-A006JBF0 Nut bonnet 2 AC
3- 7 DVLV-A272JBK0 3 way valve unit 2 BF
3- 8 LX-NZ0134JBE0 Flare nut 2 AF
3- 9 LX-NZA034JBE0 Service nut 2 AD
3-10 PCAP-A007JBE0 Nut bonnet 2 AB
3-11 PCPY-A726JB10 Capillary tube C 2 AM
3-12 PCPY-A725JB10 Capillary tube H 2 AM
3-13 PSRN-A040JBE0 Strainer 2 AN
3-14 GLEG-A073JBE0 Compressor cushion 6 AD
3-15 MSPR-A005JBE0 OCR spring 2 AB
3-16 LX-NZA026JBE0 Special nut 6 AC
3-17 LBND-A046JBE0 Wire fixing bnad 1 AE
