Sharp AY-M09AE - Page 4

4
AY-M09AE
AE-M18AE
PART NAMES
INDOOR UNIT
1 Inlet (Air)
2 Open Panel
3 Operation panel
4 Air Filters
5 Indicator Panel
6 Vertical Adjustment
Louvres
7 Horizontal Adjustment
Louvres
8 Outlet (Air)
9 Remote Control
To open the open panel, hold the bot-
tom corners of the open panel and
gently pull the panel outwards.
0 TEST RUN Button
q AUX. Button
w RECEIVER Window
e OPERATION Lamp (Red
)
r TIMER Lamp (Yellow )
t BUSY Lamp (red )
Blinks when the unit can not
operate due to the other unit
operating in different mode.
OUTDOOR UNIT
y Inlet (Air)
u Refrigerant Tube and
Interconnecting Cord
i Drainage Hose
o Outlet (Air)











TEST
RUN AUX.










TEST
RUN AUX.
0
q
w
e
r
t
y
u
i
o
1
2
3
4
5
6
7
8
9
