Sharp AY-XPM9FR - Part Names

ENGLISH
GB-3
1 AUX Button
2 Inlet (Air)
3 Open Panel
4 Deodorant Dust Collection
Filter
5 Air Filters
6 Indicator
7 Receiver Window
8 Vertical Adjustment Louvres
9 Horizontal Adjustment
Louvres
10 Outlet (Air)
11 Remote Control
12 PLASMACLUSTER Lamp
(blue)
13 TEMPERATURE INDICATOR
14 OUTDOOR Temp. Lamp
(green
)
15 ROOM Temp. Lamp
(green )
16 FULL POWER Lamp
(green )
17 TIMER Lamp (orange )
18 OPERATION Lamp (red )
INDOOR UNIT
NOTE:
Actual units might vary slightly from those shown above.
12
13
14
15
16
17
18
PART NAMES
1
2
3
4
5
6
7
8
9
10
11
