LC-52/60/70LE640U/C6400U,LC-80LE633U/844U (1st Edition)
5 – 42
Point 3 [Adjustment standard value]
LEV30087 Measuring instrument: [Minolta CA-210] Technical measuring instrument
MG3G**** Level Reference value Adjustment spec Inspection spec
MG3B****
Point 6 928
X=0.272
±0.0010 ±0.0020
MG3R**** y=0.277
MG3Y****
Point 5 792
X=0.272
±0.0010 ±0.0020
y=0.277
Point 2
Point 4 608
X=0.272
±0.0015 ±0.0030
LEV20066 y=0.277
MG2G****
Point 3 348
X=0.272
±0.0020 ±0.0040
MG2B**** y=0.277
MG2R****
Point 2 264
X=0.272
±0.0030 ±0.0060
MG2Y**** y=0.277
Point 1 180
X=0.272
±0.004 ±0.0080
Point 1 y=0.277
LEV10045
MG1G****
MG1B****
MG1R****
MG1Y****
Writing
MSET0003
Remarks Setting conditions for inspection
AV MODE: [DYNAMIC] (Reset)
Monochro: ON
Active Backlight: OFF
Aging Time: Min. 60 minutes
Brightness specification after adjustment
• LC-80LE844U: Min 320cd/m2
Adjustment
point
Adjustment conditions Adjustment procedure
