LC-52/60/70LE640U/C6400U,LC-80LE633U/844U (1st Edition)
4 – 28
[5] The location putting on the heat measure sheet (LC-52/60/70LE640U/C6400U)
1. MAIN PWB Unit
• LC-52/60LE640U/C6400U
• LC-70LE640U/6400U
2. LCD Control Unit (LC-60LE640U/C6400U)
Put 䇼PSPAZC805WJKZ䇽 along these
ruled lines.
PSPAZC741WJKZ
835
PSPA Z C85 4 WJKZ
TCON CP U COOLER
