Sharp Carousel R1874TY User Manual

8
P A r T N A m E S
BOTTOM VIEW
(Rear of Microwave)
1. Oven door with see-through window.
2. Door hinges.
3. Waveguide cover
DO NOT REMOVE.
4. Turntable motor shaft.
5. Oven light.
It will light when oven is operating or door is open.
6. Safety door latches.
The oven will not operate unless the door is securely
closed.
7. One touch DOOR OPEN button.
Push to open door.
8. FAN HI / LO button.
Push for high/low/off.
9. LIGHT button.
Push for on/off.
13
14
17
18
3
2
1
4
6
5
6
7
8 9
10
11
15
16
12
FRONT VIEW
10. Auto-Touch control panel.
11. Time display: Digital display,
99 minutes 99 seconds.
12. Ventilation openings.
13. Light cover.
14. Grease filters.
15. Removable ceramic turntable.
The turntable will rotate clockwise or
counterclockwise. Only remove for cleaning.
16. Removable turntable support.
Place the turntable support on the floor of the oven
cavity and the turntable on the turntable support.
17. Removable low rack for broiling and meat and
poultry roasting.
18. Removable high rack for two level baking.
19. Rating Label
(Front of Microwave)
19

Sharp Carousel R1874TY Specifications

General

Style	over-the-range
Color	stainless steel
Total Capacity	1.1 cubic feet
Sensor Cooking	yes
Child Lock	yes
Timer	yes
Microwave Power	850 watts
Current	13.2 amperes

Weight and Dimensions

Depth	15.28 inches
Height	16.34 inches
Width	29.94 inches
Net Weight	71 pounds
