General Information
- Controls and Indicators -
Controls and Indicators (continued)
„
Display
1.Extra Bass Indicator
2.FM Stereo Mode Indicator
3.FM Stereo Receiving Indicator
4.Karaoke Mode Indicator
5.CD Repeat Play Indicator
6.CD Pause Indicator
7.CD Play Indicator
8.Tape 2 Record Indicator
9.Tape Reverse Mode Indicator
10.Disc Number Indicators
11.Timer Play Indicator
12.Memory Indicator
13.Tape 2 Reverse Play Indicator
14.Tape 1 Play or Tape 2 Forward Play Indicator
15.Sleep Indicator
16.Timer Recording Indicator
17.Spectrum Analyser/Volume Level Indicator
„
Rear panel
Reference page
1.Surround Speaker Terminals. . . . . . . . . . . . . . . . . . . . . . . . . . . . 9 - 11
2.FM 75 Ohms Aerial Terminal . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9, 10
3.FM Aerial Earth Terminal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9, 10
4.AM Loop Aerial Socket . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9, 10
5.Span Selector Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
6.Video/Auxiliary (Audio Signal) Input Sockets . . . . . . . . . . . . . . . . .31
7.Front Speaker Terminals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9 - 11
8.AC Power Lead . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
9.AC Voltage Selector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
1
2
34 5 6
8
9
17
17 17
13 14 15 16
7
10
11
12
2
1
5
6
7
8
4
3
9
