CD-E500
CD-E55/E44
– 4 –
■ Remote control
1. Remote Control Transmitter
2. Power On/Stand-by Button
3. CD Button
4. Tape (1 2) Button
5. Memory Button
6. Program Clear Button
7. Tuning and Time Down Button
8. CD Track Down or Fast Reverse, Tape 2 Rewind,
Tuner Preset Down Button
9. CD or Tape Stop Button
10. Equalizer Mode Select Button
11. Disc Number Select Buttons
12. Tuner (Band) Button
13. Video/Auxiliary Button
14.CD Random Button
15. CD Track Up or Fast Forward, Tape 2 Fast Forward,
Tuner Preset Up Button
16. Tuning and Time Up Button
17. CD Play or Repeat, Tape Play Button
18. Tape 2 Record Pause Button
19. CD Pause Button
20. Extra Bass Button
21. Volume Up and Down Buttons
Buttons with " " mark in the illustration or highlighted in bold on the
right can be operated on the remote control only.
1
2
3
4
5
6
7
8
9
10
14
12
13
11
17
18
21
20
19
15
16
■ Display
1.Disc Number Indicators
2. CD Play Indicator
3.Tape Play Indicator
4.FM Stereo Mode Indicator
5.FM Stereo Receiving Indicator
6.Memory Indicator
7. Extra Bass Indicator
8. Timer Recording Indicator
9. Timer Play Indicator
10. CD Pause Indicator
11. CD Repeat Play Indicator
12.Tape Record Indicator
13. Sleep Indicator
■ Rear panel
1.Video/Auxiliary (Audio Signal) Input Jacks
2.Cooling Fan
3.AC Power Input Jack
4.FM/AM Loop Antenna Jack
5. Speaker Terminals
Note:
This product is equipped with a cooling fan inside, which begins to
run at a specified volume level for better heat radiation.
■ Speaker system
1. Tweeter
2. Bass Reflex Ducts
3. Woofer
4. Speaker Wire
2
1
4
5
213 4567
8
9
131210 11
4
2
3
2
3
1
