Sharp CD-E500 User Manual

NO.
PRICE
RANK
DESCRIPTIONPARTS CODE
NO. PART CODE
PRICE
RANK
DESCRIPTION
CD-E500
CD-E55/E44
R745 VRD-ST2CD102J J AA 1 kohm,1/6W
R746 VRD-ST2CD333J J AA 33 kohms,1/6W
R747 VRD-ST2CD102J J AA 1 kohm,1/6W
R749,750 VRD-ST2CD103J J AA 10 kohm,1/6W
R751 VRD-ST2CD102J J AA 1 kohm,1/6W
R752A VRD-ST2CD823J J AA 82 kohms,1/6W
R752B VRD-ST2CD823J J AA 82 kohms,1/6W
R752C VRD-ST2CD823J J AA 82 kohms,1/6W
R752D VRD-ST2CD823J J AA 82 kohms,1/6W
R752E VRD-ST2CD823J J AA 82 kohms,1/6W
R752F VRD-ST2CD823J J AA 82 kohms,1/6W
R752G VRD-ST2CD823J J AA 82 kohms,1/6W
R752H VRD-ST2CD823J J AA 82 kohms,1/6W
R752I VRD-ST2CD823J J AA 82 kohms,1/6W
R752J VRD-ST2CD823J J AA 82 kohms,1/6W
R752K VRD-ST2CD823J J AA 82 kohms,1/6W
R752L VRD-ST2CD823J J AA 82 kohms,1/6W
R752M VRD-ST2CD823J J AA 82 kohms,1/6W
R752N VRD-ST2CD823J J AA 82 kohms,1/6W
R752O VRD-ST2CD823J J AA 82 kohms,1/6W
R752P VRD-ST2CD823J J AA 82 kohms,1/6W
R752Q VRD-ST2CD823J J AA 82 kohms,1/6W
R752R VRD-ST2CD823J J AA 82 kohms,1/6W
R752S VRD-ST2CD823J J AA 82 kohms,1/6W
R752T VRD-ST2CD823J J AA 82 kohms,1/6W
R753A VRD-ST2CD823J J AA 82 kohms,1/6W
R753B VRD-ST2CD823J J AA 82 kohms,1/6W
R753C VRD-ST2CD823J J AA 82 kohms,1/6W
R753D VRD-ST2CD823J J AA 82 kohms,1/6W
R753E VRD-ST2CD823J J AA 82 kohms,1/6W
R753F VRD-ST2CD823J J AA 82 kohms,1/6W
R753G VRD-ST2CD823J J AA 82 kohms,1/6W
R753H VRD-ST2CD823J J AA 82 kohms,1/6W
R753I VRD-ST2CD823J J AA 82 kohms,1/6W
R754~759 VRD-ST2CD103J J AA 10 kohm,1/6W
R760 VRD-ST2EE470J J AA 47 ohms,1/4W
R761 VRD-ST2CD102J J AA 1 kohm,1/6W
R762 VRS-CY1JB102J J AA 1 kohm,1/16W
R763 VRD-ST2CD332J J AA 3.3 kohms,1/6W
R764 VRD-ST2CD104J J AA 100 kohm,1/6W
R765 VRD-ST2CD753J J AA 75 kohms,1/6W
R766 VRS-CY1JB153J J AA 15 kohms,1/16W
R767 VRS-CY1JB822J J AA 8.2 kohms,1/16W
R768 VRD-ST2CD562J J AA 5.6 kohms,1/6W
R769 VRD-ST2CD392J J AA 3.9 kohms,1/6W
R770 VRD-ST2CD272J J AA 2.7 kohms,1/6W
R771 VRD-ST2CD202J J AA 2 kohms,1/6W
R772 VRD-ST2CD152J J AA 1.5 kohms,1/6W
R773,774 VRD-ST2CD122J J AA 1.2 kohms,1/6W
R775 VRD-ST2CD820J J AA 82 ohms,1/6W
R776 VRD-ST2CD102J J AA 1 kohm,1/6W
R777,778 VRD-ST2CD103J J AA 10 kohm,1/6W
R779 VRD-ST2CD121J J AA 120 ohms,1/6W
R780 VRD-ST2CD753J J AA 75 kohms,1/6W
R781 VRD-ST2CD153J J AA 15 kohms,1/6W
R782 VRD-ST2CD822J J AA 8.2 kohms,1/6W
R783 VRD-ST2CD562J J AA 5.6 kohms,1/6W
R784 VRD-ST2CD392J J AA 3.9 kohms,1/6W
R785 VRD-ST2CD272J J AA 2.7 kohms,1/6W
R786 VRD-ST2CD202J J AA 2 kohms,1/6W
R787 VRD-ST2CD392J J AA 3.9 kohms,1/6W
R790 VRD-ST2CD102J J AA 1 kohm,1/6W
R791 VRD-ST2CD103J J AA 10 kohm,1/6W
R793,794 VRD-ST2CD102J J AA 1 kohm,1/6W
R795~797 VRD-ST2CD103J J AA 10 kohm,1/6W
R802,803 VRD-ST2CD271J J AA 270 ohms,1/6W
R804,805 VRD-ST2CD473J J AA 47 kohms,1/6W
R806 VRD-ST2CD472J J AA 4.7 kohms,1/6W
R807 VRD-ST2CD473J J AA 47 kohms,1/6W
R809 VRD-ST2CD473J J AA 47 kohms,1/6W
R810 VRD-ST2CD472J J AA 4.7 kohms,1/6W
R811 VRD-ST2CD103J J AA 10 kohm,1/6W
R812 VRD-ST2CD222J J AA 2.2 kohms,1/6W
R813 VRD-ST2CD332J J AA 3.3 kohms,1/6W
R815 VRD-ST2CD103J J AA 10 kohm,1/6W
R816 VRD-ST2CD472J J AA 4.7 kohms,1/6W
R817 VRD-ST2CD151J J AA 150 ohms,1/6W
R818 VRD-ST2CD332J J AA 3.3 kohms,1/6W
R819 VRD-ST2CD222J J AA 2.2 kohms,1/6W
R820,821 VRD-ST2CD563J J AA 56 kohms,1/6W
R822,823 VRD-ST2CD152J J AA 1.5 kohms,1/6W
R824~828 VRD-ST2CD103J J AA 10 kohm,1/6W
R829~832 VRD-ST2CD102J J AA 1 kohm,1/6W
R833,834 VRD-ST2CD103J J AA 10 kohm,1/6W
R835 VRD-ST2CD152J J AA 1.5 kohms,1/6W
R836,837 VRS-CY1JB470J J AA 47 ohms,1/16W
R838,839 VRD-ST2CD104J J AA 100 kohm,1/6W
R840,841 VRD-ST2CD392J J AA 3.9 kohms,1/6W
R842,843 VRD-ST2CD333J J AA 33 kohms,1/6W
R844,845 VRD-ST2CD562J J AA 5.6 kohms,1/6W
R846 VRD-ST2CD103J J AA 10 kohm,1/6W
R847 VRD-ST2CD392J J AA 3.9 kohms,1/6W
R848,849 VRD-ST2CD682J J AA 6.8 kohms,1/6W
R850 VRD-ST2CD392J J AA 3.9 kohms,1/6W
R851 VRD-ST2CD473J J AA 47 kohms,1/6W
R852,853 VRD-ST2CD152J J AA 1.5 kohms,1/6W
R854,855 VRD-ST2CD101J J AA 100 ohm,1/6W
R856 VRD-ST2CD473J J AA 47 kohms,1/6W
R857,858 VRD-ST2CD103J J AA 10 kohm,1/6W
R859 VRD-ST2EE221J J AA 220 ohms,1/4W
R860 VRD-ST2CD472J J AA 4.7 kohms,1/6W
R861,862 VRD-ST2CD473J J AA 47 kohms,1/6W
R863 VRD-ST2CD104J J AA 100 kohm,1/6W
R864 VRD-ST2CD183J J AA 18 kohms,1/6W
R865 VRS-CY1JB333J J AA 33 kohms,1/16W
R866 VRD-ST2EE101J J AA 100 ohm,1/4W
R902 VRD-ST2CD223J J AA 22 kohms,1/6W
R903 VRD-ST2EE100J J AA 10 ohm,1/4W
R904 VRD-ST2CD473J J AA 47 kohms,1/6W
R905 VRD-ST2CD123J J AA 12 kohms,1/6W
R906,907 VRD-ST2CD331J J AA 330 ohms,1/6W
OTHER CIRCUITRY PARTS
CN1 QCNWN0584SJZZ J Flat Wire,2Pin
CNP101 QCNCM050ESJZZ J AD Plug,5Pin
CNP102 QCNCM999GAFZZ J AD Plug,7Pin
CNP201 QCNCM998GAFZZ J AH Plug,7Pin
CNP202 QCNCM059GSJZZ J AB Plug,7Pin
CNP203 QCNCM046CSJZZ J AD Plug,3Pin
CNP204 QCNCM999FAFZZ J AE Plug,6Pin
CNP205 QCNCM999CAFZZ J AG Plug,3Pin
CNP301 QCNCM042CSJZZ J AB Plug,3Pin
CNP401 QCNCW014RSJZZ J Socket,16Pin
CNP405 QCNCM004LAFZZ J Plug,11Pin
CNP406 QCNCM004CAFZZ J AB Plug,3Pin
CNP601 QCNCM073CSJZZ J AB Plug,3Pin
CNP801 QCNCM074CSJZZ J AB Plug,3Pin
CNP802 QCNCM999GAFZZ J AD Plug,7Pin
CNP803 QCNCM999KAFZZ J AD Plug,10Pin
CNP901 QCNCM999EAFZZ J AG Plug,5Pin
CNS203 QCNWN0529SJZZ J Connector Ass’y,3Pin
CNW101/CNS101 QCNWN0541SJZZ J Connector Ass’y,5/5Pin
CNW102/CNS102 QCNWN0523SJZZ J Connector Ass’y,8/7Pin
CNW201/CNS201 QCNWN0528SJZZ J Connector Ass’y,8/7Pin
CNW202/CNS202 QCNWN0524SJZZ J Connector Ass’y,8/7Pin
CNW204/CNS204 QCNWN0532SJZZ J Connector Ass’y,7/6Pin
CNW205/CNS205 QCNWN0583SJZZ J Connector Ass’y,3/3Pin
CNW402/CNS402 QCNWN0533SJZZ J Connector Ass’y,7/6Pin
CNW403/CNS403 QCNWN0534SJZZ J Connector Ass’y,6/5Pin
CNW404 QCNWN0536SJZZ J Connector Ass’y,2Pin
CNW405/CNS405 QCNWN0574SJZZ J Connector Ass’y,12/11Pin
CNW601/CNS601 QCNWN0530SJZZ J Connector Ass’y,3/3Pin
CNW801 QCNWN0543SJZZ J Connector Ass’y,3Pin
CNW802 QCNWN0542SJZZ J Connector Ass’y,7Pin
CNW803/CNS803 QCNWN0527SJZZ J Connector Ass’y,11/10Pin
CNW804/CNS804 QCNWN0544SJZZ J Connector Ass’y,7/7Pin
CNW805/CNS805 QCNWN0545SJZZ J Connector Ass’y,7/7Pin
CNW901/CNS901 QCNWN0522SJZZ J Connector Ass’y,6/5Pin
MR401 RCORF0018AWZZ J AG Core
1 F901 QFS-D502BSJNI J AE Fuse,5A/125V
1 F902 QFS-D502BSJNI J AE Fuse,5A/125V
1 F903 QFS-D162BSJNI J AE Fuse,1.6A/125V
FC401 QCNWN0531SJZZ J Flat Cable,16Pin
JK101 QJAKM0001SJZZ J AG Jack,Headphone
M101(204-4) RMOTV0409AFZZ J AL Motor,Air Cooling Fan
M401(238-2) 9GD8301-PDJ01 J Motor with Pulley
[Up/Down/Loading]
M402(238-3) 9GD8301-PDJ02 J Motor with Worm Pulley [Rotate]
M801(219-10) 9GD60020322 J Motor with Pulley [Tape]
NM801 ———— –– Motor with Gear [Sled]
(Supplied at REF No.238-1)
NM802 ———— –– Motor with Chassis [Spindle]
(Supplied at REF No.238-1)
– 4 –
