PRICE
RANK
DESCRIPTION
NO.
PART CODE
NO. PARTS CODE
PRICE
RANK
DESCRIPTION
CD-E500
CD-E55/E44
RLY101 RRLYD0014AWZZ J AK Relay
RX701 VHLGP1UM271-1 J AH Remote Sensor,GP1UM271
SO101 QTANA9024SJZZ J AD Terminal,Speaker
SO601 QSOCJ0003SJZZ J AG Jack,Video/Aux In
1 SO901 QSOCA0214AWZZ J AD Socket,AC Input
SOL801(219-5) 9GD19212118 J AP Solenoid Ass’y
SOL802(219-5) 9GD19212118 J AP Solenoid Ass’y
SW1 ———— –– Switch,Leaf Type [Pickup in]
(Supplied at REF No.238-1)
SW401 QSW-B0002SJZZ J AE Switch,Leaf Type
[Disc Up/Down]
SW402(238-4) 9GD8301-DKG02 J Switch,Leaf Type [Open/Close]
SW403(238-5) 9GDM03-DKG01 J Switch,Leaf Type [Disc No.]
SW404(238-6) 9GDM03-DKG01 J Switch,Leaf Type [Disc 1]
SW701 QSW-K0002SJZZ J AC Switch,Key Type
[X-BASS/DEMO]
SW702 QSW-K0002SJZZ J AC Switch,Key Type
[POWER ON/STAND-BY]
SW703 QSW-K0002SJZZ J AC Switch,Key Type
[OPEN/CLOSE]
SW704 QSW-K0002SJZZ J AC Switch,Key Type [DISK SKIP]
SW705 QSW-K0002SJZZ J AC Switch,Key Type [VIDEO/AUX]
SW706 QSW-K0002SJZZ J AC Switch,Key Type [TAPE]
SW707 QSW-K0002SJZZ J AC Switch,Key Type
[PRESET DOWN]
SW708 QSW-K0002SJZZ J AC Switch,Key Type
[PLAY/REPEAT]
SW709 QSW-K0002SJZZ J AC Switch,Key Type [PRESET UP]
SW710 QSW-K0002SJZZ J AC Switch,Key Type [STOP]
SW711 QSW-K0002SJZZ J AC Switch,Key Type
[MEMORY/SET]
SW712 QSW-K0002SJZZ J AC Switch,Key Type
[TUNING/TIME DOWN]
SW713 QSW-K0002SJZZ J AC Switch,Key Type
[TUNING/TIME UP]
SW714 QSW-K0002SJZZ J AC Switch,Key Type
[TIMER/SLEEP]
SW715 QSW-K0002SJZZ J AC Switch,Key Type [CLOCK]
SW719 QSW-K0002SJZZ J AC Switch,Key Type [EQUALIZER]
SW720 QSW-K0002SJZZ J AC Switch,Key Type [VOLUME UP]
SW721 QSW-K0002SJZZ J AC Switch,Key Type
[VOLUME DOWN]
SW722 QSW-K0002SJZZ J AC Switch,Key Type
[TUNER (BAND)]
SW723 QSW-K0002SJZZ J AC Switch,Key Type [CD]
SW724 QSW-K0002SJZZ J AC Switch,Key Type [REC/PAUSE]
SW801(219-8) 9GD19211305 J Switch,Leaf Type [
Tape 2 Initialize
]
SW802(219-8) 9GD19211305 J Switch,Leaf Type [
Tape 1 Initialize
]
SW803(219-9) 9GD19211305 J Switch,Leaf Type [Tape 2 Rec]
VFD701 VVK200906F/-1 J AT FL Display
CABINET PARTS
201 CPNLC1068SJ01 J AV Front Panel Ass’y [CD-E44]
201 CPNLC1068SJ03 J AV Front Panel Ass’y [CD-E55]
201 CPNLC1068SJ05 J AV Front Panel Ass’y [CD-E500]
201- 1 ———— –– Front Panel
(Not Replacement Item)
201- 2 CGERH0001SJ02 J Gear,Damper Ass’y
201- 3 GDORF0030SJSA J AF Holder,Cassette,Left
201- 4 GDORF0031SJSA J AF Holder,Cassette,Right
201- 5 HDECQ0116SJSA J Panel,Amp [CD-E44]
201- 5 HDECQ0122SJSA J AF Panel,Amp [CD-E500]
201- 5 HDECQ0123SJSA J AF Panel,Amp [CD-E55]
201- 6 MSPRD0028SJFW J AB Spring,Cassette Holder,Left
201- 7 MSPRD0029SJFJ J AD Spring,Cassette Holder,Right
201- 8 PCUSG0017SJSA J Cushion,Leg
202 GITAS0010SJ01 J Side Panel Ass’y,Left
[CD-E44/55]
202 GITAS0010SJ02 J Side Panel Ass’y,Left [CD-E500]
202- 1 ———— –– Side Panel,Left
(Not Replacement Item)
202- 2 PCUSG0017SJSA J Cushion,Leg
203 GITAS0011SJ01 J Side Panel Ass’y,Right
[CD-E44/55]
203 GITAS0011SJ02 J Side Panel Ass’y,Right
[CD-E500]
203- 1 ———— –– Side Panel,Right
(Not Replacement Item)
203- 2 PCUSG0017SJSA J Cushion,Leg
204 CFANP0001SJ03 J Fan Motor Ass’y
204- 1 LANGK0055SJFW J Bracket,Fan Motor
204- 2 MSPRK0001SJFJ J AC Spring,Ring
204- 3 NFANP0001SJSA J AG Rotary,Fan
204- 4(M101) RMOTV0409AFZZ J AL Motor,Air Cooling Fan
205 GCAB-1002SJSA J AP Top Cabinet [CD-E44/55]
205 GCAB-1002SJSB J AP Top Cabinet [CD-E500]
206 GCOVA1030SJSA J AG Cover,CD Tray
207 GCOVA1031SJSA J AF Cover,Cassette,Left
208 GCOVA1032SJSA J AF Cover,Cassette,Right
209 GCOVA1033SJSA J AD Cover,Remote Sensor
210 GCOVA1034SJSA J AD Cover,Timer LED
211 GITAR0061SJSA J AL Rear Panel [CD-E44]
211 GITAR0068SJSA J Rear Panel
[CD-E500 For U.S.A.]
211 GITAR0069SJSA J AL Rear Panel [CD-E55 For U.S.A.]
211 GITAR0072SJSA J Rear Panel
[CD-E55 For Canada]
211 GITAR0073SJSA J Rear Panel
[CD-E500 For Canada]
212 HBDGA1005SJSA J AE SHARP Badge
213 JKNBZ0083SJSA J AD Button,Power [CD-E44/55]
213 JKNBZ0083SJSB J AD Button,Power [CD-E500]
214 JKNBZ0085SJSA J AF Button,Function [CD-E44/55]
214 JKNBZ0085SJSB J AF Button,Function [CD-E500]
215 JKNBZ0086SJSA J AF Button,Stop/Play [CD-E44/55]
215 JKNBZ0086SJSB J AF Button,Stop/Play [CD-E300]
216 JKNBZ0087SJSA J AD Button,X-BASS
217 JKNBZ0088SJSA J AF Button,Volume [CD-E44/55]
217 JKNBZ0088SJSB J AF Button,Volume [CD-E500]
218 JKNBZ0089SJSA J AE Button,Operation [CD-E44/55]
218 JKNBZ0089SJSB J AE Button,Operation [CD-E500]
219 KMECB0012SJZZ J Tape Mechanism Ass’y
219- 1 9GD18210721 J Belt,FF/REW
219- 2 9GD19210945 J Belt,Main,Tape 1
219- 3 9GD19210944 J Belt,Main,Tape 2
219- 4 9GD192104309 J AR Pinch Roller Arm Ass’y
219- 5(SOL801,802)
9GD19212118 J AP Solenoid Ass’y
219- 6 9GD62261401 J Head,Erase
219- 7 9GD620101111 J AR Head,Record/Playback
219- 8(SW801,802)
9GD19211305 J Switch,Leaf Type [Initialize]
219- 9(SW803) 9GD19211304 J Switch,Leaf Type [Rec]
219-10(M801) 9GD60020322 J Motor with Pulley [Tape]
219-11(PWB-H1,2)
9GD192114325 J Tape Mechanism PWB Ass’y
220 LANGK0056SJFW J Bracket,Main PWB
221 LANGK0059SJFW J Bracket,Cassette Lock
Lever,Tape 1
222 LANGK0060SJFW J Bracket,Cassette Lock
Lever,Tape 2
223 LANGK0065SJFW J Bracket,Terminal PWB
224 LANGK0066SJFW J Bracket,Power PWB
225 LCHSM0023SJFW J Shassis,Main
226 LHLDW1001SJZZ J AD Nylon Band
227 LHLDZ1062SJSA J Holder,FL Display
228 LHLDZ1072SJSA J Bracket,Front Panel Top
229 MLEVP0010SJSA J Lock Lever,Cassette,Tape 1
230 MLEVP0011SJSA J Lock Lever,Cassette,Tape 2
231 MSPRD0008SJFJ J AB Spring,Cassette Lock
Lever,Tape 1
232 MSPRD0030SJFW J AD Spring,Cassette Lock
Lever,Tape 2
233 NBLTK0009SJZZ J AE Belt [Rotate]
234 NBLTK0010SJZZ J AE Belt [Up/Down Loading]
235 PRDAR0076SJFW J Heat Sink
236 PRDAR0087SJFW J Heat Sink
1 237 QFSHD0001AWZZ J AB Holder,Fuse
238 KMECZ0006SJZZ J CD Player Unit Ass'y
1 238- 1 KRPLE0022SJM2 J CD Mechanism Ass’y
238- 2(M401) 9GD8301-PDJ01 J Motor with Pulley
[Up/Down Loading]
238- 3(M402) 9GD8301-PDJ02 J Motor with Pulley [Rotate]
238- 4(SW402) 9GD8301-DKG02 J Switch,Leaf Type [Open/Close]
238- 5(SW403) 9GDM03-DKG01 J Switch,Leaf Type [Disc No.]
238- 6(SW404) 9GDM03-DKG01 J Switch,Leaf Type [Disc 1]
601 LX-BZ0007SJFD J Screw,Special
602 LX-JZ0001SJFD J AA Screw,ø3×10mm
603 LX-JZ0002SJFD J AD Screw,Special
604 XHBSD20P03000 J AA Screw,ø2×3mm
605 XHBSD20P05000 J AA Screw,ø2×5mm
606 XHBSD30P06000 J AA Screw,ø3×6mm
607 XHBSD30P08000 J AA Screw,ø3×8mm
– 5 –
