Sharp CD-E500 User Manual

PRICE
RANK
DESCRIPTION
NO.
PART CODE
NO. PARTS CODE
PRICE
RANK
DESCRIPTION
CD-E500
CD-E55/E44
C901,902 RC-GZA107AF1H J AC 100 µF,50V,Electrolytic
C903~906 VCFYFA1HA104J J AC 0.1 µF,50V,Thin Film
C907 RC-GZV227AF1H J AC 220 µF,50V,Electrolytic
C908 RC-GZA476AF1H J AB 47 µF,50V,Electrolytic
C909 RC-GZV337AF1V J AB 330 µF,35V,Electrolytic
C910 RC-GZA107AF1H J AC 100 µF,50V,Electrolytic
RESISTORS
VRS-CY1JB000J J AA 0 ohm,Jumper,0.8×1.55mm,Green
R101 VRD-ST2EE102J J AA 1 kohm,1/4W
R102 VRD-ST2CD102J J AA 1 kohm,1/6W
R103,104 VRD-ST2CD103J J AA 10 kohm,1/6W
R105 VRD-ST2EE332J J AA 3.3 kohms,1/4W
R106 VRD-ST2EE682J J AA 6.8 kohms,1/4W
R107,108 VRD-ST2CD393J J AA 39 kohms,1/6W
R109,110 VRD-ST2EE102J J AA 1 kohm,1/4W
R111,112 VRD-ST2EE471J J AA 470 ohms,1/4W
R113,114 VRD-ST2CD102J J AA 1 kohm,1/6W
R115,116 VRD-ST2CD563J J AA 56 kohms,1/6W
1 R117,118 VRG-ST2EC101J J AB 100 ohm,1/4W,Fusible
R119,120 VRS-VV3AAR20J J AB 0.2 ohms,1W
R121~124 VRD-ST2EE472J J AA 4.7 kohms,1/4W
R125,126 VRD-ST2CD563J J AA 56 kohms,1/6W
R127 VRS-CY1JB102J J AA 1 kohm,1/16W
R127A VRD-ST2EE391J J AA 390 ohms,1/4W
R128 VRS-CY1JB102J J AA 1 kohm,1/16W
R128A VRD-ST2EE391J J AA 390 ohms,1/4W
R130 VRS-CY1JB562J J AA 5.6 kohms,1/16W
R131 VRD-ST2CD473J J AA 47 kohms,1/6W
R132 VRS-CY1JB223J J AA 22 kohms,1/16W
R135,136 VRD-ST2EE6R8J J AA 6.8 ohms,1/4W
R137,138 VRD-ST2EE4R7J J AA 4.7 ohms,1/4W
R201 VRD-ST2EE100J J AA 10 ohm,1/4W
R202 VRD-ST2CD223J J AA 22 kohms,1/6W
R203 VRD-ST2EE332J J AA 3.3 kohms,1/4W
R204 VRS-CY1JB103J J AA 10 kohm,1/16W
R205 VRD-ST2CD223J J AA 22 kohms,1/6W
R206 VRD-ST2CD103J J AA 10 kohm,1/6W
R207 VRD-ST2EE474J J AA 470 kohms,1/4W
R208 VRD-ST2EE183J J AA 18 kohms,1/4W
R209 VRD-ST2CD104J J AA 100 kohm,1/6W
R210 VRD-RT2HD560J J AA 56 ohms,1/2W
R211 VRD-ST2CD273J J AA 27 kohms,1/6W
R212 VRD-ST2CD104J J AA 100 kohm,1/6W
R213 VRD-ST2EE332J J AA 3.3 kohms,1/4W
R217 VRD-ST2CD103J J AA 10 kohm,1/6W
R218 VRD-ST2CD561J J AA 560 ohms,1/6W
R219 VRD-ST2CD102J J AA 1 kohm,1/6W
R221 VRD-ST2CD221J J AA 220 ohms,1/6W
R301 VRD-ST2EE220J J AA 22 ohms,1/4W
R302 VRS-CY1JB104J J AA 100 kohm,1/16W
R303 VRD-ST2CD333J J AA 33 kohms,1/6W
R304 VRS-CY1JB473J J AA 47 kohms,1/16W
R305 VRS-CY1JB681J J AA 680 ohms,1/16W
R306 VRS-CY1JB330J J AA 33 ohms,1/16W
R307 VRD-ST2EE470J J AA 47 ohms,1/4W
R308 VRS-CY1JB103J J AA 10 kohm,1/16W
R309 VRD-ST2EE471J J AA 470 ohms,1/4W
R310 VRS-CY1JB472J J AA 4.7 kohms,1/16W
R312 VRS-CY1JB222J J AA 2.2 kohms,1/16W
R313 VRS-CY1JB681J J AA 680 ohms,1/16W
R314,315 VRS-CY1JB330J J AA 33 ohms,1/16W
R316 VRS-CY1JB331J J AA 330 ohms,1/16W
R323 VRS-CY1JB683J J AA 68 kohms,1/16W
R336 VRD-ST2CD562J J AA 5.6 kohms,1/6W
R350 VRS-CY1JB272J J AA 2.7 kohms,1/16W
R351 VRS-CY1JB562J J AA 5.6 kohms,1/16W
R352 VRS-CY1JB102J J AA 1 kohm,1/16W
R353 VRS-CY1JB271J J AA 270 ohms,1/16W
R355 VRS-CY1JB332J J AA 3.3 kohms,1/16W
R356 VRS-CY1JB102J J AA 1 kohm,1/16W
R357 VRS-CY1JB474J J AA 470 kohms,1/16W
R358 VRS-CY1JB822J J AA 8.2 kohms,1/16W
R359 VRS-CY1JB182J J AA 1.8 kohms,1/16W
R360 VRS-CY1JB472J J AA 4.7 kohms,1/16W
R361,362 VRS-CY1JB123J J AA 12 kohms,1/16W
R363 VRD-ST2CD332J J AA 3.3 kohms,1/6W
R364 VRS-CY1JB332J J AA 3.3 kohms,1/16W
R365 VRS-CY1JB103J J AA 10 kohm,1/16W
R366 VRS-CY1JB222J J AA 2.2 kohms,1/16W
R371~374 VRS-CY1JB102J J AA 1 kohm,1/16W
R376 VRD-ST2CD103J J AA 10 kohm,1/6W
R377 VRD-ST2CD562J J AA 5.6 kohms,1/6W
R379 VRS-CY1JB222J J AA 2.2 kohms,1/16W
R380 VRD-ST2CD152J J AA 1.5 kohms,1/6W
R381 VRS-CY1JB103J J AA 10 kohm,1/16W
R382 VRD-ST2EE331J J AA 330 ohms,1/4W
R383 VRS-CY1JB562J J AA 5.6 kohms,1/16W
R384 VRD-ST2CD682J J AA 6.8 kohms,1/6W
R385 VRD-ST2CD562J J AA 5.6 kohms,1/6W
R386 VRD-ST2EE331J J AA 330 ohms,1/4W
R387 VRD-ST2CD562J J AA 5.6 kohms,1/6W
R391,392 VRD-ST2EE391J J AA 390 ohms,1/4W
R393 VRS-CY1JB102J J AA 1 kohm,1/16W
R395 VRD-ST2CD473J J AA 47 kohms,1/6W
R401 VRS-CY1JB104J J AA 100 kohm,1/16W
R402~405 VRS-CY1JB333J J AA 33 kohms,1/16W
R406 VRS-CY1JB104J J AA 100 kohm,1/16W
R407 VRS-CY1JB152J J AA 1.5 kohms,1/16W
R408 VRS-CY1JB332J J AA 3.3 kohms,1/16W
R409 VRS-CY1JB223J J AA 22 kohms,1/16W
R410 VRD-ST2CD223J J AA 22 kohms,1/6W
R411 VRD-ST2CD332J J AA 3.3 kohms,1/6W
R412 VRS-CY1JB152J J AA 1.5 kohms,1/16W
R413 VRS-CY1JB332J J AA 3.3 kohms,1/16W
R414 VRD-ST2CD471J J AA 470 ohms,1/6W
R415 VRD-ST2CD470J J AA 47 ohms,1/6W
R416 VRD-ST2CD123J J AA 12 kohms,1/6W
R417 VRS-CY1JB3R3J J AA 3.3 ohms,1/16W
R418 VRD-ST2CD104J J AA 100 kohm,1/6W
R419 VRD-ST2CD273J J AA 27 kohms,1/6W
R420 VRS-CY1JB331J J AA 330 ohms,1/16W
R421,422 VRS-CY1JB103J J AA 10 kohm,1/16W
R423 VRD-ST2CD682J J AA 6.8 kohms,1/6W
R424 VRS-CY1JB122J J AA 1.2 kohms,1/16W
R425 VRD-ST2CD153J J AA 15 kohms,1/6W
R426 VRS-CY1JB123J J AA 12 kohms,1/16W
R427,428 VRD-ST2CD102J J AA 1 kohm,1/6W
R429,430 VRS-CY1JB681J J AA 680 ohms,1/16W
R431 VRD-ST2CD103J J AA 10 kohm,1/6W
R434 VRD-ST2CD103J J AA 10 kohm,1/6W
R435~439 VRD-ST2CD102J J AA 1 kohm,1/6W
R440 VRD-ST2CD101J J AA 100 ohm,1/6W
R441 VRD-ST2CD102J J AA 1 kohm,1/6W
R442 VRD-ST2CD222J J AA 2.2 kohms,1/6W
R443 VRS-CY1JB101J J AA 100 ohm,1/16W
R446 VRD-ST2CD103J J AA 10 kohm,1/6W
R447 VRD-ST2CD101J J AA 100 ohm,1/6W
R448 VRD-ST2CD103J J AA 10 kohm,1/6W
R449 VRD-ST2CD222J J AA 2.2 kohms,1/6W
R451 VRS-CY1JB101J J AA 100 ohm,1/16W
R452 VRD-ST2EE221J J AA 220 ohms,1/4W
R453 VRD-ST2EE680J J AA 68 ohms,1/4W
R601~609 VRD-ST2CD102J J AA 1 kohm,1/6W
R612 VRD-ST2CD392J J AA 3.9 kohms,1/6W
R613 VRS-CY1JB392J J AA 3.9 kohms,1/16W
R614,615 VRD-ST2CD103J J AA 10 kohm,1/6W
R616~619 VRD-ST2CD333J J AA 33 kohms,1/6W
R620,621 VRD-ST2CD392J J AA 3.9 kohms,1/6W
R622,623 VRD-ST2CD104J J AA 100 kohm,1/6W
R624,625 VRD-ST2CD123J J AA 12 kohms,1/6W
R628,629 VRD-ST2CD102J J AA 1 kohm,1/6W
R630 VRD-ST2EE221J J AA 220 ohms,1/4W
R641,642 VRS-CY1JB223J J AA 22 kohms,1/16W
R643,644 VRS-CY1JB222J J AA 2.2 kohms,1/16W
R701~707 VRD-ST2CD102J J AA 1 kohm,1/6W
R708 VRS-CY1JB102J J AA 1 kohm,1/16W
R709 VRD-ST2CD102J J AA 1 kohm,1/6W
R712~714 VRD-ST2CD102J J AA 1 kohm,1/6W
R715 VRS-CY1JB102J J AA 1 kohm,1/16W
R716~718 VRD-ST2CD102J J AA 1 kohm,1/6W
R719 VRD-ST2CD101J J AA 100 ohm,1/6W
R720~722 VRD-ST2CD102J J AA 1 kohm,1/6W
R725 VRD-ST2CD271J J AA 270 ohms,1/6W
R726,727 VRD-ST2CD103J J AA 10 kohm,1/6W
R728~732 VRD-ST2CD102J J AA 1 kohm,1/6W
R733 VRD-ST2CD272J J AA 2.7 kohms,1/6W
R734,735 VRD-ST2CD103J J AA 10 kohm,1/6W
R736~739 VRD-ST2CD102J J AA 1 kohm,1/6W
R742,743 VRD-ST2CD103J J AA 10 kohm,1/6W
R744 VRD-ST2CD102J J AA 1 kohm,1/6W
R744A VRD-ST2CD473J J AA 47 kohms,1/6W
– 3 –
