Sharp CD-E500 User Manual

PRICE
RANK
DESCRIPTION
NO.
PART CODE
NO. PARTS CODE
PRICE
RANK
DESCRIPTION
CD-E500
CD-E55/E44
INTEGRATED CIRCUITS
IC101 VHISTK40207-1 J AZ Power Amp.,STK40207
IC201 VHIKIA7805API J AF Voltage Regulator,KIA7805API
IC202 VHIKIA7812API J Voltage Regulator,KIA7812API
IC203 VHIKIA7808API J AF Voltage Regulator,KIA7808API
IC301 VHITA7358AP-1 J AG FM Front End,TA7358AP
IC302 VHILC72131/-1 J AP PLL (Tuner),LC72131
IC303 VHILA1832S/-1 J AN FM IF Det./FM Mpx./AM IF,
LA1832S
IC401 VHILC78646E-1 J AY Servo/Signal Control,LC78646E
IC402 VHILA6548D/-1 J AN Focus/Tracking/Spin/Sled Driver,
LA6548D
IC601 VHILC75341M-1 J AM Audio Processor,LC75341M
IC701 RH-IX0058SJZZ J BH System Microcomputer,
IX0058SJ
IC801 VHIAN7345K/-1 J AM Playback and Record/Playback
Amp.,AN7345K
TRANSISTORS
Q101~107 VSKSC1815GR-1 J AB Silicon,NPN,KSC1815 GR
Q108 VSKRA107M//-1 J AE Digital,PNP,KRA107 M
Q109 VSKRC107M//-1 J AC Digital,NPN,KRC107 M
Q201 VSHSC1609GR-1 J AC Silicon,NPN,HSC1609 GR
Q202 VSSC1674-C/-1 J AC Silicon,NPN,SSC1674 C
Q203 VSKSC1815GR-1 J AB Silicon,NPN,KSC1815 GR
Q204 VSKSA1015GR-1 J AB Silicon,PNP,KSA1015 GR
Q205 VSKSC1815GR-1 J AB Silicon,NPN,KSC1815 GR
Q206 VSHSB562-C/-1 J AC Silicon,PNP,HSB562 C
Q207,208 VSKSC1815GR-1 J AB Silicon,NPN,KSC1815 GR
Q302 VSSC1674-C/-1 J AC Silicon,NPN,SSC1674 C
Q306 VSSC1674-C/-1 J AC Silicon,NPN,SSC1674 C
Q351 VSKRC104M//-1 J AC Digital,NPN,KRC104 M
Q360 VSKSA1015GR-1 J AB Silicon,PNP,KSA1015 GR
Q401 VSKSC3203Y/-1 J AC Silicon,NPN,KSC3203 Y
Q402 VSKSA1271Y/-1 J AC Silicon,PNP,KSA1271 Y
Q403,404 VSKSC1815GR-1 J AB Silicon,NPN,KSC1815 GR
Q405 VSKSA1271Y/-1 J AC Silicon,PNP,KSA1271 Y
Q406 VSKSC3203Y/-1 J AC Silicon,NPN,KSC3203 Y
Q407 VSKSC1815GR-1 J AB Silicon,NPN,KSC1815 GR
Q408 VSKSA1271Y/-1 J AC Silicon,PNP,KSA1271 Y
Q409 VSKSA1015GR-1 J AB Silicon,PNP,KSA1015 GR
Q411 VSHSB562-C/-1 J AC Silicon,PNP,HSB562 C
Q412 VSKSC3203Y/-1 J AC Silicon,NPN,KSC3203 Y
Q701 VSKSC1815GR-1 J AB Silicon,NPN,KSC1815 GR
Q702 VSKRC102M//-1 J AC Digital,NPN,KRC102 M
Q703,704 VSKSC1815GR-1 J AB Silicon,NPN,KSC1815 GR
Q801 VSKSC1815GR-1 J AB Silicon,NPN,KSC1815 GR
Q802 VSKSA1015GR-1 J AB Silicon,PNP,KSA1015 GR
Q803 VSKSC1815GR-1 J AB Silicon,NPN,KSC1815 GR
Q804,805 VSHSB562-C/-1 J AC Silicon,PNP,HSB562 C
Q806 VSKRC107M//-1 J AC Digital,NPN,KRC107 M
Q807,808 VSKSC1815GR-1 J AB Silicon,NPN,KSC1815 GR
Q809 VSKRC107M//-1 J AC Digital,NPN,KRC107 M
Q810,811 VSKRC104M//-1 J AC Digital,NPN,KRC104 M
Q812~814 VSKSC1815GR-1 J AB Silicon,NPN,KSC1815 GR
Q815 VSHSB562-C/-1 J AC Silicon,PNP,HSB562 C
Q816~818 VSKRC102M//-1 J AC Digital,NPN,KRC102 M
Q819 VSKSC1815GR-1 J AB Silicon,NPN,KSC1815 GR
Q820 VSKRA102M//-1 J AC Digital,PNP,KRA102 M
Q821 VSKRC104M//-1 J AC Digital,NPN,KRC104 M
Q822 VSKSA1015GR-1 J AB Silicon,PNP,KSA1015 GR
Q823 VS2SC2001-K-1 J AD Silicon,NPN,2SC2001 K
Q901 VSKSA1015GR-1 J AB Silicon,PNP,KSA1015 GR
DIODES
D101~103 VHD1N4148//-1 J AA Silicon,1N4148
D104 VHD1N4004//-1 J AB Silicon,1N4004
D201~205 VHD1N4004//-1 J AB Silicon,1N4004
D207 VHD1N4004//-1 J AB Silicon,1N4004
D210 VHD1N4004//-1 J AB Silicon,1N4004
D301,302 VHD1N4148//-1 J AA Silicon,1N4148
D305~308 VHD1N4148//-1 J AA Silicon,1N4148
D401,402 VHD1N4004//-1 J AB Silicon,1N4004
D405 VHD1N4004//-1 J AB Silicon,1N4004
D604,605 VHD1N4148//-1 J AA Silicon,1N4148
D701 VHD1N4004//-1 J AB Silicon,1N4004
D702~705 VHD1N4148//-1 J AA Silicon,1N4148
D706 VHD1N4004//-1 J AB Silicon,1N4004
D801~805 VHD1N4148//-1 J AA Silicon,1N4148
1 D901~904 VHD1N6A2M++-1 J Silicon,1N6A2M++
1 D905~908 VHD1N4004//-1 J AB Silicon,1N4004
D909~911 VHD1N4004//-1 J AB Silicon,1N4004
LED701 VHPSD3210W+-1 J AC LED,White,SD3210W+
VD301 VHCSVC348S/-1 J AK Variable Capacitance,SVC348S
VD302,303 VHCKDV147B/-1 J AH Variable Capacitance,KDV147B
1 J213 VHHMZC950//-1 J Thermistor
ZD201 VHEDZH05C2+-1 J AB Zener,5.1V,DZH05C2+
ZD351 VHEDZH05C2+-1 J AB Zener,5.1V,DZH05C2+
ZD401 VHEDZH03C3+-1 J AB Zener,3.3V,DZH03C3+
ZD402 VHEDZH06B2+-1 J Zener,6.2V,DZH06B2+
ZD701 VHEDZH03C3+-1 J AB Zener,3.3V,DZH03C3+
ZD901 VHEDZH3001+-1 J AB Zener,30V,DZH3001+
ZD902 VHEDZH06C2+-1 J AB Zener,6.2V,DZH06B2+
FILTERS
BF301 RFILR0008AWZZ J AE Band Pass Filter
CF302,303 RFILF0004SJZZ J AG FM IF,10.7 MHz
CF351 RFILF0003AWZZ J AK FM IF
CF352 RFILA0003SJZZ J AF AM IF
TRANSFORMERS
T302 RCILA0007SJZZ J AG AM Tracking
T304 RCILI0005SJZZ J AF FM IF
T306 RCILB0009SJZZ J AG AM OSC.
T351 RCILI0004SJZZ J AF AM IF
1 T901 RTRNP0119SJZZ J BA Power Transformer
COILS
L103 VP-DH100K0000 J AB 10 µH,Choke
L105 VP-DH2R2K0000 J AB 2.2 µH,Peaking
L302 RCILR0003SJZZ J AD FM RF
L303 RCILB0016SJZZ J AD FM OSC.
L351,352 VP-DH101K0000 J AB 100 µH,Choke
L353 VP-DH102K0000 J AB 1 mH,Choke
L401~412 VP-DHR82K0000 J AE 0.82 µH,Choke
L601 VP-DH2R2K0000 J AB 2.2 µH,Peaking
L701~705 VP-DHR82K0000 J AE 0.82 µH,Choke
L801 VP-MK331K0000 J AB 330 µH,Choke
VARIABLE RESISTOR
VR351 RVR-M0026AWZZ J AC 10 kohm (B),Semi-VR
[FM Mute Level]
VIBRATORS
X351 RCRM-0007SJZZ J AG VCO,456 kHz
X352 RCRSP0003SJZZ J AL Crystal,4.5 MHz
X401 RCRSP0002SJZZ J AL Crystal,16.9344 MHz
X702 RCRSP0013SJZZ J AE Crystal,8 MHz
CAPACITORS
C101 RC-GZA336AF1C J AB 33 µF,16V,Electrolytic
C102 RC-GZA335AF1C J AB 3.3 µF,16V,Electrolytic
C103,104 RC-GZA105AF1H J AB 1 µF,50V,Electrolytic
C105,106 VCKYPA1HB152K J AA 0.0015 µF,50V
C107,108 RC-GZA106AF1H J AB 10 µF,50V,Electrolytic
C109,110 VCCCPA1HH3R0C J AA 3 pF (CH),50V
C111,112 RC-GZA106AF1H J AB 10 µF,50V,Electrolytic
C113,114 VCKYPA1HF223Z J AB 0.022 µF,50V
C115,116 RC-GZA107AF1H J AC 100 µF,50V,Electrolytic
C117,118 VCKYPA1HF223Z J AB 0.022 µF,50V
C119,120 VCKYCY1HB221K J AA 220 pF,50V
C121 VCKYCY1HB102K J AA 0.001 µF,50V
C125~128 VCFYFA1HA104J J AC 0.1 µF,50V,Thin Film
C130 RC-GZA476AF1H J AB 47 µF,50V,Electrolytic
C133~136 VCKYPA1HF223Z J AB 0.022 µF,50V
C145,146 VCKYPA1HB472K J AB 0.0047 µF,50V
C201 RC-GZA107AF1C J AB 100 µF,16V,Electrolytic
C202 VCKYPA1HF223Z J AB 0.022 µF,50V
C203 RC-GZW338AF1V J AH 3300 µF,35V,Electrolytic
C204 VCKYPA1HF223Z J AB 0.022 µF,50V
C205 RC-GZA227AF1E J AB 220 µF,25V,Electrolytic
– 1 –
