Sharp CD-M10000

NO.
PRICE
RANK
DESCRIPTIONPARTS CODE
NO. PART CODE
PRICE
RANK
DESCRIPTION
CD-M10000W/CP-M10000
– 6 –
SW702 92LSWICHT1663T J AC Switch,Key Type [Clock]
SW703 92LSWICHT1663T J AC Switch,Key Type [Timer]
SW709 92LSWICHT1663T J AC Switch,Key Type [Disc 1]
SW710 92LSWICHT1663T J AC Switch,Key Type [Disc 2]
SW711 92LSWICHT1663T J AC Switch,Key Type [Disc 3]
SW712 92LSWICHT1663T J AC Switch,Key Type [Disc Skip]
SW713 92LSWICHT1663T J AC Switch,Key Type [Open/Close]
SW714 92LSWICHT1663T J AC Switch,Key Type [Dimmer]
SW715 92LSWICHT1663T J AC Switch,Key Type [Monster Bass]
SW716 92LSWICHT1663T J AC Switch,Key Type [Equalizer]
SW717 92LSWICHT1663T J AC Switch,Key Type
[Reverse Mode]
SW722 92LSWICHT1663T J AC Switch,Key Type [CD]
SW723 92LSWICHT1663T J AC Switch,Key Type [Tape]
SW724 92LSWICHT1663T J AC Switch,Key Type [Tuning Down]
SW725 92LSWICHT1663T J AC Switch,Key Type [Memory Set]
SW726 92LSWICHT1663T J AC Switch,Key Type [Fast Rewind]
SW727 92LSWICHT1663T J AC Switch,Key Type [Fast Forward]
SW728 92LSWICHT1663T J AC Switch,Key Type [Play]
SW729 92LSWICHT1663T J AC Switch,Key Type [Stop]
SW730 92LSWICHT1663T J AC Switch,Key Type [Reverse Play]
SW731 92LSWICHT1663T J AC Switch,Key Type
[RECORD/Pause]
SW732 92LSWICHT1663T J AC Switch,Key Type [Tuning Up]
SW733 92LSWICHT1663T J AC Switch,Key Type [Video]
SW734 92LSWICHT1663T J AC Switch,Key Type [Tuner]
1 SW801 QSOCE0010AWZZ J Switch,Slide Type [Voltage
Selector]
CD MECHANISM PARTS
301 NGERH0011AWZZ J AC Gear,Middle
302 NGERH0012AWZZ J AC Gear,Drive
303 MLEVP0080AWZZ J AC Rail,Guide
304 NSFTM0020AWFW J AD Shaft,Guide
305 92LM-CUSN1524A J AC Cushion
1 306 92LHPC1LXASY J BD Pickup Unit Ass’y
306- 1 ———— — Pickup Unit
(Not Replacement Item)
306- 2 NGERR0043AFZZ J AC Gear,Rack
306- 3 MSPRC0961AFZZ J AA Spring,Rack
701 XBSSD26P06000 J AA Screw,ø2.6×6mm
702 XHBSD20P05000 J AA Screw,ø2×5mm
703 XBBSD20P03000 J AA Screw,ø2×3mm
704 LX-WZ1070AFZZ J AA Washer,ø1.5×3.8×0.25mm
M1 92LMTR2790CASY J BB Motor with Chassis [Spindle]
M2 92LMTR1854BASY J AP Motor with Gear [Sled]
SW4 QSW-F9001AW01 J AD Switch,Leaf Type [Pickup In]
CABINET PARTS
201 92LCAB3808AASY J Front Panel Ass’y
201- 1 ———— — Front Panel
(Not Replacement Item)
201- 2 GDORF0097AWSA J AE Holder,Cassette [Tape 1]
201- 3 GDORF0098AWSA J AE Holder,Cassette [Tape 2]
201- 4 GCOVA1352AWSA J AH Cover,Cassette [Tape 1]
201- 5 GCOVA1384AWSA J AK Cover,Cassette [Tape 2]
201- 6 HDECQ0670AWSA J AE Panel,Cassette [Tape 1]
201- 7 HDECQ0671AWSA J AE Panel,Cassette [Tape 2]
201- 8 HDECQ0829AWSA J Panel,Amp.
201- 9 JKNBZ0820AWSA J AE Button,ON/Stand-by
201-10 JKNBZ0766AWSA J AG Button,Dimmer/Tuning
201-11 JKNBZ0768AWSA J AE Button,Function
201-12 HDECQ0674AWSA J AE Volume Ring
201-13 JKNBZ0800AWSA J AF Button,Disc Control
201-14 JKNBZ0801AWSA J AG Button,Center Operation
201-15 MLIFP0008AWZZ J AD Damper
201-16 JKNBZ0834AWSA J AG Button,Equalizer/Monster Bass
201-17 92LBADGE1671A J AC Badge,SHARP
201-18 GCOVA1339AWSA J AB Cover,LED,Power
201-19 GCOVA1380AWSA J AB Cover,LED,A
201-20 GCOVA1381AWSA J AB Cover,LED,B
201-21 PSPAK0006AWZZ J AB Spacer,Cassette Lock Holder
201-22 MLOKC0006AWZZ J AB Lock Lever,Cassette [Tape 1]
201-23 MLOKC0007AWZZ J AB Lock Lever,Cassette [Tape 2]
201-24 LHLDZ1328AWZZ J AC Holder,Cassette Lock
201-25 GCOVA1382AWSA J AB Cover,LED,C
201-26 GCOVA1344AWSA J AB Cover,Disc No.LED,A
201-27 GCOVA1345AWSA J AB Cover,Disc No.LED,B
201-28 GCOVA1346AWSA J AB Cover,Disc No.LED,C
201-29 GCOVA1394AWSA J AD Cover,Remote Control Sensor
201-30 MSPRC0029AWFJ J AB Spring,Cassette Lock
201-31 PSHEM0008AWZZ J AD Sheet,Shield
201-32 GCOVA1404AWSA J AE Cover,Monster Button
201-33 MSPRD0167AWFJ J AB Spring,Cassette [Tape 1]
201-34 MSPRD0168AWFJ J AB Spring,Cassette [Tape 2]
202 92LCAB3808BASY J Side Panel Ass’y,Left
202- 1 ———— — Side Panel,Left
(Not Replacement Item)
202- 2 PCUSG0022AWZZ J AB Cushion,Leg
203 92LCAB3808CASY J Side Panel Ass’y,Right
203- 1 ———— — Side Panel,Right
(Not Replacement Item)
203- 2 PCUSG0022AWZZ J AB Cushion,Leg
204 GCAB-1192AWSA J AN Top Cabinet
206 GCOVA1338AWSA J AH Cover,CD Tray
207 GITAR0873AWSA J Rear Panel
[Except for Philippines/Russia]
207 GITAR0932AWSA J Rear Panel [For Philippines]
207 GITAR0933AWSA J Rear Panel [For Russia]
209 LANGK0318AWFW J Bracket,Main Heat Sink [Left]
210 LANGK0311AWFW J Bracket,Main Heat Sink [Right]
211 LANGK0313AWFW J Bracket,Fan Support A
213 LCHSM0149AWFW J Chassis,Main
214 LHLDZ1332AWZZ J AD Holder,FL Display
215 QCNWN2030AWZZ J AD Lug Wire
218 NFANP0001AWZZ J AD Rotary Fan
219 PCUSG0022AWZZ J AB Cushion,Leg
220 PRDAR0228AWFW J Heat Sink,Main
221 PRDAR0227AWFW J Heat Sink,Sub
1 222 QACCA0005AW00 J AC Power Supply Cord
1 222 QACCE0014AW00 J AC Power Supply Cord
1 222 QACCL0007AW00 J AC Power Supply Cord
223 QCNWN2200AWZZ J Lug Wire
1 224 QFSHD0001AWZZ J AB Holder,Fuse
225 92LBE231616 J AD Belt
226 92LCSPR1431C J AA Spring,Ring
227 92LEVA0330702 J AD Velvet Carpet,Chassis
228 92LMAG0104302 J AE Magnet
229 92LMT0304302 J AB Plate,Metal
230 92LNBAND1318A J AA Nylon Band,80mm
231 TWPT0312005 J Cam Gear Ass’y
231- 1 92LPT0312005 J AL Gear,Cam
231- 2 92LSP0304303 J AB Spring,Stopper
231- 3 92LPT0304304 J AB Stopper
231- 4 92LNM0305401 J AB Velvet Carpet
231- 5 92LPT0305413 J AG Cam Gear Lower
232 92LPT0303002 J AB Roller
233 92LPT0304303 J AB Lever,Stop
235 92LPT0304305 J AE Lever,Lock
236 92LPT0304306 J AG Stabilizer
237 92LPT0304307 J AC Support,Cam
238 92LPT0304308 J AB Lock Gear Pin
239 92LPT0304309 J AB Cap,Pulley Stopper
241 92LPT0309506 J AD Gear,Turntable Drive
242 92LPT0309507 J AD Gear,Open/Close Drive
243 92LPT0309508 J AD Gear,Planet
244 92LPT0309509 J AD Gear,Drive
245 92LPT0309510 J AE Gear,Pulley
246 92LPT0309511 J AD Gear,Middle
247 92LPT0311101 J AB Lever,Clamp
248 92LPT0311102 J AC Lever,Disc
250 92LPT0320201 J AE Support,Stabilizer
251 92LPT0330301 J AU Chassis,Loading
252 92LPT0330803 J AK Chassis,CD Mechanism
253 92LPT0331003 J AT Shassis,Slide
254 92LPT0331105 J AM Turntable
256 92LSP0304305 J AB Spring,Lock
257 92LSP0304306 J AB Spring,Lock Gear
258 KMECB0019AWZZ J BH Tape Mechanism Ass’y
258- 1 92PF513-853 J BL Head Plate Block [Tape 2]
258- 2 92PF525-336 J BE Motor with Pulley [Tape]
258- 3 92PF567-677 J BA Tape Mechanism PWB Ass’y
258- 4 92PFF19N-21 J AL Belt,Main [Tape 2]
258- 5 92PF514-133 J AL Pinch Roller
258- 6 92PF19S-31 J AL Belt,FF/REW [Tape 2]
258- 7 92PFF19N-11 J AL Belt,Main [Tape 1]
258- 8 92PF522-061 J AZ Clutch Ass’y Block [Tape 1]
258- 9 92PFF19S-52 J AL Belt,FF/REW [Tape 1]
258-10 92PF513-861 J AG Head Plate Block [Tape 1]
258-11 92PF522-063 J AZ Clutch Ass’y Block [Tape 2]
