CD-M10000W/CP-M10000
CP-M10000 (MAIN SPEAKER)
A
B
C
D
E
F
G
H
1
23456
– 12 –
Figure 12 SPEAKER EXPLODED VIEW (2/2)
931
932
935
930
940x4
941x4
SP7,8
SP3,4
SP5,6
941x4
934x4
933
936
BK
BK
BL
BK
BL
RD
SP3,4
WOOFER
SP5,6
WOOFER
SP7,8
TWEETER
SPEAKER
TERMINAL
TWEETER
SP7(L-CH)
SP8(R-TH)
WOOFER
SP5(L-CH)
SP6(R-TH)
WOOFER
SP3(L-CH)
SP4(R-TH)
SPEAKER
TERMINAL
C1,2
Capacitor(N.P.)
2.2 µF,250 V
Electrolytic
C1,2
Capacitor(N.P.)
2.2 µF,250 V
Electrolytic
