Sharp CD-PC3500

PRICE
RANK
DESCRIPTIONNO.
PARTS CODE NO. PARTS CODE
PRICE
RANK
DESCRIPTION
CD-PC3500
RD27 VRD-ST2CD223J J AA 22 kohms,1/6W
RD28 VRD-ST2CD333J J AA 33 kohms,1/6W
RD29 VRD-ST2CD104J J AA 100 kohm,1/6W
RM710~712 VRD-ST2CD104J J AA 100 kohm,1/6W
RM713~715 VRD-ST2CD102J J AA 1 kohm,1/6W
RS701~704 VRD-ST2CD102J J AA 1 kohm,1/6W
RS708~710 VRD-ST2CD103J J AA 10 kohm,1/6W
RS714~718 VRD-ST2CD102J J AA 1 kohm,1/6W
RS720 VRD-MN2BD221J J AA 220 ohms,1/8W
RS721,722 VRD-MN2BD102J J AA 1 kohm,1/8W
RS723 VRD-ST2CD102J J AA 1 kohm,1/6W
RS724~726 VRD-ST2CD103J J AA 10 kohm,1/6W
OTHER CIRCUITRY PARTS
BI4/CNS4 QCNWN1572AWZZ J AF Connector Ass’y,6/6Pin
BI99/CNS99 QCNWN1611AWZZ J AG Connector Ass’y,3/3Pin
BI101/CNS101 QCNCM705CAFZZ J AA Connector Ass’y,3/3Pin
BI102/CNS102 QCNCM705GAFZZ J AB Connector Ass’y,7/7Pin
BI401/CNS401 QCNWN1540AWZZ J AF Connector Ass’y,5/5Pin
BI701/CNS701 QCNWN1541AWZZ J AH Connector Ass’y,12/12Pin
BI702/CNS702 QCNWN1607AWZZ J AG Connector Ass’y,9/9Pin
CNP1 QCNCM704GAWZZ J AC Plug,7Pin
CNP2 QCNCM704HAWZZ J AC Plug,8Pin
CNP3 92LCONE6P53253 J AC Plug,6Pin
CNP4 QCNCM705FAFZZ J AB Plug,6Pin
CNP11 92LCONE5P53254 J AB Plug,5Pin
CNP12 92LCONEAP53254 J AD Plug,10Pin
CNP301 92LCONE3P5268 J AC Plug,3Pin
CNP602 QCNCWZG23AWZZ J AE Plug,23Pin
CNP701 QCNCWZF23AWZZ J AE Plug,23Pin
CNP702 QCNCWZF13AWZZ J AC Plug,13Pin
CNP801 QCNCM049BAWZZ J AC Plug,2Pin
CNP802 92LCONE8P5267X J AD Plug,5Pin
CNP803 QCNWM050CAWZZ J AB Plug,3Pin
CNP804 92LCONE9P53253 J AB Plug,9Pin
CNS1A/B QCNWN1537AWZZ J AG Connector Ass’y,7/7Pin
CNS2A/B QCNWN1538AWZZ J AG Connector Ass’y,8/8Pin
CNS3A/B QCNWN1539AWZZ J AE Connector Ass’y,6/6Pin
CNS806 QCNWN1542AWZZ J AC Connector Ass’y,2Pin
! F801,802 92LFUSE-T402D J AD Fuse,5A/125V
! F803,804 92LFUSET502D J AC Fuse,4A/125V
! F805 92LFUSET202D J AC Fuse,2A/250V
FC701 QCNWN1564AWZZ J AG Flat Cable,23Pin
FC702 QCNWN1544AWZZ J AE Flat Cable,13Pin
FL701 VVKBJ744GNK-1 J BD FL Display
IC99 VHPTOTX178A-1 J AP Optical Fiber Data Link,
TOTX178A
FW907 QCNWN1610AWZZ J AD Flat Wire,5Pin
JK201 QSOCJ0409AWZZ J AF Jack,Video In
JK501 QSOCJ0111AWZZ J AD Sub Woofer Output
JK601 QJAKM0004AWZZ J AF Jack,Headphones
JOG701 QSW-Z0010AWZZ J AF Switch,Push Type [Jog]
LG901,902 QLUGP0001AWZZ J AC Lug
M1 92LMTR2790CASY J BB Motor with Chassis [Spindle]
M2 92LMTR1854BASY J AP Motor with Gear [Sled]
M3 92LTWMEN7E6Y J Motor with Worm Pulley
[T/T Up/Down Loading]
M901 RMOTV0027AWZZ J AM Motor,Air Cooling Fan
RL801 RRLYD0001SJZZ J AQ Relay
RL901,902 RRLYD0014AWZZ J AP Relay
RX701 VHLN63H380A-1 J AK Remote Sensor,N63H380A
SO901 QTANA1003AWZZ J AG Terminal,Speaker
SW1 SWMPU10780MLB J Switch,Push Type [Open/Close]
SW2 SWMPU11470MLB J Switch,Push Type [Clamp]
SW3 SWMPU11470MLB J Switch,Push Type [Disc Number]
SW4 QSW-F9001AW01 J AD Switch,Leaf Type [Pickup In]
SW701 92LSWICH1401AT J AC Switch,Key Type [CD]
SW702 92LSWICH1401AT J AC Switch,Key Type [TAPE]
SW703 92LSWICH1401AT J AC Switch,Key Type
[TUNING DOWN]
SW704 92LSWICH1401AT J AC Switch,Key Type
[MEMORY/SET]
SW705 92LSWICH1401AT J AC Switch,Key Type [REV]
SW706 92LSWICH1401AT J AC Switch,Key Type [FF]
SW707 92LSWICH1401AT J AC Switch,Key Type [PLAY]
SW708 92LSWICH1401AT J AC Switch,Key Type [STOP]
SW710 92LSWICH1401AT J AC Switch,Key Type [REC]
SW711 92LSWICH1401AT J AC Switch,Key Type [TUNING UP]
SW712 92LSWICH1401AT J AC Switch,Key Type [VIDEO]
SW713 92LSWICH1401AT J AC Switch,Key Type [TUNING]
– 5 –
R811 VRD-ST2CD123J J AA 12 kohms,1/6W
R812 VRD-ST2CD473J J AA 47 kohms,1/6W
R813 VRD-ST2CD100J J AA 10 ohm,1/6W
R814 VRD-ST2CD222J J AA 2.2 kohms,1/6W
R815 VRD-ST2CD102J J AA 1 kohm,1/6W
R816 VRD-ST2CD473J J AA 47 kohms,1/6W
R817 VRD-ST2EE221J J AA 220 ohms,1/4W
R821 VRD-RT2HD3R3J J AA 3.3 ohms,1/2W
R901 VRD-ST2CD102J J AA 1 kohm,1/6W
R902 VRD-ST2CD821J J AA 820 ohms,1/6W
R903 VRD-ST2CD563J J AA 56 kohms,1/6W
R904 VRD-ST2CD102J J AA 1 kohm,1/6W
! R905 VRG-ST2EC101J J AB 100 ohm,1/4W,Fusible
R906 VRD-ST2CD223J J AA 22 kohms,1/6W
R907 VRD-ST2EE0R1J J 0.1 ohms,1/4W
R908 VRD-ST2CD102J J AA 1 kohm,1/6W
R909 VRD-ST2CD103J J AA 10 kohm,1/6W
! R910 VRG-ST2EC101J J AB 100 ohm,1/4W,Fusible
R911 VRD-ST2EE0R1J J 0.1 ohms,1/4W
R912 VRD-ST2CD102J J AA 1 kohm,1/6W
R913 VRD-ST2CD103J J AA 10 kohm,1/6W
R914 VRD-ST2CD821J J AA 820 ohms,1/6W
R915 VRD-ST2CD563J J AA 56 kohms,1/6W
R916,917 VRD-ST2CD102J J AA 1 kohm,1/6W
R918~920 VRD-ST2CD563J J AA 56 kohms,1/6W
R921,922 VRD-ST2CD683J J AA 68 kohms,1/6W
R923,924 VRD-ST2EE4R7J J AA 4.7 ohms,1/4W
R930 VRD-ST2CD223J J AA 22 kohms,1/6W
! R931 VRG-ST2EC0R1J J 0.1 ohms,1/4W,Fusible
R932 VRD-ST2CD102J J AA 1 kohm,1/6W
R933 VRD-ST2CD563J J AA 56 kohms,1/6W
R934 VRD-ST2CD102J J AA 1 kohm,1/6W
R935 VRN-VV3AAR10J J 0.1 ohm,1W
R936 VRD-ST2CD102J J AA 1 kohm,1/6W
R937 VRD-ST2CD821J J AA 820 ohms,1/6W
R938 VRD-ST2CD103J J AA 10 kohm,1/6W
R939,940 VRD-ST2CD683J J AA 68 kohms,1/6W
! R941 VRG-ST2EC0R1J J 0.1 ohms,1/4W,Fusible
R942 VRN-VV3AAR10J J 0.1 ohm,1W
R943 VRD-ST2CD102J J AA 1 kohm,1/6W
R944 VRD-ST2CD103J J AA 10 kohm,1/6W
R945 VRD-ST2CD821J J AA 820 ohms,1/6W
R946 VRD-ST2CD563J J AA 56 kohms,1/6W
R947,948 VRD-ST2CD102J J AA 1 kohm,1/6W
R949~951 VRD-ST2CD563J J AA 56 kohms,1/6W
R952,953 VRD-ST2CD222J J AA 2.2 kohms,1/6W
R954,955 VRD-RT2HD331J J AA 330 ohms,1/2W
R956,957 VRD-ST2CD222J J AA 2.2 kohms,1/6W
R958,959 VRD-ST2CD473J J AA 47 kohms,1/6W
R960,961 VRD-ST2EE4R7J J AA 4.7 ohms,1/4W
R971 VRD-RT2HD4R7J J AA 4.7 ohms,1/2W
R972 VRD-ST2CD153J J AA 15 kohms,1/6W
R973 VRD-ST2CD102J J AA 1 kohm,1/6W
R974 VRD-ST2CD683J J AA 68 kohms,1/6W
R987~990 VRN-VV3DAR22J J AC 0.22 ohms,2W
R991 VRD-ST2CD473J J AA 47 kohms,1/6W
RD1 VRD-ST2CD821J J AA 820 ohms,1/6W
RD2 VRD-ST2CD122J J AA 1.2 kohms,1/6W
RD3 VRD-ST2CD152J J AA 1.5 kohms,1/6W
RD4 VRD-ST2CD182J J AA 1.8 kohms,1/6W
RD5 VRD-ST2CD392J J AA 3.9 kohms,1/6W
RD6 VRD-ST2CD682J J AA 6.8 kohms,1/6W
RD7 VRD-ST2CD123J J AA 12 kohms,1/6W
RD8 VRD-ST2CD223J J AA 22 kohms,1/6W
RD9 VRD-MN2BD103J J 10 kohms,1/8W
RD10 VRD-ST2CD683J J AA 68 kohms,1/6W
RD11 VRD-MN2BD333J J 33 kohms,1/8W
RD12 VRD-MN2BD104K J 100 kohm,1/8W
RD13 VRD-ST2CD821J J AA 820 ohms,1/6W
RD14 VRD-ST2CD122J J AA 1.2 kohms,1/6W
RD15 VRD-ST2CD152J J AA 1.5 kohms,1/6W
RD16 VRD-ST2CD182J J AA 1.8 kohms,1/6W
RD17 VRD-ST2CD222J J AA 2.2 kohms,1/6W
RD18 VRD-ST2CD821J J AA 820 ohms,1/6W
RD19 VRD-ST2CD122J J AA 1.2 kohms,1/6W
RD20 VRD-ST2CD152J J AA 1.5 kohms,1/6W
RD21 VRD-ST2CD182J J AA 1.8 kohms,1/6W
RD22 VRD-ST2CD222J J AA 2.2 kohms,1/6W
RD23 VRD-ST2CD332J J AA 3.3 kohms,1/6W
RD24 VRD-ST2CD392J J AA 3.9 kohms,1/6W
RD25 VRD-ST2CD682J J AA 6.8 kohms,1/6W
RD26 VRD-ST2CD123J J AA 12 kohms,1/6W
