Sharp CD-PC3500

NO.
PRICE
RANK
DESCRIPTIONPARTS CODE
NO. PARTS CODE
PRICE
RANK
DESCRIPTION
CD-PC3500
SW714 92LSWICH1401AT J AC Switch,Key Type [DIMMER]
SW715 92LSWICH1401AT J AC Switch,Key Type [X-BASS]
SW716 92LSWICH1401AT J AC Switch,Key Type [EQUAL]
SW717 92LSWICH1401AT J AC Switch,Key Type [NORMAL]
SW718 92LSWICH1401AT J AC Switch,Key Type [PHANTOM]
SW719 92LSWICH1401AT J AC Switch,Key Type [BY-PASS]
SW720 92LSWICH1401AT J AC Switch,Key Type [POWER]
SW721 92LSWICH1401AT J AC Switch,Key Type [CLOCK]
SW722 92LSWICH1401AT J AC Switch,Key Type [TIMER]
SW728 92LSWICH1401AT J AC Switch,Key Type [DISC 1]
SW729 92LSWICH1401AT J AC Switch,Key Type [DISC 2]
SW730 92LSWICH1401AT J AC Switch,Key Type [DISC 3]
SW731 92LSWICH1401AT J AC Switch,Key Type [DISC SKIP]
SW732 92LSWICH1401AT J AC Switch,Key Type [OPEN/CLOS]
CD MECHANISM PARTS
301 NGERH0011AWZZ J AC Gear,Middle
302 NGERH0012AWZZ J AC Gear,Drive
303 MLEVP0080AWZZ J AC Rail,Guide
304 NSFTM0020AWFW J AD Shaft,Guide
305 92LM-CUSN1524A J AC Cushion
! 306 92LHPC1LXASY J BD Pickup Unit Ass’y
306- 1 ———— — Pickup Unit
(Not Replacement Item)
306- 2 NGERR0043AFZZ J AC Gear,Rack
306- 3 MSPRC0961AFZZ J AA Spring,Rack
701 XBSSD26P06000 J AA Screw,ø2.6×6mm
702 XHBSD20P05000 J AA Screw,ø2×5mm
703 XBBSD20P03000 J AA Screw,ø2×3mm
704 LX-WZ1070AFZZ J AA Washer,ø1.5×ø3.8×0.25mm
M1 92LMTR2790CASY J BB Motor with Chassis [Spindle]
M2 92LMTR1854BASY J AP Motor with Gear [Sled]
SW4 QSW-F9001AW01 J AD Switch,Leaf Type [Pickup In]
CABINET PARTS
201 92LCAB3306AASY J Front Cabinet Ass’y
201- 1 ———— — Front Panel
(Not Replacement Item)
201- 2 GDORF0074AWSA J AE Holder,Cassette,Tape 1
201- 3 GDORF0075AWSA J AE Holder,Cassette,Tape 2
201- 4 GCOVA1251AWSA J AH Cover,Cassette,Tape 1
201- 5 GCOVA1252AWSA J AH Cover,Cassette,Tape 2
201- 6 HDECQ0521AWSA J AD Panel,Cassette,Tape 1
201- 7 HDECQ0522AWSA J AD Panel,Cassette,Tape 2
201- 8 HDECQ0539AWSA J AK Panel,Amp.
201- 9 HDECQ0524AWSA J AG Decoration Plate
201-10 JKNBZ0655AWSA J AF Knob,Disc Control
201-11 JKNBZ0656AWSA J AG Knob,Center Operation
201-12 JKNBZ0657AWSA J AF Knob,Power/Clock
201-13 JKNBZ0672AWSA J AF Knob,Function,A
201-14 JKNBZ0673AWSA J AF Knob,Function,B
201-15 JKNBZ0660AWSA J AF Knob,Tuning
201-16 JKNBZ0661AWSA J AE Knob,Dimmer
201-17 HDECQ0526AWSA J AC Volume Light Up Ring
201-19 GCOVA1257AWSA J AB Cover,LED,Play/Stop
201-20 GCOVA1256AWSA J AB Cover,LED,Preset
201-21 MLIFP0008AWZZ J AD Damper
201-22 MSPRD0092AWFJ J AB Spring,Cassette,Tape 1
201-23 MSPRD0093AWFJ J AB Spring,Cassette,Tape 2
201-24 92LBADGE1671A J AC Badge,SHARP
201-25 JKNBZ0663AWSA J AE Knob,Dolby
201-26 GCOVA1258AWSA J LED,Power Top
201-27 GCOVA1265AWSA J LED,Function Top A
201-28 GCOVA1266AWSA J LED,Function Top B
201-29 GCOVA1267AWSA J LED,Function Top C
201-30 GCOVA1268AWSA J LED,Function Top D
202 92LCAB3303BASY J Side Panel Ass’y,Left
202- 1 ———— — Side Panel,Left
(Not Replacement Item)
202- 2 PCUSG0022AWZZ J AB Cushion,Leg
203 92LCAB3303CASY J Side Panel Ass’y,Right
203- 1 ———— — Side Panel,Right
(Not Replacement Item)
203- 2 PCUSG0022AWZZ J AB Cushion,Leg
204 92LCOV3303AASY J CD Tray Cover Ass’y
204- 1 ———— — Cover,CD Tray
(Not Replacement Item)
204- 2 GCOVA1254AWSA J AE Cover,CD Tray Panel,Left
204- 3 GCOVA1255AWSA J AE Cover,CD Tray Panel,Right
– 6 –
205 GCAB-1184AWSA J AP Top Cabinet
206 GITAR0543AWSA J AN Rear Panel
[For U.S.A./Central America]
206 GITAR0544AWSA J Rear Panel [For Mexico]
206 GITAR0545AWSA J Rear Panel [For Canada]
207 JKNBK0072AWSA J AE Knob,Volume
208 LANGK0110AWFW1J AD Bracket,Cassette Lock,Tape 1
209 LANGK0111AWFW1J AD Bracket,Cassette Lock,Tape 2
210 LANGK0188AWFW J AF Bracket,Fan Support
211 LANGT0042AWFW J AC Bracket,PWB Support
212 LBSHC0005AWZZ J AD Bushing,AC Power Supply Cord
213 LCHSM0096AWFW J AR Main Chassis
214 LHLDZ1242AWZZ J AE Holder,FL Display
215 LHLDZ1243AWZZ J AC Holder,LED,A
219 MLOKC0003AWZZ J AD Lock Lever,Cassette,Tape 1
220 MLOKC0004AWZZ J AD Lock Lever,Cassette,Tape 2
221 MSPRD0109AWFJ J AB Spring,Cassette Lock,Tape 1
222 MSPRD0110AWFJ J AB Spring,Cassette Lock,Tape 2
223 NFANP0001AWZZ J AD Rotary Fan
224 92LPT0331105 J AM Turntable
225 PCUSG0022AWZZ J AB Cushion,Leg
226 PRDAR0149AWFW J AP Heat Sink,Main
227 PRDAR0150AWFW J AS Heat Sink,Sub,A
228 PRDAR0151AWFW J AG Heat Sink,Sub,B
! 229 QACCD0022AWZZ J AM AC Power Supply Cord
230 QCNWN1615AWZZ J AC Lug Wire
! 231 QFSHD0001AWZZ J AB Holder,Fuse
232 92LBE231616 J Belt
233 92LCSPR1431C J AA Spring,Ring
234 92LEVA0330702 J Velvet Carpet,Cushion
235 92LMAG0104302 J Magnet
237 92LNBAND1318A J AA Nylon Band,80mm
238 92LNM0305401 J Velvet Carpet
239 92LPT0303002 J AB Roller
240 92LPT0304303 J AB Lever,Stop
241 92LPT0304304 J Stopper
242 92LPT0304305 J AE Lever,Lock
243 92LPT0304306 J Stabilizer
244 92LPT0304307 J AC Support,Cam
245 92LPT0304308 J Lock Gear Pin
246 92LPT0304309 J Cap,Pulley Stopper
247 92LPT0305413 J Cam Gear Lower
248 92LPT0309506 J AD Gear,Turntable Drive
249 92LPT0309507 J AD Gear,Open/Close Drive
250 92LPT0309508 J AD Gear,Planet
251 92LPT0309509 J AD Gear,Drive
252 92LPT0309510 J AE Gear,Pulley
253 92LPT0309511 J AD Gear,Middle
254 92LPT0311101 J AB Lever,Clamp
255 92LPT0311102 J AC Lever,Disc
256 92LPT0312005 J Gear,Cam
257 92LPT0320201 J AE Support,Stabilizer
258 92LPT0330301 J AU Chassie
259 92LPT0330803 J AK CD,Chassis
260 92LPT0331003 J AT Holder,Slide
262 92LSP0304303 J Spring,Stopper
263 92LSP0304305 J AB Spring,Lock Lever
264 92LSP0304306 J Spring,Lock Gear
265 KMECB0011AWZZ J BH Tape Mechanism Ass’y
266 92LMT0304302 J Metal Plate
267 LANGK0189AWFW J AC Support Bracket,
Sub Heat Sink A
268 LHLDZ1244AWZZ J Holder,LED Dolby
269 LHLDZ1247AWZZ J Holder,LED Function
270 GCOVA1264AWZZ J Volume,Reflector A
271 PSHEP0037AWZZ J Sheet, Reflector A
601 XBBSD20P04000 J AA Screw,ø2×4mm
604 XEBSF30P12000 J AA Screw,ø3×12mm
605 XESSD30P10000 J AA Screw,ø3×10mm
606 XHBSD26P04000 J AA Screw,ø2.6×4mm
607 XHBSD30P06000 J AA Screw,ø3×6mm
608 XJBSD30P10000 J AA Screw,ø3×10mm
609 XJBSD30P14000 J AA Screw,ø3×14mm
612 LX-BZ2222AXZZ J Screw,Special
613 LX-HZ0082AFZZ J AA Screw,ø4×8mm
614 LX-JZ0010AFFD J AA Screw,ø3×10mm
616 92LSC0308RBZZ J Screw,ø3×8mm
