– 5 –
CD-XP200/CD-XP2200
CD-XP200/CD-XP2200
1. Tweeter
2. Woofer
3. Bass Reflex Duct
4. Speaker Wire
1
3
3
4
2
Remote control
1. Remote Control Transmitter
2. Power On/Stand-by Button
3. Disc Number Select Buttons
4. CD Random Button
5. CD Memory Button
6. Tape 2 Record Pause Button
7. CD Track Down or Fast Reverse, Tape 2 Rewind Button
8. CD or Tape Stop Button
9. Tuner (Band) Button
10. CD Button
11. Video/Auxiliary Button
12. Extra Bass Button
13. Equalizer Mode Select Button
14. CD Clear Button
15. Tuner Preset Up and Down Buttons
16. CD Pause Button
17. CD Track Up or Fast Forward, Tape 2 Fast Forward Button
18. CD Play or Repeat, Tape Play Button
19. Tape (1 2) Button
20. Volume Up and Down Buttons
1
2
3
4
5
6
7
8
9
10
11
12
15
16
17
18
19
13
14
20
Buttons with " " mark in the illustration can be operated on the remote control
only.
Other buttons can be operated both on the main unit and the remote control.
CP-XP200/CP-XP2200
