Sharp CD-XP500

PRICE
RANK
DESCRIPTION
NO.
PART CODE
NO. PARTS CODE
PRICE
RANK
DESCRIPTION
CD-XP500/CD-XP5500
CABINET PARTS
201 92LCAB3857AASY J Front Panel Ass’y [CD-XP500]
201 92LCAB3858AASY J Front Panel Ass’y [CD-XP5500]
201- 1 ———— — Front Panel
(Not Replacement Item)
201- 2 GCOVA1417AWSA J AH Cover,Cassette [Tape 1]
[CD-XP500]
201- 2 GCOVA1417AWSB J AG Cover,Cassette [Tape 1]
[CD-XP5500]
201- 3 GCOVA1418AWSA J AH Cover,Cassette [Tape 2]
[CD-XP500]
201- 3 GCOVA1418AWSB J AG Cover,Cassette [Tape 2]
[CD-XP5500]
201- 4 GCOVA1421AWSA J AC Cover,Remote Sensor
201- 5 GCOVA1422AWSA J AB Cover,LED,Timer
201- 6 GDORF0112AWSA J AE Holder,Cassette [Tape 1]
201- 7 GDORF0113AWSA J AE Holder,Cassette [Tape 2]
201- 8 HDECQ0834AWSA J AE Panel,Cassette [Tape 1]
[CD-XP500]
201- 8 HDECQ0834AWSB J AE Panel,Cassette [Tape 1]
[CD-XP5500]
201- 9 HDECQ0835AWSA J AE Panel,Cassette [Tape 2]
[CD-XP500]
201- 9 HDECQ0835AWSB J AE Panel,Cassette [Tape 2]
[CD-XP5500]
201-10 HDECQ0846AWSA J AL Panel,Amp. [CD-XP500]
201-10 HDECQ0860AWSA J AL Panel,Amp. [CD-XP5500]
201-11 HDECQ0844AWSC J AE Ring,Play/Stop
201-12 JKNBZ0879AWSA J AG Button,Open/Close [CD-XP500]
201-12 JKNBZ0879AWSB J AG Button,Open/Close [CD-XP5500]
201-13 JKNBZ0876AWSA J AD Button,X-Bass/Equalizer
[CD-XP500]
201-13 JKNBZ0876AWSB J AD Button,X-Bass/Equalizer
[CD-XP5500]
201-14 JKNBZ0865AWSA J AD Button,Function [CD-XP500]
201-14 JKNBZ0865AWSB J AD Button,Function [CD-XP5500]
201-15 JKNBZ0866AWSA J AF Button,Power [CD-XP500]
201-15 JKNBZ0866AWSB J AE Button,Power [CD-XP5500]
201-16 MLIFP0008AWZZ J AD Damper
201-17 MSPRD0151AWFJ J AB Spring,Cassette [Tape 1]
201-18 MSPRD0152AWFJ J AB Spring,Cassette [Tape 2]
202 92LCAB3838BASY J Side Panel Ass’y,Left
[CD-XP500]
202 92LCAB3839BASY J Side Panel Ass’y,Left
[CD-XP5500]
202- 1 ———— — Side Panel,Left
(Not Replacement Item)
202- 2 PCUSG0022AWZZ J AB Cushion,Leg
203 92LCAB3838CASY J Side Panel Ass’y,Right
[CD-XP500]
203 92LCAB3839CASY J Side Panel Ass’y,Right
[CD-XP5500]
203- 1 ———— — Side Panel,Right
(Not Replacement Item)
203- 2 PCUSG0022AWZZ J AB Cushion,Leg
204 GCAB-1197AWZZ J AM Loading Tray
205 GCAB-1215AWSA J AT Top Cabinet [CD-XP500]
205 GCAB-1215AWSB J AR Top Cabinet [CD-XP5500]
206 GCOVA1416AWSC J AM Cover,CD Tray [CD-XP500]
206 GCOVA1416AWSD J AM Cover,CD Tray [CD-XP5500]
207 GITAR0947AWSA J AN Rear Panel
[CD-XP500 Except for Canada]
207 GITAR0948AWSA J Rear Panel
[CD-XP500 for Canada]
207 GITAR0992AWSA J AN Rear Panel [CD-XP5500]
208 KMECB0024AWZZ J BF Tape Mechanism Ass’y
208- 1 92PF513-853 J BL Head Plate Block [Tape 2]
208- 2 92PF525-336 J BE Motor with Pulley [Tape]
208- 3 92PF567-677 J — Tape Mechanism PWB Ass’y
208- 4 92PFF19N-21 J AL Belt,Main [Tape 2]
208- 5 92PF514-133 J AL Pinch Roller
208- 6 92PF19S-31 J AL Belt,FF/REW [Tape 2]
208- 7 92PFF19N-11 J AL Belt,Main [Tape 1]
208- 8 92PF522-061 J AZ Clutch Ass’y Block [Tape 1]
208- 9 92PFF19S-52 J AL Belt,FF/REW [Tape 1]
208-10 92PF513-861 J AG Head Plate Block [Tape 1]
208-11 92PF522-063 J AZ Clutch Ass’y Block [Tape 2]
208-12 92PFD60F-11 J AK Cam Gear [Tape 1]
208-13 92PFR26C-11 J AN Flywheel [Tape 1]
208-14 92PFR26D-11 J AN Flywheel [Tape 2]
208-15 92PF765-292 J AS Solenoid Ass’y
208-16 92PFD58M-14 J AK Cam Gear [Tape 2]
209 LANGK0110AWFW J AE Bracket,Cassette Lock,Tape 1
210 LANGK0111AWFW J AE Bracket,Cassette Lock,Tape 2
211 LANGK0317AWFW J AF Bracket,Fan Support
212 LBSHC0005AWZZ J AD Bushing,AC Power Supply Cord
213 LCHSM0153AWFW J AQ Chassis,Main
214 LCHSM0155AWZZ J AS Chassis,Loading
215 LHLDM1018AWZZ J AE Stabilizer
216 LHLDZ1357AWZZ J AH Holder,CD Mechanism
217 LHLDZ1358AWZZ J AF Holder,Stabilizer
218 LHLDZ1359AWZZ J AD Holder,Gear
219 LHLDZ1410AWZZ J AD Holder,FL Display
220 LHLDZ1412AWZZ J AC Holder,LED
221 MCAMP0010AWZZ J AE Gear,Can Upper
222 MCAMP0011AWZZ J AE Gear,Can Lower
223 MLEVP0109AWZZ J AB Lever,Cam Lock
224 MLEVP0110AWZZ J AB Lever,Switch A
225 MLEVP0111AWZZ J AB Lever,Switch B
226 MLEVP0112AWZZ J AB Turntable Actuator
227 MLOKC0003AWZZ J AD Lock Lever,Cassette,Tape 1
228 MLOKC0004AWZZ J AD Lock Lever,Cassette,Tape 2
229 MSPRC0033AWFJ J AB Spring,Friction
230 MSPRD0109AWFJ J AB Spring,Cassette Lock,Tape 1
231 MSPRD0110AWFJ J AB Spring,Cassette Lock,Tape 2
232 MSPRP0057AWFW J AC Spring,Tray Lock
233 MSPRP0068AWFW J AB Spring,Motor Gear
234 NFANP0001AWZZ J AD Rotary Fan
235 NGERH0152AWZZ J AC Gear,Turntable Drive
236 NGERH0153AWZZ J AC Gear,Drive
237 NGERW0020AWZZ J AC Gear,Center
238 NGERW0021AWZZ J AC Gear,Idler
239 NGERW0022AWZZ J AD Gear,Worm
240 NGERW0023AWZZ J AC Gear,Motor
241 NTNT-0022AWZZ J AK Turntable
242 PCUSG0022AWZZ J AB Cushion,Leg
243 PMAGF0001AWZZ J AF Magnet
244 PRDAR0236AWFW J AX Heat Sink
1 245 QACCD0022AWZZ J AM AC Power Supply Cord
246 QCNWN1860AWZZ J AC Lug Wire
1 247 QFSHD0001AWZZ J AB Holder,Fuse
248 92LCSPR1431C J AA Spring,Ring
249 92LMT0304302 J AB Plate,Metal
250 92LNBAND1318A J AA Nylon Band,80mm
251 92LPT0303002 J AB Roller
254 HDECQ0837AWSA J AF Light Panel
255 LHLDZ1411AWZZ J AE Holder,Light Panel
256 GCOVA1419AWSA J AC Light Cover,Right
257 GCOVA1420AWSA J AC Light Cover,Left
258 PSHEP0086AWZZ J AE Light Sheet
259 LHLDZ1417AWZZ J AE Block,Button
260 JKNBK0092AWSA J AL Knob,Volume
261 LANGK0327AWFW J AF Bracket,Heat Sink
262 KNOB3857AASY1 J Operation Button Ass’y
[CD-XP500]
262 KNOB3858AASY1 J Operation Button Ass’y
[CD-XP5500]
262- 1 JKNBZ0878AWSA J AH Button,Operation [CD-XP500]
262- 1 JKNBZ0878AWSB J AH Button,Operation [CD-XP5500]
262- 2 GCOVA1434AWSA J AD Cover,LED,Play
262- 3 GCOVA1435AWSA J AD Cover,LED,Stop
263 LHLDZ1418AWZZ J AC Holder,LED
601 LX-BZ0082AWFC J Screw,Transport
602 LX-EZ0010AWFD J AA Screw,Special
603 LX-HZ0009AWFD J AC Screw,ø2×13mm
604 LX-JZ0010AFFD J AA Screw,ø3×10mm
605 XBBSD20P04000 J AA Screw,ø2×4mm
606 XEBSD26P08000 J AA Screw,ø2.6×8mm
608 XEBSD30P10000 J AA Screw,ø3×10mm
609 XEBSD30P12000 J AA Screw,ø3×12mm
610 XESSD30P10000 J AA Screw,ø3×10mm
611 XHBSD26P04000 J AA Screw,ø2.6×4mm
612 XHBSD40P06000 J AA Screw,ø4×6mm
613 XJBSD20P05000 J AA Screw,ø2×5mm
614 XJBSD30P10000 J AA Screw,ø3×10mm
615 XJBSD30P12000 J AA Screw,ø3×12mm
618 XJSSD30P10000 J AA Screw,ø3×10mm
619 92LSC0310RBZI J AB Screw,ø3×10mm
620 92LSC0314WBZI J AB Screw,ø3×14mm
622 XHBSD30P06000 J AA Screw,ø3×6mm
623 XJBSD30P14000 J AA Screw,ø3×14mm
– 5 –
