Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
33
32L-S400, 36L-S400
CL32S40, CL36S40
C253 VCCCCY1HH470J J 47p 50V Ceramic AA
C301 VCCCCY1HH330J J 33p 50V Ceramic AA
C302 VCCCCY1HH151J J 150p 50V Ceramic AA
C303 VCCCCY1HH390J J 39p 50V Ceramic AA
C307 VCCCCY1HH1R5C J 1.5p 50V Ceramic AD
C308 VCKYCY1HB102K J 1000p 50V Ceramic AA
C309 VCEA0A1CW337M J 330 16V EL. AC
C312 VCEA0A1CW476M J 47 16V EL. AB
C360 VCEA0A1HW225M J 2.2 50V EL. AB
C361 VCEA0A1HW225M J 2.2 50V EL. AB
C364 VCEA0A1EW107M J 100 25V EL. AC
C365 VCEA0A0JW107M J 100 6.3V EL. AB
C368 VCEA0A1CW477M J 470 16V EL. AC
C369 VCEA0A1CW477M J 470 16V EL. AC
C370 VCEA0A0JW107M J 100 6.3V EL. AB
C371 RC-QZA104TAYK J 0.1 50V Mylar AB
C372 RC-QZA104TAYK J 0.1 50V Mylar AB
C380 RC-QZA103TAYK J 0.01 50V Mylar AA
C381 RC-QZA103TAYK J 0.01 50V Mylar AA
C401 VCKYCY1HB331K J 330p 50V Ceramic AA
C402 VCCCCY1HH101J J 100p 50V Ceramic AA
C403 VCKYCY1CB104K J 0.1 16V Ceramic AB
C404 VCEA0A1CW107M J 100 16V EL. AC
C405 VCEA0A1HW335M J 3.3 50V EL. AB
C406 VCEA0A1HW225M J 2.2 50V EL. AB
C408 VCEA0A1HW106M J 10 50V EL. AB
C409 VCEA0A1HW335M J 3.3 50V EL. AB
C410 VCKYCY1CB104K J 0.1 16V Ceramic AB
C411 VCEA0A1CW337M J 330 16V EL. AC
C412 VCKYCY1HB103K J 0.01 50V Ceramic AA
C413 VCKYCY1HB103K J 0.01 50V Ceramic AA
C414 VCKYCY1HB103K J 0.01 50V Ceramic AA
C422 VCEA0A1CW476M J 47 16V EL. AB
C451 RC-QZA104TAYK J 0.1 50V Mylar AB
C452 VCEA0A1HW475M J 4.7 50V EL. AB
C453 VCEA0A1CW226M J 22 16V EL. AB
C471 VCKYCY1HB103K J 0.01 50V Ceramic AA
C472 VCEA0A1HW106M J 10 50V EL. AB
C473 VCEA0A1CW106M J 10 16V EL. AB
C474 VCEA0A1CW106M J 10 16V EL. AB
C476 VCKYCY1HB103K J 0.01 50V Ceramic AA
C477 VCE9GA1CW106M J 10 16V EL.(N.P) AB
C478 VCKYCY1HB103K J 0.01 50V Ceramic AA
C501 VCKYPA2HB102K J 1000p 500V Ceramic AA
C502 VCEA0A1VW337M J 330 35V EL. AD
C509 VCCSPA1HL101J J 100p 50V Ceramic AA
C510 VCFYSA1JA564J J 0.56 63V Mylar AE
C511 VCKYPA2HB391K J 390p 500V Ceramic AA
C512 RC-QZA683TAYJ J 0.068 50V Mylar AB
C513 RC-QZA103TAYK J 0.01 50V Mylar AA
C514 VCEA0A1VW107M J 100 35V EL. AC
C515 VCEACA1HC225J J 2.2 50V EL. AC
C516 VCEACA1HC105J J 1.0 50V EL. AB
C517 VCEA0A1VW108M J 1000 35V EL. AD
C518 VCFYSA1JA473J J 0.047 63V Mylar AC
C519 VCEA0A1HW105M J 1.0 50V EL. AB
C551 VCSATA1CE225K J 2.2 16V Tantalum AB
C552 VCEA0A1HW225M J 2.2 50V EL. AB
C553 VCKYCY1HB102K J 1000p 50V Ceramic AA
C605 VCKYPA1HB102K J 1000p 50V Ceramic AA
C606 VCKYPA2HB561K J 560p 500V Ceramic AA
C607 VCKYPA1HB472K J 4700p 50V Ceramic AA
C608 VCKYPH3DB271K J 270p 2000V Ceramic AC
(36L-S400, CL36S40)
C608 RC-KZ0033CEZZ J 150p 2kV Ceramic AB
(32L-S400, CL32S40)
C609 VCFPVC3CA822H J 8200p 1.6kV M-Poly. AE
(36L-S400, CL36S40)
C609 VCFPVC3CA912H J 9100p 1.6kV M-Poly. AE
(32L-S400, CL32S40)
C610 VCFPVC3CA912H J 9100p 1.6kV M-Poly. AE
C615 VCKYPA2HB272K J 2700p 500V Ceramic AA
C622 VCKYPA2HB102K J 1000p 500V Ceramic AA
C623 VCEA0A2CW336M J 33 160V EL. AE
C631 VCEA0A1HW335M J 3.3 50V EL. AB
C632 RC-QZA103TAYK J 0.01 50V Mylar AA
PWB-A: DUNTK9829WEK0 (32L-S400, CL32S40)
PWB-A: DUNTK9829WEK1 (36L-S400, CL36S40)
MAIN UNIT (Continued)
X801 RCRSB0205CEZZ J Crystal AF
or
RCRSB0001PEZZ
FILTERS
CF301 RFiLC0267CEZZ J Ceramic Filter AD
CF302 RFiLC0029TAZZ J Ceramic Filter AD
CF401 RFiLC0013CEZZ J Ceramic Filter AE
CF631 RFiLA0034CEZZ J Ceramic Filter AD
CF2040 RFiLC0121GEZZ J Ceramic Filter AD
SF201 RFiLC0405CEZZ J S.A.W. Filter AH
COILS
L201 VP-XF1R2K0000 J Peaking 1.2µH AB
L202 RCiLi0588CEZZ J VCO Coil AF
L251 VP-XF390K0000 J Peaking 39µH AB
L301 VP-XF8R2K0000 J Peaking 8.2µH AB
L302 RCiLi0613CEZZ J IF Coil AE
L401 VP-XF6R8K0000 J Peaking 6.8µH AB
L402 VP-XF3R3K0000 J Peaking 3.3µH AB
L403 VP-XF8R2K0000 J Peaking 8.2µH AB
L404 VP-XF8R2K0000 J Peaking 8.2µH AB
L631 VP-XF150K0000 J Peaking 15µH AB
L671 RCiLZ1005CEZZ J Coil AH
L672 RCiLZ0789CEZZ J Coil AK
å L701 RCiLF0273CEZZ J Line Filter AM
å L702 RCiLF0025PEZZ R Line Filter AK
or
RCiLF0273PEZZ
L705 RCiLP0179CEZZ J Coil AD
L729 RCiLP0179CEZZ J Coil AD
L1401 VP-XF100K0000 J Peaking 10µH AB
L1402 VP-XF100K0000 J Peaking 10µH AB
L1403 VP-XF150K0000 J Peaking 15µH AB
L1405 VP-XF330K0000 J Peaking 33µH AB
L2040 RCiLB0159CEZZ J Oscillation Coil AE
TRANSFORMERS
å T601 RTRNZ0057PEZZ R Transformer AK
çå T602 RTRNF0040MEZZ M H-Volt Transformer
(36L-S400, CL36S40)
çå T602 RTRNF0035MEZZ M H-Volt Transformer
(32L-S400, CL32S40)
å T701 RTRNP0543CEZZ J Power Transformer AM
å T702 RTRNZ0018MEZZ M Transformer
CONTROLS
R502 RVR-M4334CEZZ J 10k (B) V-Lin AC
R676 RVR-M4334CEZZ J 10k (B) H-Lin AC
R678 RVR-M4336CEZZ J 22k (B) H-Size AC
CAPACIORS
[EL.··· Electrolytic, M-Poly.··· Metalized Polypro Film]
C51 VCEA0A1CW476M J 47 16V EL. AB
C53 VCEA0A1HW105M J 1.0 50V EL. AB
C54 VCEA0A1HW475M J 4.7 50V EL. AB
C55 VCEA0A1CW108M J 1000 16V EL. AD
C103 VCEA0A1CW228M J 2200 16V EL. AD
C201 VCKYCY1HB102K J 1000p 50V Ceramic AA
C202 VCKYCY1HF103Z J 0.01 50V Ceramic AA
C203 VCKYCY1HB102K J 1000p 50V Ceramic AA
C204 VCKYCY1HF103Z J 0.01 50V Ceramic AA
C205 VCEA0A1HW474M J 0.47 50V EL. AB
C206 VCEA0A1CW337M J 330 16V EL. AC
C207 VCKYCY1HF103Z J 0.01 50V Ceramic AA
C208 VCEA0A1HW474M J 0.47 50V EL. AB
C209 VCKYCY1HB222K J 2200p 50V Ceramic AA
C210 VCKYCY1HB102K J 1000p 50V Ceramic AA
C251 VCKYCY1HB103K J 0.01 50V Ceramic AA
C252 VCKYCY1HB103K J 0.01 50V Ceramic AA
