Sharp CL32S40 - Main Unit

Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
32
32L-S400, 36L-S400
CL32S40, CL36S40
PWB-A: DUNTK9829WEK0 (32L-S400, CL32S40)
PWB-A: DUNTK9829WEK1 (36L-S400, CL36S40)
MAIN UNIT
Q1402 VS2SD601AR/-1 J 2SD601AR AC
Q1403 VS2SD601AR/-1 J 2SD601AR AC
Q1404 VS2SD601AR/-1 J 2SD601AR AC
Q1405 VS2SD601AR/-1 J 2SD601AR AC
Q1406 VS2SD601AR/-1 J 2SD601AR AC
Q1407 VS2SD601AR/-1 J 2SD601AR AC
Q1601 VS2SD601AR/-1 J 2SD601AR AC
Q1602 VS2SB709AR/-1 J 2SB709AR AC
Q2060 VS2SD601AR/-1 J 2SD601AR AC
Q2201 VS2SD601AR/-1 J 2SD601AR AC
Q2211 VS2SD601AR/-1 J 2SD601AR AC
DIODES
D51 RH-EX0611GEZZ J Zener Diode AA
D52 RH-EX0676GEZZ J Zener Diode AA
D53 RH-EX0611GEZZ J Zener Diode AA
D103 VHD1SS119//-1 J Diode AB
D401 VHD1SS119//-1 J Diode AB
D402 RH-EX0723GEZZ J Zener Diode AB
D403 RH-EX0611GEZZ J Zener Diode AA
D404 RH-EX0611GEZZ J Zener Diode AA
D405 RH-EX0611GEZZ J Zener Diode AA
D454 RH-EX0611GEZZ J Zener Diode AA
D455 VHD1SS119//-1 J Diode AB
D481 VHD1SS119//-1 J Diode AB
D482 VHD1SS119//-1 J Diode AB
å D501 RH-DX0302CEZZ J Diode AC
D510 RH-DX0441CEZZ J Diode AC
D511 RH-EX0654CEZZ J Zener Diode AD
å D605 RH-DX0255CEZZ J Diode AC
D621 RH-EX0631GEZZ J Zener Diode AA
D622 RH-DX0131CEZZ J Diode AC
çå D651 RH-DX0073CEZZ J Diode AD
çå D652 RH-EX0641GEZZ J Zener Diode AA
çå D653 VHD1SS119//-1 J Diode AB
(32L-S400, CL32S40)
çå D654 VHD1SS119//-1 J Diode AB
(32L-S400, CL32S40)
D671 RH-EX0664GEZZ J Zener Diode AA
D672 VHD1SS119//-1 J Diode AB
å D673 RH-DX0229CEZZ J Diode AF
D674 VHD1SS119//-1 J Diode AB
D705 VHD1SS82///1A J Diode AC
D706 RH-DX0066GEZZ J Diode AB
D707 VHD1SS82///1A J Diode AC
D708 RH-DX0066GEZZ J Diode AB
D709 RH-DX0229CEZZ J Diode AF
å D710 RH-EX0673GEZZ J Zener Diode AB
å D712 RH-DX0407CEZZ J Diode AD
or
RH-DX0468CEZZ
å D713 RH-DX0259CEZZ J Diode AH
or
RH-DX0477CEZZ
D715 RH-EX0610GEZZ J Zener Diode AA
D716 VHD1SS119//-1 J Diode AB
D717 RH-EX0650GEZZ J Zener Diode AB
å D725 RH-DX0407CEZZ J Diode AD
or
RH-DX0468CEZZ
å D751 RH-DX0441CEZZ J Diode AC
å D752 RH-DX0441CEZZ J Diode AC
å D753 RH-DX0441CEZZ J Diode AC
å D754 RH-DX0441CEZZ J Diode AC
D755 VHD1SS119//-1 J Diode AB
D756 RH-DX0441CEZZ J Diode AC
D1401 VHD1SS119//-1 J Diode AB
D1402 VHD1SS119//-1 J Diode AB
D1403 VHD1SS119//-1 J Diode AB
D2011 RH-EX0611GEZZ J Zener Diode AA
å VA701 RH-VX0035CEZZ J Varistor AF
PACKAGED CIRCUITS
å PR701 RMPTP0059CEZZ J Packaged Circuit AH
TUNER
NOTE: THE PARTS HERES SHOWN ARE SUPPLIED AS AN
ASSEMBLY BUT NOT INDEPENEDENTLY.
å TU51 VTU115B8035AT M Tuner AU
or
VTU115B8025AM
TU51 R53 D53 C54 R57
115B8035AT
47
EX0611GE
4.7u 3.9k
(2W) (50V)
115B8025AM 1 —
2.2u 10k
(50V)
INTEGRATED CIRCUITS
IC101 VHiKA78S05P-1 J KA78S05P AD
çå IC201 RH-iX3253CEZZ J TA1268AN AV
å IC361 RH-iX1135CEZZ J LA4261 AH
IC470 VHiM52055FP-1 J M52055FP AH
å IC501 VHiTA8427K/-1 J TA8427K AL
or
RH-iX1224CEZZ
IC671 VHiUPC358C/-1 J UPC358C AD
çå IC701 VHiSTRF66261E J STRF6626 AX
å IC702 RH-FX0002GEZZ J PS2501-1 AD
å IC703 VHiSE135N//-1 J SE135N AG
(36L-S400, CL36S40)
å IC703 VHiSE125N//-1 M SE125N
(32L-S400, CL32S40)
å IC750 VHiKA7809Pi-1 R KA7809PI AE
IC751 VHiKA7809Pi-1 R KA7809PI AE
IC951 VHiMM1113XF1E J MM1113XFBE AE
IC1401 VHiTC90A45F-1 J TC90A45F AM
IC1402 VHiMM1111XF1E J MM1111XFBE AE
IC1403 VHiKA78L05B-1 J KA78L05BP AE
IC2001 RH-iX3256CEZZ J I.C.
IC2040 VHiKiA7045P-1 J KIA7045P AD
IC2101 VHiM24C01B/-1 J I.C.
IC3001 VHiCXA2074Q-1 J CXA2074Q AY
IC3201 VHiAN5285K/-1 J AN5285K AP
TRANSISTORS
You can subsitute "VS2SD601AR/-1" for "VS2SC2462-C-1".
Q201 VS2SC2735//1E J 2SC2735 AC
Q251 VS2SD601AR/-1 J 2SD601AR AC
Q252 VS2SD601AR/-1 J 2SD601AR AC
Q253 VS2SD601AR/-1 J 2SD601AR AC
Q301 VS2SD601AR/-1 J 2SD601AR AC
Q360 VS2SD601AR/-1 J 2SD601AR AC
Q401 VS2SD601AR/-1 J 2SD601AR AC
Q402 VS2SB709AR/-1 J 2SB709AR AC
Q403 VS2SD601AR/-1 J 2SD601AR AC
Q421 VS2SB709AR/-1 J 2SB709AR AC
Q451 VS2SA1266-Y-1 J 2SA1266 (Y) AA
Q601 VS2SC2482//-1 J 2SC2482 AD
å Q602 VS2SC5150//2E M 2SC5150
(36L-S400, CL36S40)
å Q602 VS2SD2500//2E J 2SD2500 AT
(32L-S400, CL32S40)
Q672 VS2SA1266-Y-1 J 2SA1266 (Y) AA
Q673 VS2SD2045//-1 J 2SD2045 AL
Q751 VS2SC3198-Y-1 J 2SC3198 (Y) AA
Q901 VS2SD601AR/-1 J 2SD601AR AC
Q902 VS2SD601AR/-1 J 2SD601AR AC
Q903 VS2SD601AR/-1 J 2SD601AR AC
Q904 VS2SD601AR/-1 J 2SD601AR AC
Q921 VS2SD601AR/-1 J 2SD601AR AC
Q922 VS2SD601AR/-1 J 2SD601AR AC
Q923 VS2SD601AR/-1 J 2SD601AR AC
Q924 VS2SD601AR/-1 J 2SD601AR AC
Q1401 VS2SD601AR/-1 J 2SD601AR AC
COMBI-
NATION
