Sharp CL32S40 - Control Unit

Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
40
32L-S400, 36L-S400
CL32S40, CL36S40
PWB-R: DUNTK9511WEK2
P-IN-P UNIT (Continued)
PWB-F: DUNTK9514WEK0
CONTROL UNIT
R1881 VRS-CY1JF473J J 47k 1/16W M-Ox. AA
R1882 VRS-CY1JF223J J 22k 1/16W M-Ox. AA
R1883 VRS-CY1JF123J J 12k 1/16W M-Ox. AA
R1884 VRS-CY1JF101J J 100 1/16W M-Ox. AA
R1885 VRS-CY1JF473J J 47k 1/16W M-Ox. AA
R1886 VRS-CY1JF223J J 22k 1/16W M-Ox. AA
R1887 VRS-CY1JF123J J 12k 1/16W M-Ox. AA
R1889 VRD-RA2BE101J J 100 1/8W Carbon AB
MISCELLANEOUS PARTS
P1701 QPLGZ0810CEZZ J Plug 8-pin AD
P1702 QPLGZ0610CEZZ J Plug 6-pin AB
P1703 QPLGZ0810CEZZ J Plug 8-pin AD
SLD1801 PSLDM0012MEFW M Shield AC
CAPACITOR
[EL.··· Electrolytic]
C4001 VCEA0A1HW475M J 4.7 50V EL. AB
RESISTORS
R4001 VRD-RA2BE103J J 10k 1/8W Carbon AA
R4003 VRD-RA2BE273J J 27k 1/8W Carbon AA
R4004 VRD-RA2BE563J J 56k 1/8W Carbon AA
R4005 VRD-RA2BE331J J 330 1/8W Carbon AA
R4006 VRD-RA2BE563J J 56k 1/8W Carbon AA
R4007 VRD-RA2BE123J J 12k 1/8W Carbon AA
R4008 VRD-RA2EE750J J 75 1/4W Carbon AA
R4009 VRD-RA2BE153J J 15k 1/8W Carbon AA
R4010 VRD-RA2BE272J J 2.7k 1/8W Carbon AA
SWITCHES
S4001 QSW-K0079GEZZ J Power AB
S4002 QSW-K0079GEZZ J CH-UP AB
S4003 QSW-K0079GEZZ J CH-DOWN AB
S4004 QSW-K0079GEZZ J VOL-UP AB
S4005 QSW-K0079GEZZ J VOL-DOWN AB
MISCELLANEOUS PARTS
J4001 QJAKE0179CEZZ M Audio In (L)
J4002 QJAKE0180CEZZ M Audio In (R)
J4003 QJAKE0181CEZZ M Video In
P4001 QPLGN0461CEZZ J 4-pin (YR) AB
P4003 QPLGN0661CEZZ J 6-pin (EJ) AD
RMC4001 RRMCU0230CEZZ M R/C Receiver
QCNW-0176MEZZ M Connecting Cord AE
QCNW-0179MEZZ M Connecting Cord AH
