9
32L-S400, 36L-S400
CL32S40, CL36S40
SERVICE
NUMBER
DATA
ADJUSTMENT ITEM
RANGE
INITIAL VALUE
S01 PICTURE 55 00-7F
S02 TINT 46 00-7F
S03 COLOR 32 00-7F
S04 BRIGHTNESS 40 00-7F
S05 SHARPNESS 28 00-3F Must be set to "24"
S06 Vert. PHASE 00 00-07 Must be set to "00"
S07 Hor. PHASE 12 00-1F
S08 RF AGC 23 00-3F
S09 Vert. AMPLITUDE 20 00-3F
S10 PIF VCO 2C 00-7F
S11 R CUT-OFF 00 00-FF
S12 G CUT -OFF 00 00-FF
S13 B CUT-OFF 00 00-FF
S14 G GAIN 7F 00-FF
S15 B GAIN 7F 00-FF
S16 TRAP 0 00,01 Must be set to "01"
S17 BALANCE 20 00-3F Must be set to "20"
S18 CC POSITION 17 00-7F
S19 MUTE 00 00,01,03
"00" : NORMAL, "01" : Y-MUTE, "03" : V-STOP & Y-MUTE
S20 ENERGY SAVE OFFSET 20 00-3F Must be set to "23"
S21 D.D.E. OFFSET 03 00-1F Must be set to "03"
S22 OSD SETUP 00 00-03 Must be set to "00"
S23 TUNER SETUP 00 00,01 Must be set to "00"
OP OPTION 30 00-FF Must be set to "FE"
M01 INPUT LEVEL 0A 00-0F
M02 ST VCO 20 00-3F
M03 FILTER 1C 00-3F
M04 WIDE BAND 20 00-3F
M05 SPECTRAL 1B 00-3F
P01 PIP Y-LEVEL 30 00-7F
P02 PIP TINT 29 00-3F Must be set to "29"
P03 PIP COLOR 2E 00-7F
P04 PIP Y-OFFSET 09 00-1F Must be set to "09"
P05 PIP H-POSI. 0A 00-FF Must be set to "0A"
P06 PIP BGPM 00 00-0F Must be set to "00"
P07 PP FREERUN 0B 00-0F Must be set to "0B"
NECESSARY
UNNECESSARY
ADJUSTMENT
PART REPLACED
IC2001
IC2101
X
IC3001 X
CRT X
IC201 X
X
IC1801
Data is stored in IC2101.
The adjustment is needed to compensate for characteristics
of parts including IC201 and MTS level (M01).
Holding down both the CH-up/down bottons on the TV set in
the service mode for more than 2 seconds will automatically
write the above initial values into IC2101. Then perform a
complete adjustment.
Adjust items related to picture tube only.
Adjust items related to MTS only (M01~M05).
Holding down both the CH-up/down buttons on the TV set at service mode for more than 2 seconds will automatically
write the above initial values into IC2101.
Adjust items related to P-IN-P only (P01~P07).
X
Table - B
Table - A
ADJUSTMENT CONTENTS
NOTES
To Next Page
