Sharp GX-CH170X User Manual

PRICE
RANK
DESCRIPTIONNO. PART CODE NO. PARTS CODE
PRICE
RANK
DESCRIPTION
GX-CH170X/CH170Z
– 1 –
FILTERS
CF2 92LFILT-F1342A J AD FM IF
CF3 RFILA0006AWZZ J AG AM IF [X]
CF3 RFILA0007AWZZ J AG AM IF [Z]
F1 92LFILTF1759AT J AD FM Band Pass Filter
TRANSFORMERS
T1 RCILI0007AWZZ J AD FM IF
[SERIAL No.60500001~
607×××××]
T1 RCILI0012AWZZ J FM IF [SERIAL No.608×××××~]
T2 RCILI0008AWZZ J AF FM Detection
[SERIAL No.60500001~
607×××××]
T2 RCILI0013AWZZ J FM Detection
[SERIAL No.608×××××~]
T3 RCILI0010AWZZ J AF AM IF [Z]
T3 RCILI0014AWZZ J AE AM IF [X]
T651 RTRNP0091AWZZ J AZ Power
COILS
L1 RCILR0364AFZZ J AA FM RF
L2 RCILB0020AWZZ J AA FM Oscillation [X]
L2 RCILB0628AFZZ J AC FM Oscillation [Z]
L3 RCILA0048AWZZ J MW/SW1 Bar Antenna [Z]
L3 RCILA0053AWZZ J AK AM Bar Antenna [X]
L4 RCILB0047AWZZ J SW1 Oscillation [Z]
L4 RCILB0051AWZZ J AE AM Oscillation [X]
L5 RCILB0053AWZZ J AC MW Oscillation [Z Only]
L6 RCILA0556AFZZ J AD SW2 Antenna [Z Only]
L7 RCILB0048AWZZ J SW2 Oscillation [Z Only]
L351 VP-MK331K0000 J AB 330 µH,Choke
L391 VP-YF470K0000 J AB 47 µH,Choke
L450 VP-DH100K0000 J AB 10 µH,Choke
L500 VP-DH100K0000 J AB 10 µH,Choke
L501 VP-DH100K0000 J AB 10 µH,Choke [Z Only]
L701,702 VP-XH1R5K0000 J AB 1.5 µH,Choke
L801 VP-XHR82K0000 J AC 0.82 µH,Choke
VARIABLE RESISTORS
VR1 92LVRS682NBUT J AC 6.8 kohms (B),Semi-VR [VCO]
VR391 92LVRS472NBUT J AD 4.7 kohms (B),Semi-VR
[Tape Speed]
VR500 RVR-B0011AWZZ J 5 kohms (B),Semi-VR
[Fine Tuning] [Z Only]
VR901 92LVRS1788B J AE 100 kohm (B),Semi-VR[X-BASS]
VR902~904 92LVRS1788A J AE 100 kohm (B),Semi-VR
[Graphic Equalizer]
VARIABLE CAPACITORS
TC5~8 92LTO-1527AT J AF Trimmer,20 pF [Z Only]
VC1-4 92LVC-1455A J AN Variable Capacitor with
Trimmers (TC1~4) [X]
VC1-4 92LVC-197A J AS Variable Capacitor with
Trimmers (TC1~4) [Z]
VIBRATORS
X701 RCRM-0009AWZZ J AF Ceramic,4.000 MHz
XL801 RCRM-0008AWZZ J AF Ceramic,16.93 MHz
CAPACITORS
C2 VCKYMN1HB102K J AA 0.001 µF,50V
C4 VCCCPA1HH180J J AA 18 pF (CH),50V [Z]
C4 VCCCPA1HH220J J AA 22 pF (CH),50V [X]
C5 VCCCPA1HH330J J AA 33 pF (CH),50V
C6 VCCRPA1HH150J J AA 15 pF (RH),50V
C8 VCCCPA1HH3R0C J AA 3 pF (CH),50V [Z]
C8 VCCCPA1HH4R0C J AA 4 pF (CH),50V [X]
C9 VCTYPA1EX472M J AA 0.0047 µF,25V
C10 VCTYPA1EX223M J AA 0.022 µF,25V
C11 VCKYPA1HB221K J AA 220 pF,50V
C14 VCTYMN1EF223Z J AA 0.022 µF,25V
C15 VCTYPA1EX223M J AA 0.022 µF,25V
C16 VCTYPA1EX472M J AA 0.0047 µF,25V
C17 VCTYMN1EF223Z J AA 0.022 µF,25V
INTEGRATED CIRCUITS
IC1 VHILA1186N/-1 J AE FM Front End,LA1186N
IC2 VHILA1805//-1 J AM FM/AM IF MPX.,LA1805
IC201 VHIAN7345K/-1 J AM Playback and Record/ Playback
Amp.,AN7345K
IC500 VHITC9211P/-1 J AS Electronic Volume,TC9211P
IC601 VHILA4597//-1 J AH Power Amp.,LA4597
IC761 VHIBA6218//-1 J AH Changer Motor Control,BA6218
IC801 VHILA9240M/-1 J AV Servo Amp.,LA9240M
IC802 VHILC78622E-1 J BA Servo/Signal Control,LC78622E
IC804 VHIBA5920FP-1 J AR Focus/Tracking/Spin/Slide
Driver,BA5920FP
IC901 RH-IX0146AWZZ J AV System,Microcomputer,
IX0146AW
TRANSISTORS
Q201,202 VSKTC3199GR-1 J AB Digital,NPN,KTC3199 GR
Q252 VSKRC102M//-1 J AC Digital,NPN,KRC102 M
Q253 VSKRA102M//-1 J AC Digital,PNP,KRA102 M
Q351 VS2SC2001-K-1 J AD Silicon,NPN,2SC2001 K
Q352,353 VSKTC3199GR-1 J AB Digital,NPN,KTC3199 GR
[Z Only]
Q362,363 VSKTC3199GR-1 J AB Digital,NPN,KTC3199 GR
[Z Only]
Q391 VSKTC3199GR-1 J AB Digital,NPN,KTC3199 GR
Q392 VS2SB562C//-1 J AC Silicon,PNP,2SB562 C
Q393 VSKRC102M//-1 J AC Digital,NPN,KRC102 M
Q394 VSKTC3199GR-1 J AB Digital,NPN,KTC3199 GR
Q521,522 VSKTC3199GR-1 J AB Digital,NPN,KTC3199 GR
Q623 VSKRA102M//-1 J AC Digital,PNP,KRA102 M
Q651 VS2SD468-C/-1 J AD Silicon,NPN,2SD468 C
Q652 VS2SD2394F/-1 J AE Silicon,NPN,2SD2394 F
Q653 VS2SB561-C/-1 J AC Silicon,PNP,2SB561 C
Q654 VS2SD468-C/-1 J AD Silicon,NPN,2SD468 C
Q655,656 VSKRC102M//-1 J AC Digital,NPN,KRC102 M
Q657 VSKRA102M//-1 J AC Digital,PNP,KRA102 M
Q658 VSKTC3199GR-1 J AB Digital,NPN,KTC3199 GR
Q659 VSKRC102M//-1 J AC Digital,NPN,KRC102 M
Q660 VS2SB561-C/-1 J AC Silicon,PNP,2SB561 C
Q661 VSKRC102M//-1 J AC Digital,NPN,KRC102 M [Z Only]
Q662 VSKRC102M//-1 J AC Digital,NPN,KRC102 M
Q701,702 VSKRC102M//-1 J AC Digital,NPN,KRC102 M
Q703 VSKRA102M//-1 J AC Digital,PNP,KRA102 M
Q704 VSKRC102M//-1 J AC Digital,NPN,KRC102 M
Q705 VSKTC3199GR-1 J AB Digital,NPN,KTC3199 GR
Q711,712 VSKRC102M//-1 J AC Digital,NPN,KRC102 M
Q713 VSKRA102M//-1 J AC Digital,PNP,KRA102 M
Q714 VSKTC3199GR-1 J AB Digital,NPN,KTC3199 GR
Q715 VSKTC3199GR-1 J AB Digital,NPN,KTC3199 GR
Q804 VS2SD468-C/-1 J AD Silicon,NPN,2SD468 C
Q805 VSKTA1266GR-1 J AB Silicon,PNP,KTA1266 GR
Q901,902 VSKTC3199GR-1 J AB Digital,NPN,KTC3199 GR
DIODES
D1 VHD1SS133//-1 J AA Silicon,1SS133 [Z Only]
D202,203 VHD1SS133//-1 J AA Silicon,1SS133
D250,251 VHD1SS133//-1 J AA Silicon,1SS133
D252 VHD1SS133//-1 J AA Silicon,1SS133 [Z Only]
D253 VHD1SS133//-1 J AA Silicon,1SS133
D261,262 VHD1SS133//-1 J AA Silicon,1SS133
D264 VHD1SS133//-1 J AA Silicon,1SS133
D392 VHD1SS133//-1 J AA Silicon,1SS133
D601~606 VHD1SS133//-1 J AA Silicon,1SS133
D631~633 VHD1SS133//-1 J AA Silicon,1SS133
D651~654 VHDRL204F//-1 J AC Silicon,RL204F
D655,656 VHD1SS133//-1 J AA Silicon,1SS133
D701~704 VHD1SS133//-1 J AA Silicon,1SS133
D711 VHD1SS133//-1 J AA Silicon,1SS133
D713 VHD1SS133//-1 J AA Silicon,1SS133
D802 VHD1SS133//-1 J AA Silicon,1SS133
D803 VHDRL104A//-1 J AB Silicon,RL104A [Z Only]
LED500 92LLED3N4PDN32 J AC LED,Red,3N4PDN32 [Z Only]
LED701 VHP3N8PGN33-1 J AE LED,Red/Green,3N8PGN33
LED703 92LLED3N4GDN32 J AD LED,Green,3N4GDN32
LED704 92LLED3N4PDN32 J AC LED,Red,3N4PDN32
ZD651 VHEHZ9A1///-1 J AB Zener,9V,HZ9A1
ZD653,654 VHEMTZJ5R6C-1 J AB Zener,5.6V,MTZJ5.6C
ZD801 VHEMTZJ5R6B-1 J AD Zener,5.6V,MTZJ5.6B
!
!
