Sharp HT-SB200 Service Manual

HT-SB200
3 – 2
CAUTION:
TO REMOVE SPEAKER UNIT, PRESS THESE LOCKING TABS
TO RELEASE SPEAKER WIRES.
SPEAKER UNIT
LOCKING TAB
LOCKING TAB
SPEAKER
WIRE
Front Cabinet Ass’y
Front Cabinet Ass’y
(F1)x4
M2.6x8mm
(F1)x4
M2.6x8mm
(E4)x2
M3x10mm
(E4)x2
M3x10mm
(E4)x2
M3x10mm
(E4)x2
M3x10mm
Woofer
Woofer
Woofer
Woofer
Speaker
Speaker
(E2)x1
Duct Port Ass’y
(E2)x1
Duct Port Ass’y
(E3)x6
M3x10mm
(E3)x6
M3x10mm
(E1)x1
Duct Port Holder
(E1)x1
Duct Port Holder
Figure 2
Figure 3
Figure 4
Amplifier PWB
Power PWB
(B1)x2
Special Screw
(C3)x1
Special Screw
Front Cabinet Ass’y
(C2)x4
M3x10mm
(C1)x1
Main Chassis
(C5)x2
M3x8mm
(D1)x1
M3x8mm
(B2)x1
(B3)x1
(C4)x1
(B3)x1
Main PWB
