Sharp HT-SBW110 User Manual

EN
Accessories
• 1x Remote control • 2x Wall Bracket
• 1x User manual • 1x Set of wall-mounting screws
• 1x power cord • 2 x AAA battery
Controls
1
3
2
1
1. Remote Control Sensor
2. LED Indicators
•
Red indicator: In STANDBY mode.
•
Green indicator: In AUX mode.
•
Orange indicator: In Optical mode.
•
Blue indicator: In Bluetooth mode.
••
White indicator: In HDMI ARC mode.
3. Wall bracket screws
4.
button
Switch the unit between ON and STANDBY mode.
5.
button
Select the play function.
6.
button
Select the Bluetooth mode. Press and hold to activate the pairing
function in Bluetooth mode or disconnect the existing paired
Bluetooth device.
7. +/- buttons
Increase/decrease the volume level.
Inputs/Outputs
1. AC~ Socket
Connect power cord.
2. SUBWOOFER OUT Socket
3. OPTICAL Socket
Opticial input jack.
4. SERVICE ONLY Socket
The USB socket is for service only. It is not designed to charge smart-
phones, tablets or similar devices.
5. AUX 1 Socket
Connect to an external audio device.
6. HMDI ARC Socket
Connect to a TV via HDMI cable.
4 5 6 7
1 32 4 5 61
EN

Sharp HT-SBW110 Specifications

General

RMS rated power	180 W
Audio output channels	2.1 channels
Audio Return Channel (ARC)	Yes
Receiver included	-
Bluetooth version	4.2
Connectivity technology	Wired & Wireless
Frequency range	60 - 20000 Hz
Certification	CE (EMC), CB (Safety), ErP (Energy)
Product color	Black
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Power consumption (standby)	0.5 W

Weight and Dimensions

Depth	60 mm
Width	800 mm
Soundbar weight	1300 g
Subwoofer depth	320 mm
Subwoofer width	150 mm
Subwoofer height	220 mm
Subwoofer weight	2700 g
