E-3
Controls and indicators
4 5 6 7 8
1 2 3 4 5
1. LED Indicators
RED
In Standby mode
MAGENTA
In USB mode
BLUE
In Bluetooth mode or Dolby
Digital signal
WHITE
In HDMI mode
GREEN
In Audio In mode or PCM signal
ORANGE
In Optical mode
2. Wall bracket holes
3. Remote Control Sensor
4. Duct ports
5. button
Switch the sound bar between ON and
STANDBY mode.
6. button
Select the input function.
7. button
Press to activate the pairing function in
Bluetooth mode or disconnect the existing
paired Bluetooth device.
8. button
Play or pause in Bluetooth and USB modes.
9. buttons
Decrease or increase the volume level.
1
44
2
3
HDMI (ARC)
USB
AUDIO
IN
OPTICAL
IN
5678 9
 Front panel
