Sharp HT-SBW460 User Manual

EN
What’s in the Box
• Main Unit
• Remote Control
• Wireless Subwoofer
• EU AC Power Cord (2 pcs)
• UK AC Power Cord (2 pcs)
• Audio Cable 3.5mm to 3.5mm
• HDMI Cable
• Wall Brackets (2pcs)
• Wall mounting Screws
• User manual
• Quick Start Guide
• Warranty lea et
Design and speci cations are subject to change without notice.
Panels & Controls
aux
2 1
3
4 6 75
8 9
1110 12
13
Main Unit
1. Display Window – Show the current status.
2. Remote Control Sensor – Receive signal from the remote control.
3. Wall bracket screws
4.
(ON/OFF) button – Switch the unit between ON and Standby mode.
5.
(SOURCE) button – Select the play function.
6.
– Play/pause/resume playback in Bluetooth/USB mode.
Press and hold to activate the pairing function in Bluetooth mode or
disconnect the existing paired Bluetooth device.
7. VOL+/VOL- buttons – Increase/decrease the volume level.
8. AC~ Socket
9. COAXIAL Socket
10. OPTICAL Socket
11. USB Socket – Insert the USB device to play music.
12. AUX Socket – Connect to an external audio device.
13. HDMI (1/2/ARC) Sockets – Connect to a TV via HDMI cable.
Wireless Subwoofer
1. AC~ Socket – Connect to power.
2. PAIR button – Press activate the pairing function between the main
unit and the subwoofer.
3. PAIR Indicator – Light up solidly when the pairing succeed.
Remote Control
1. – Switch the unit between ON and STANDBY mode.
2.
– Select the Bluetooth mode.
Press and hold to activate the pairing function in Bluetooth mode or
disconnect the existing paired Bluetooth device.
3.
– Select the play function.
4. SURR – Turn the surround ON/OFF.
5. HDMI – Select the HDMI 1/2/ARC mode.
6. VOL +/- – Increase/decrease the volume level.
7.
/ – Skip to previous/next track in Bluetooth/USB mode.
8.
– Play/pause/resume playback in Bluetooth/USB mode.
9.
– (MUTE) Mute or resume the sound.
10. BASS +/- – Adjust bass level.
11. TRE +/- – Adjust treble level.
12. EQ – Select a preset sound mode.

Sharp HT-SBW460 Specifications

General

Audio decoders	Dolby Atmos, Dolby Digital, Dolby Digital Plus, Dolby TrueHD
RMS rated power	440 W
Audio output channels	3.1 channels
Audio Return Channel (ARC)	Yes
Wi-Fi	No
Bluetooth version	4.2
HDMI ports quantity	3
Connectivity technology	Wired & Wireless
Digital audio coaxial in	1
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Soundbar power consumption	25 W
Power consumption (standby)	0.5 W
Subwoofer power consumption	20 W
Soundbar speaker RMS power	100 W
Subwoofer connectivity	Wireless
Subwoofer frequency range	50 - 130 Hz
Display type	LED
Product color	Metallic
Package type	Box
Package depth	273 mm
Package width	1023 mm
Package height	395 mm
Package weight	10300 g
Cables included	AC, AUX, HDMI
Soundbar frequency range	120 - 20000 Hz
Remote control battery type	AAA
Number of remote control batteries	2
Master (outer) case width	1040 mm
Master (outer) case height	535 mm
Master (outer) case length	285 mm
Master (outer) case weight	22800 g
Quantity per master (outer) case	2 pc(s)
Master (outer) case GTIN (EAN/UPC)	8586018085502

Weight and Dimensions

Depth	105 mm
Width	950 mm
Height	70 mm
Soundbar weight	2500 g
Subwoofer width	240 mm
Subwoofer height	415 mm
Subwoofer weight	5400 g
