E-17
ENGLISH
SYMPTOM REMEDY (not a malfunction)
When the Roller / Float was removed.
• Install the Roller / Float in order below.
AUTO RESTART
After a power failure, automatically resume
the operation when the power recovers.
Auto Restart can be set.
• Even when the plug is unplugged or the breaker
is thrown during the operation, the operation re-
sumes at the previous operation mode and set-
tings if the power recovers.
FLOAT
ROLLER
1. Insert the float under
this tab.
2. Inner the tab
of float into
the hole.
3. Insert the tab on the other
side of the float into the
hole.
Fix the roller in the tray from side way.
NOTE
Check the direction
of the roller.
Float
Tab
Float
Cross-Section view
(with the unit OFF)
ON
(with the unit OFF)
CANCELLATION
(simultaneously for more 3 sec.)
If the , , lamp lights up for
10 seconds, the setting is com-
plete.
(simultaneously for more 3 sec.)
OM_KC-A60Y_A50Y_A40Y(EN-ID)indb.indb Sec1:17 5/18/11 4:18:21 PM
