Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
66
LC-13SH1E
LC-15SH1E
DUNTKC859WE06 (LC-13SH1E)
DUNTKC859WE05 (LC-15SH1E)
R/C, LED UNIT
TRANSISTORS
Q4001 VSKRC104S//-1Y J KRC104S AA
Q4002 VSKRC104S//-1Y J KRC104S AA
Q4004 VSKRC104S//-1Y J KRC104S AA
Q4005 VSKRC104S//-1Y J KRC104S AA
DIODES
D4001 RH-PXA014WJZZ+ J STANDBY/On Indicator AD
D4002 RH-PXA014WJZZ+ J OPC Indicator AD
D4004 RH-EX0640GEZZY J Zener Diode AA
D4005 RH-EX0640GEZZY J Zener Diode AA
D4007 RH-EX0640GEZZY J Zener Diode AA
D4008 RH-PXA088WJZZ J OPC Sensor AG
CAPACITORS
C4001 VCEAEA1CW106M+ J 10 16V Electrolytic AB
C4002 VCEAEA1CW106M+ J 10 16V Electrolytic AB
C4003 VCEAEA0JW107M+ J 100 6.3V Electrolytic AB
C4004 VCKYCY1HF103ZY J 0.01 50V Ceramic AA
RESISTORS
R4001 VRS-CY1JF331JY J 330 1/16W Metal Oxide AA
R4002 VRS-CY1JF681JY J 680 1/16W Metal Oxide AA
R4003 VRS-CY1JF472JY J 4.7k 1/16W Metal Oxide AA
R4006 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R4007 VRS-CY1JF331JY J 330 1/16W Metal Oxide AA
R4010 VRS-CY1JF333JY J 33k 1/16W Metal Oxide AA
MISCELLANEOUS PARTS
SC4001 QSOCN0896REZZ J Socket, 8-pin AC
RMC4001 RRMCUA034WJQZ J R/C Receiver AE
LHLDZA486WJZZ S LED Holder AD
TUNER
NOTE: THE PARTS HERE SHOWN ARE SUPPLIED AS AN
ASSEMBLY BUT NOT INDEPENDENTLY.
TU201 VTUVT1Y5ED501 S Tuner AS
INTEGRATED CIRCUITS
IC101 VHiM24C64WN-1Y J M24C64-WMN6T AL
IC151 VHi39VF01WH-1Q J I.C. AN
IC501 RH-iXB219WJZZQ J I.C. BK
IC701 VHiLM1117MJ-1Y J LM1117MPX-ADJ AF
IC702 VHiMM1563DF-1Y J MM1563DFBE AE
IC703 VHiLM1117MJ-1Y J LM1117MPX-ADJ AF
IC704 VHiBA05FP++-1Y J BA05FP-E2 AF
IC751 VHiNJ79M08D-1Y J NJM79M08DL1A AF
IC801 RH-iX3251CEZZY J TDA9178T/N1 AY
IC1101 VHiBD8120FP-1Y J BD8120FP AX
IC1201 RH-iXA370WJZZQ J LR38819 AY
IC2201 VHiTLVDF84B-1Y J THC63LVDF84B AT
TRANSISTORS
Q101 VSFMMT718//-1Y J FMMT718 AE
Q102 VS2SC3928AR-1Y J 2SC3928AR AB
Q103 VSFMMT718//-1Y J FMMT718 AE
Q104 VS2SC3928AR-1Y J 2SC3928AR AB
Q105 VSUM5K1NTR+-1Y J UM5K1NTR AC
Q201 VS2SC3928AR-1Y J 2SC3928AR AB
Q202 VS2SC3928AR-1Y J 2SC3928AR AB
Q205 VS2SC3928AR-1Y J 2SC3928AR AB
Q701 VSDTA144EE/-1Y J DTA144EE AA
Q702 VSDTA124EE/-1Y J DTA124EE AB
Q751 VS2SC3928AR-1Y J 2SC3928AR AB
Q752 VS2SA1530AR-1Y J 2SA1530A AB
Q753 VSDTC144EE/-1Y J DTC144EE AA
Q754 VSFMMT718//-1Y J FMMT718 AE
Q755 VSDTC144EE/-1Y J DTC144EE AA
Q756 VSDTC144EE/-1Y J DTC144EE AA
Q757 VSDTC144EE/-1Y J DTC144EE AA
Q758 VS2SC3928AR-1Y J 2SC3928AR AB
Q759 VSDTA144EE/-1Y J DTA144EE AA
Q801 VS2SC3928AR-1Y J 2SC3928AR AB
Q802 VS2SC3928AR-1Y J 2SC3928AR AB
Q803 VS2SC3928AR-1Y J 2SC3928AR AB
Q1105 VS2SC4520//-1Y J 2SC4520 AE
Q1106 VS2SA1729//-1Y J 2SA1729 AF
DIODES
D101 VHDHSU119//-1Y J Diode AB
D202 RH-EXA101WJZZY J Zener Diode AB
D203 VHDRB481K++-1Y J Diode AD
D204 VHD1SS390++-1Y J Diode AB
D205 VHDHSU119//-1Y J Diode AB
D206 VHDHSU119//-1Y J Diode AB
D208 VHD1SS390++-1Y J Diode AB
D701 VHDHSU119//-1Y J Diode AB
D702 VHDHSU119//-1Y J Diode AB
D703 VHDHSU119//-1Y J Diode AB
D704 VHD1SS119//-1Y J Diode AA
D751 RH-EXA099WJZZY J Zener Diode AB
D755 VHDRB481K++-1Y J Diode AD
D756 VHDHSU119//-1Y J Diode AB
D757 VHDHSU119//-1Y J Diode AB
D759 VHD1SS250//1EY J Diode AB
D1103 VHD1SS250//1EY J Diode AB
D1104 VHD1SS250//1EY J Diode AB
PACKAGED CIRCUITS
X101 RCRSAA058WJZZ J Crystal AD
X501 RCRSAA037WJZZ J Crystal AE
FILTERS AND COILS
SF201 RFiLCA102WJZZ S S.A.W Filter AH
DUNTKC860FM05 (LC-13SH1E)
DUNTKC860FM04 (LC-15SH1E)
MAIN UNIT
