Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
67
LC-13SH1E
LC-15SH1E
DUNTKC860FM05 (LC-13SH1E)
DUNTKC860FM04 (LC-15SH1E)
MAIN UNIT
SF202 RFiLCA103WJZZ S S.A.W Filter AM
L202 RCiLPA143WJZZY J Coil AD
L751 RCiLPA143WJZZY J Coil AD
L752 VPCNN470J5R4NY J Peaking 47µH AB
L2201 VPCNN2R7JR85NY J Peaking 2.7µH AB
L2202 VPCNN2R7JR85NY J Peaking 2.7µH AB
CAPACITORS
C101 VCKYCY1CF224ZY J 0.22 16V Ceramic AB
C102 VCKYCY1CF224ZY J 0.22 16V Ceramic AB
C104 VCKYCY1CF224ZY J 0.22 16V Ceramic AB
C106 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C107 VCKYCY1CF224ZY J 0.22 16V Ceramic AB
C109 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C110 VCKYCY1CF224ZY J 0.22 16V Ceramic AB
C111 VCEASX0JN227MY J 220 6.3V Electrolytic AC
C113 VCKYCY1CF224ZY J 0.22 16V Ceramic AB
C116 VCKYCY1CF224ZY J 0.22 16V Ceramic AB
C117 VCEASX0JN107MY J 100 6.3V Electrolytic AC
C118 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C119 VCKYCY1CF224ZY J 0.22 16V Ceramic AB
C121 VCKYCY1CF224ZY J 0.22 16V Ceramic AB
C122 VCKYCY1CF224ZY J 0.22 16V Ceramic AB
C123 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C124 VCEASX0JN107MY J 100 6.3V Electrolytic AC
C126 VCEASX1CN106MY J 10 16V Electrolytic AC
C127 VCKYCY1CB223KY J 0.022 16V Ceramic AB
C128 VCCCCY1HH101JY J 100p 50V Ceramic AA
C151 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C152 VCEASX1CN106MY J 10 16V Electrolytic AC
C161 VCCCCY1HH101JY J 100p 50V Ceramic AA
C162 VCCCCY1HH101JY J 100p 50V Ceramic AA
C163 VCCCCY1HH101JY J 100p 50V Ceramic AA
C201 VCEASX1CN106MY J 10 16V Electrolytic AC
C203 VCKYCY1HF333ZY J 0.033 50V Ceramic AA
C204 VCEASX1CN476MY J 47 16V Electrolytic AC
C205 VCEASX1CN476MY J 47 16V Electrolytic AC
C206 VCEASX0JN227MY J 220 6.3V Electrolytic AC
C207 VCEASX1HN225MY J 2.2 50V Electrolytic AB
C208 VCKYCY1HB103KY J 0.01 50V Ceramic AA
C213 VCKYCY1HB103KY J 0.01 50V Ceramic AA
C215 VCEASX1CN106MY J 10 16V Electrolytic AC
C216 VCEASX1HN225MY J 2.2 50V Electrolytic AB
C217 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C218 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C220 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C301 VCEASX1HN475MY J 4.7 50V Electrolytic AC
C302 VCKYCY1HB392KY J 3900p 50V Ceramic AA
C303 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C304 VCEASX1HN225MY J 2.2 50V Electrolytic AB
C305 VCCCCY1HH101JY J 100p 50V Ceramic AA
C306 VCCCCY1HH101JY J 100p 50V Ceramic AA
C331 VCCCCY1HH101JY J 100p 50V Ceramic AA
C332 VCCCCY1HH101JY J 100p 50V Ceramic AA
C358 VCCCCY1HH101JY J 100p 50V Ceramic AA
C359 VCCCCY1HH101JY J 100p 50V Ceramic AA
C360 VCCCCY1HH101JY J 100p 50V Ceramic AA
C361 VCCCCY1HH101JY J 100p 50V Ceramic AA
C362 VCKYTV1EB474KY J 0.47 25V Ceramic AC
C363 VCKYTV1EB474KY J 0.47 25V Ceramic AC
C366 VCCCCY1HH101JY J 100p 50V Ceramic AA
C367 VCCCCY1HH101JY J 100p 50V Ceramic AA
C368 VCKYTV1EB474KY J 0.47 25V Ceramic AC
C369 VCKYTV1EB474KY J 0.47 25V Ceramic AC
C409 VCCCCY1HH101JY J 100p 50V Ceramic AA
C410 VCCCCY1HH101JY J 100p 50V Ceramic AA
C411 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C412 VCCCCY1HH101JY J 100p 50V Ceramic AA
C413 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C414 VCKYCY1HB103KY J 0.01 50V Ceramic AA
C415 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C416 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C417 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C418 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C419 VCCCCY1HH101JY J 100p 50V Ceramic AA
C420 VCEASX1CN106MY J 10 16V Electrolytic AC
C421 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C501 VCEASX0JN226MY J 22 6.3V Electrolytic AB
C504 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C505 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C506 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C507 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C510 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C511 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C512 VCEASX0JN226MY J 22 6.3V Electrolytic AB
C513 VCEASX1CN106MY J 10 16V Electrolytic AC
C514 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C515 VCKYCY1HB102KY J 1000p 50V Ceramic AA
C517 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C518 VCKYCY1HB102KY J 1000p 50V Ceramic AA
C519 VCCCCY1HH8R0DY J 8p 50V Ceramic AA
C520 VCCCCY1HH8R0DY J 8p 50V Ceramic AA
C521 VCEASX0JN226MY J 22 6.3V Electrolytic AB
C522 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C523 VCEASX0JN226MY J 22 6.3V Electrolytic AB
C524 VCEASX0JN226MY J 22 6.3V Electrolytic AB
C525 VCEASX0JN226MY J 22 6.3V Electrolytic AB
C535 VCKYCY1CF224ZY J 0.22 16V Ceramic AB
C536 VCKYCY1CF224ZY J 0.22 16V Ceramic AB
C547 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C548 VCKYCY1CF224ZY J 0.22 16V Ceramic AB
C549 VCEASX0JN107MY J 100 6.3V Electrolytic AC
C550 VCKYCY1CF224ZY J 0.22 16V Ceramic AB
C551 VCEASX0JN107MY J 100 6.3V Electrolytic AC
C552 VCKYCY1CF224ZY J 0.22 16V Ceramic AB
C554 VCKYCY1CF224ZY J 0.22 16V Ceramic AB
C556 VCEASX0JN107MY J 100 6.3V Electrolytic AC
C557 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C558 VCKYCY1CF224ZY J 0.22 16V Ceramic AB
C570 VCKYCY1CB333KY J 0.033 16V Ceramic AA
C571 VCCCCY1HH100DY J 10p 50V Ceramic AA
C574 VCKYCY1CB333KY J 0.033 16V Ceramic AA
C575 VCKYCY1CB333KY J 0.033 16V Ceramic AA
C576 VCCCCY1HH100DY J 10p 50V Ceramic AA
C578 VCKYCY1CB333KY J 0.033 16V Ceramic AA
C579 VCKYCY1CB223KY J 0.022 16V Ceramic AB
C580 VCKYCY1CB333KY J 0.033 16V Ceramic AA
C581 VCCCCY1HH100DY J 10p 50V Ceramic AA
C582 VCKYCY1CB333KY J 0.033 16V Ceramic AA
C701 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C702 VCEASX1CN476MY J 47 16V Electrolytic AC
C703 VCEASX0JN107MY J 100 6.3V Electrolytic AC
C704 VCEASX1CN476MY J 47 16V Electrolytic AC
C709 VCEASX1CN106MY J 10 16V Electrolytic AC
C710 VCEASX1CN476MY J 47 16V Electrolytic AC
C711 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C712 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C720 VCEASX1CN106MY J 10 16V Electrolytic AC
C721 VCKYCY1HB471KY J 470p 50V Ceramic AA
C722 VCEASX1CN476MY J 47 16V Electrolytic AC
C723 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C724 VCEASX1CN106MY J 10 16V Electrolytic AC
C725 VCKYCY1CF224ZY J 0.22 16V Ceramic AB
C751 VCEASX1HN225MY J 2.2 50V Electrolytic AB
C752 VCEASX1CN106MY J 10 16V Electrolytic AC
C753 VCEASX1CN107MY J 100 16V Electrolytic AC
C754 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C758 RC-KZ0075TAZZY J 2.2 16V Ceramic AC
C759 VCEASX1HN225MY J 2.2 50V Electrolytic AB
C760 VCEASX1CN107MY J 100 16V Electrolytic AC
C761 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C763 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C764 VCEASX1HN475MY J 4.7 50V Electrolytic AC
C765 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C766 VCAAPC0JJ107MY J 100 6.3V Electrolytic AE
C801 VCEASX1HN105MY J 1 50V Electrolytic AB
