Sharp LC-13SH1E Service Manual

Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
68
LC-13SH1E
LC-15SH1E
DUNTKC860FM05 (LC-13SH1E)
DUNTKC860FM04 (LC-15SH1E)
MAIN UNIT (Continued)
C802 VCKYCY1HB682KY J 6800p 50V Ceramic AA
C803 VCKYCY1CF224ZY J 0.22 16V Ceramic AB
C804 VCEASX1CN106MY J 10 16V Electrolytic AC
C805 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C806 VCKYCY1CF334ZY J 0.33 16V Ceramic AB
C807 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C808 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C809 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C810 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C811 VCCCCY1HH220JY J 22p 50V Ceramic AA
C812 VCCCCY1HH220JY J 22p 50V Ceramic AA
C813 VCCCCY1HH220JY J 22p 50V Ceramic AA
C814 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C815 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C816 VCEASX1CN106MY J 10 16V Electrolytic AC
C817 RC-KZ0074TAZZY J 10 6.3V Ceramic AF
C818 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C819 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C820 VCEASX1CN476MY J 47 16V Electrolytic AC
C821 VCKYCY1HB102KY J 1000p 50V Ceramic AA
C822 VCEASX0JN107MY J 100 6.3V Electrolytic AC
C823 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C825 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C826 VCEASX1CN106MY J 10 16V Electrolytic AC
C827 RC-KZ0074TAZZY J 10 6.3V Ceramic AF
C828 RC-KZ0074TAZZY J 10 6.3V Ceramic AF
C829 RC-KZ0074TAZZY J 10 6.3V Ceramic AF
C830 VCCCCY1HH470JY J 47p 50V Ceramic AA
C831 VCCCCY1HH470JY J 47p 50V Ceramic AA
C832 VCCCCY1HH470JY J 47p 50V Ceramic AA
C833 VCKYCY1HB271KY J 270p 50V Ceramic AA
C834 VCKYCY1HB271KY J 270p 50V Ceramic AA
C835 VCKYCY1HB271KY J 270p 50V Ceramic AA
C1104 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C1106 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C1107 RC-KZA041WJZZY J 10 10V Ceramic AC
C1108 VCCCCY1HH560JY J 56p 50V Ceramic AB
C1109 RC-KZA041WJZZY J 10 10V Ceramic AC
C1110 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C1113 VCKYCY1HB103KY J 0.01 50V Ceramic AA
C1116 VCKYTV1CB105KY J 1 16V Ceramic AC
C1117 VCKYTV1CB105KY J 1 16V Ceramic AC
C1118 VCKYCY1EB104KY J 0.1 25V Ceramic AB
C1119 RC-KZA041WJZZY J 10 10V Ceramic AC
C1120 VCEASY1HN106MY J 10 50V Electrolytic AC
C1202 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C1203 RC-KZ0117TAZZY J 4.7 6.3V Ceramic AD
C1210 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C1213 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C1214 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C1215 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C1216 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C2201 VCEASX1CN106MY J 10 16V Electrolytic AC
C2202 VCKYCY1HB103KY J 0.01 50V Ceramic AA
C2203 VCEASX1CN106MY J 10 16V Electrolytic AC
C2204 VCKYCY1HB103KY J 0.01 50V Ceramic AA
C2205 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C2206 VCCCCY1HH470JY J 47p 50V Ceramic AA
RESISTORS
R101 VRS-CY1JF332JY J 3.3k 1/16W Metal Oxide AA
R102 VRS-CY1JF332JY J 3.3k 1/16W Metal Oxide AA
R103 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R104 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R105 VRS-CY1JF153JY J 15k 1/16W Metal Oxide AA
R106 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R107 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R108 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R109 VRS-CY1JF222JY J 2.2k 1/16W Metal Oxide AA
R111 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R113 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R114 VRS-CY1JF2R2JY J 2.2 1/16W Metal Oxide AA
R115 VRS-CY1JF2R2JY J 2.2 1/16W Metal Oxide AA
R116 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R117 VRS-CY1JF2R2JY J 2.2 1/16W Metal Oxide AA
R118 VRS-CY1JF2R2JY J 2.2 1/16W Metal Oxide AA
R119 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R120 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R122 VRS-CY1JF153JY J 15k 1/16W Metal Oxide AA
R123 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R124 VRS-CY1JF154JY J 150k 1/16W Metal Oxide AA
R125 VRS-CY1JF332JY J 3.3k 1/16W Metal Oxide AA
R126 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R127 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
R129 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R131 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R132 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R133 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R134 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R136 VRS-CY1JF472JY J 4.7k 1/16W Metal Oxide AA
R137 VRS-CY1JF472JY J 4.7k 1/16W Metal Oxide AA
R138 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R139 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R140 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R141 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R142 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R143 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R144 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R145 VRS-CY1JF332JY J 3.3k 1/16W Metal Oxide AA
R146 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R147 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R148 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R149 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R151 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R152 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R161 VRS-CY1JF332JY J 3.3k 1/16W Metal Oxide AA
R164 VRS-CY1JF332JY J 3.3k 1/16W Metal Oxide AA
R201 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R202 VRS-CY1JF122JY J 1.2k 1/16W Metal Oxide AA
R203 VRS-CY1JF122JY J 1.2k 1/16W Metal Oxide AA
R204 VRS-CY1JF122JY J 1.2k 1/16W Metal Oxide AA
R205 VRS-CY1JF122JY J 1.2k 1/16W Metal Oxide AA
R206 VRS-CY1JF473JY J 47k 1/16W Metal Oxide AA
R207 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
R208 VRS-CY1JF392JY J 3.9k 1/16W Metal Oxide AA
R209 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R210 VRS-CY1JF153JY J 15k 1/16W Metal Oxide AA
R211 VRS-CY1JF332JY J 3.3k 1/16W Metal Oxide AA
R212 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
R217 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R218 VRS-CY1JF681JY J 680 1/16W Metal Oxide AA
R219 VRS-CJ1JF102JY J 1k 1/16W Metal Oxide AA
R220 VRS-CY1JF122JY J 1.2k 1/16W Metal Oxide AA
R221 VRS-CY1JF122JY J 1.2k 1/16W Metal Oxide AA
R224 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
R237 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
R239 VRS-CY1JF222JY J 2.2k 1/16W Metal Oxide AA
R301 VRS-CY1JF391JY J 390 1/16W Metal Oxide AA
R302 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R303 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R304 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R305 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R306 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R362 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R363 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R364 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R365 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R366 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R367 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R368 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R369 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R370 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R371 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R423 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R544 VRS-CY1JF823JY J 82k 1/16W Metal Oxide AA
R548 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
