Sharp LC-13SH1E Service Manual

Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
69
LC-13SH1E
LC-15SH1E
DUNTKC860FM05 (LC-13SH1E)
DUNTKC860FM04 (LC-15SH1E)
MAIN UNIT (Continued)
R549 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
R550 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
R551 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
R552 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
R553 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
R554 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
R557 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
R558 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
R559 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
R570 VRS-CY1JF100JY J 10 1/16W Metal Oxide AA
R571 VRS-CY1JF470JY J 47 1/16W Metal Oxide AA
R573 VRS-CY1JF100JY J 10 1/16W Metal Oxide AA
R574 VRS-CY1JF470JY J 47 1/16W Metal Oxide AA
R575 VRS-CY1JF100JY J 10 1/16W Metal Oxide AA
R576 VRS-CY1JF470JY J 47 1/16W Metal Oxide AA
R577 VRS-CY1JF123JY J 12k 1/16W Metal Oxide AA
R701 VRS-CY1JF121JY J 120 1/16W Metal Oxide AA
R702 VRS-CY1JF271JY J 270 1/16W Metal Oxide AA
R704 VRS-CY1JF472JY J 4.7k 1/16W Metal Oxide AA
R705 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
R709 VRS-TW2HF000JY J 0 1/2W Metal Oxide AA
R710 VRS-CY1JF271JY J 270 1/16W Metal Oxide AA
R711 VRS-CY1JF471JY J 470 1/16W Metal Oxide AA
R714 VRS-TW2HF1R0JY J 1 1/2W Metal Oxide AA
R715 VRS-TW2HF1R0JY J 1 1/2W Metal Oxide AA
R716 VRS-TW2HF101JY J 100 1/2W Metal Oxide AA
R717 VRS-TW2HF101JY J 100 1/2W Metal Oxide AA
R718 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
R721 VRS-CY1JF105JY J 1M 1/16W Metal Oxide AA
R722 VRS-TW2HF1R0JY J 1 1/2W Metal Oxide AA
R751 VRS-CY1JF472JY J 4.7k 1/16W Metal Oxide AA
R752 VRS-CY1JF272JY J 2.7k 1/16W Metal Oxide AA
R753 VRS-TW2ED102JY J 1k 1/4W Metal Oxide AA
R754 VRS-CY1JF472JY J 4.7k 1/16W Metal Oxide AA
R755 VRS-CY1JF472JY J 4.7k 1/16W Metal Oxide AA
R757 VRS-TW2ED103JY J 10k 1/4W Metal Oxide AA
R761 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R762 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R764 VRS-CY1JF223JY J 22k 1/16W Metal Oxide AA
R766 VRS-TW2HF330JY J 33 1/2W Metal Oxide AA
R767 VRS-TW2HF472JY J 4.7k 1/2W Metal Oxide AA
R769 VRS-CY1JF562JY J 5.6k 1/16W Metal Oxide AA
R801 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R802 VRS-CY1JF123JY J 12k 1/16W Metal Oxide AA
R803 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R804 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R805 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R806 VRS-CY1JF105JY J 1 M 1/16W Metal Oxide AA
R807 VRS-CY1JF393JY J 39k 1/16W Metal Oxide AA
R808 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R809 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R810 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R811 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R812 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R813 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R814 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R815 VRS-CY1JF100JY J 10 1/16W Metal Oxide AA
R816 VRS-CY1JF273JY J 27k 1/16W Metal Oxide AA
R817 VRS-CY1JF473JY J 47k 1/16W Metal Oxide AA
R819 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R820 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R821 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R822 VRS-CY1JF472JY J 4.7k 1/16W Metal Oxide AA
R823 VRS-CY1JF472JY J 4.7k 1/16W Metal Oxide AA
R824 VRS-CY1JF472JY J 4.7k 1/16W Metal Oxide AA
R825 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R826 VRS-CY1JF104JY J 100k 1/16W Metal Oxide AA
R827 VRS-CY1JF473JY J 47k 1/16W Metal Oxide AA
R828 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R829 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R830 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R831 VRS-CY1JF121JY J 120 1/16W Metal Oxide AA
R832 VRS-CY1JF121JY J 120 1/16W Metal Oxide AA
R833 VRS-CY1JF121JY J 120 1/16W Metal Oxide AA
R834 VRS-CY1JF750JY J 75 1/16W Metal Oxide AA
R835 VRS-CY1JF750JY J 75 1/16W Metal Oxide AA
R836 VRS-CY1JF750JY J 75 1/16W Metal Oxide AA
R1101 VRS-CY1JF273JY J 27k 1/16W Metal Oxide AA
R1102 VRS-CY1JF472JY J 4.7k 1/16W Metal Oxide AA
R1103 VRS-CY1JF472JY J 4.7k 1/16W Metal Oxide AA
R1104 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R1112 VRS-CY1JF181JY J 180 1/16W Metal Oxide AA
R1113 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R1114 VRS-CY1JF181JY J 180 1/16W Metal Oxide AA
R1117 VRS-TW2HF5R6JY J 5.6 1/2W Metal Oxide AA
R1118 VRS-TW2HF5R6JY J 5.6 1/2W Metal Oxide AA
R1121 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
R1122 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
R1123 VRS-TW2HF000JY J 0 1/2W Metal Oxide AA
R1124 VRS-TW2HF101JY J 100 1/2W Metal Oxide AA
R1126 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
R1128 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
R1129 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R1130 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
R1203 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R1204 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R1205 VRK-CD1JJ220JY J 22 1/16W Metal Compo. AC
R1206 VRK-CD1JJ220JY J 22 1/16W Metal Compo. AC
R1207 VRK-CD1JJ220JY J 22 1/16W Metal Compo. AC
R1208 VRS-CY1JF220JY J 22 1/16W Metal Oxide AA
R1209 VRS-CY1JF220JY J 22 1/16W Metal Oxide AA
R1210 VRS-CA1JF220JY J 22 1/16W Metal Oxide AA
R1211 VRS-CA1JF101JY J 100 1/16W Metal Oxide AA
R1214 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R1215 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R1216 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R1217 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R1218 VRS-CY1JF220JY J 22 1/16W Metal Oxide AA
R1223 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
R1230 VRS-CY1JF472JY J 4.7k 1/16W Metal Oxide AA
R1240 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R1241 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R1242 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R1243 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
R2203 VRS-CB1JF470JY J 47 1/16W Metal Oxide AA
R2204 VRS-CB1JF470JY J 47 1/16W Metal Oxide AA
R2205 VRS-CB1JF470JY J 47 1/16W Metal Oxide AA
R2206 VRS-CB1JF470JY J 47 1/16W Metal Oxide AA
R2207 VRS-CB1JF470JY J 47 1/16W Metal Oxide AA
R2208 VRS-CB1JF470JY J 47 1/16W Metal Oxide AA
R2224 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R2225 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R2226 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R2227 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R2228 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R2232 VRS-CY1JF100JY J 10 1/16W Metal Oxide AA
R2233 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
MISCELLANEOUS PARTS
FB101 RBLN-0062TAZZY J Ferrite Bead AB
FB102 RBLN-0062TAZZY J Ferrite Bead AB
FB103 RBLN-0062TAZZY J Ferrite Bead AB
FB104 RBLN-0062TAZZY J Ferrite Bead AB
FB105 RBLN-0062TAZZY J Ferrite Bead AB
FB106 RBLN-0062TAZZY J Ferrite Bead AB
FB107 RBLN-0062TAZZY J Ferrite Bead AB
FB108 RBLN-0062TAZZY J Ferrite Bead AB
FB109 RBLN-0062TAZZY J Ferrite Bead AB
FB151 RBLN-0062TAZZY J Ferrite Bead AB
FB201 RBLN-0062TAZZY J Ferrite Bead AB
FB204 RBLN-0062TAZZY J Ferrite Bead AB
FB401 RBLN-0062TAZZY J Ferrite Bead AB
FB501 RBLN-0062TAZZY J Ferrite Bead AB
FB502 RBLN-0062TAZZY J Ferrite Bead AB
FB504 RBLN-0062TAZZY J Ferrite Bead AB
FB507 RBLN-0062TAZZY J Ferrite Bead AB
