Sharp LC-19DV200E Service Manual

WAVEFORMS
SOUND AMP/AUDIO DAC JACK COMMON INTERFACE
2ms 50us 1ms
100mV 0.2V 0.5V
19 25 31
MPEG/MICON/DSP
2ms 10us 5ns
500mV 0.2V G 200mV
20 26 50
2ms 10us 20ns
500mV 0.2V 200mV
21 27 51
JACK MICON
1us 500us 5ns
0.2V 0.5V 200mV
22
SPDIF
28 54
10us 200ms 200ns
0.2V 1V 200mV
23 29 55
VIDEO/AUDIO IN/OUT
10us 200ms 10us
0.2V 1V 200mV
24 30 56
The following waveforms were measured at the point
of the corresponding balloon number in the
schematic diagram.
NOTE:
I-2
