Sharp LC-19DV200E Service Manual

DVD DECK REPLACEMENT PARTS LIST
REF. NO. PART NO. DESCRIPTION CODE
! 600 9JDA54N01A650 DVD MECHA ASS'Y A54N01A650
601 9JD92AAA0026
A
FEED RACK ASS'Y
602 9JD92P100203
A
GEAR MOTOR
603 9JD92P100201
A
GEAR FEED
604 9JD92P100202
A
GEAR MIDDLE
605 9JD92P300035
A
SPRING LEVER GUIDE
606 9JD92P200018
A
INSULATOR, R
607 9JD92P500016
A
SHAFT ROLLER
608 9JDA54N01A700 LOADER SUB ASS'Y
609 9JD92P000036
A
COVER CLAMPER
610 9JD92P000037
A
PLATE CLAMPER
611 9JD92P000039
A
PLATE RETAINER
612 9JD92P100222
A
FRAME MAIN
613 9JD92P100159
A
RETAINER SHUTTER
614 9JD92P400011
A
MAGNET CLAMPER
615 9JD92P100161
A
LEVER DISC
616 9JD92P100162
A
LEVER GUIDE
617 9JD92P100218
A
GUIDE DISC
618 9JD92P100164
A
GEAR ROLLER
619 9JD92P100165
A
CLAMPER
620 9JD92P100172
A
GEAR WORM
621 9JD92P100175
A
RACK LEVER
622 9JD92P100176
A
PLATE TRVS UD
623 9JD92P100180
A
LUMIRROR WASHER
624 9JD92P200020
A
ROLLER CONE
625 9JD92P300033
A
SPRING SHUTTER
626 9JD92P300034
A
SPRING LEVER DISC
701 9JD92P700020
A
SCREW TAP TITE
(
P
)
PAN WH5.4 1.7x8
702 9JD92P700018
A
SCREW TAP TITE
(
P
)
BIND 2.6x8
703 9JD813381750U SCREW,T-TITE
(
B
)
CAMERA PAN M1.7x5.0 P3
704 9JD814011723U SCREW,PAN M1.7x2.3 P3
705 9JD92P700021
A
SCREW TAP TITE
(
P
)
PAN WH8 2x8
706 9JD810922030U SCREW TAP TITE
(
B
)
BIND 2x3
707 9JD810922060U SCREW,TAP TITE
(
B
)
BIND 2x6
708 9JD92P700017
A
SCREW TAP TITE
(
P
)
BIND WH7 M2.6x8
CD2301 9JD12C1042202 CORD JUMPER FFC100422505030800T8-004
CD2302 9JD12C1052702 CORD JUMPER FFC100527005030800T8-004
M2601 9JD1515U98007 MOTOR JQ24-35H440
M2603 9JD1596L98004 MOTOR,LOADING WRF-300CA-10460F or
9JD1515U98009 MOTOR JQ24-35H440B
PCB610 9JDA52C01T610 LOADING MOTOR PCB ASS'Y FEH002B
PCB630 9JD13FEJ006AW PCB FEJ006
A
SW001 9JD0500101042 PUSH SWITCH ESE31R11T
SW002 9JD0500101042 PUSH SWITCH ESE31R11T
K2-1
