Sharp LC-19LE430E User Manual

LC-19LE430E/UK, LC-22LE430E/UK, LC-26LE430E/UK, LC-32LE430E/UK
127
IR SCHEMATIC DIAGRAM(for 32″)
CN001 B1
CN002 B4
C001 D4
C002 D3
C003 C2
Q002 B4
R002 A4
R003 B3
R005 C3
R006 C4
R007 B3
U001 C4
Q002
BC847C
U001
IRM-3638TF16
VOUT
1
GND
2
VCC
3
R002
0R05 1/10W
CN001
CONN 5P 1.25MM LOCK
1
2
3
4
5
6 7
R003
2.2KOHM 1/10W
R001
NC/10K 1/10W 5%
LED_B
DV33SB
LED001
50-115UMC/343996F/TR8
12
--------><------|
----><----|
----><----|
--------><----|
R006
100 OHM 1/10W
C001
1UF16V
C002
NC/100P 50V
C003
100N 50V
R005
2K7 1/10W 5%
DV33SB
DV33SB
IR_in
LED_K
