LC-19LE430E/UK, LC-22LE430E/UK, LC-26LE430E/UK, LC-32LE430E/UK
126
[4] IR SCHEMATIC DIAGRAM(for 19″, 22″ and 26″)
Q002
BC847C
U001
IRM-3638TF16
VOUT
1
GND
2
VCC
3
CN001
CONN 5P 1.25MM LOCK
1
2
3
4
5
6 7
R003
2.2KOHM 1/10W
R001
NC/10K 1/10W 5%
LED_B
DV33SB
LED001
50-115UMC/343996F/TR8
12
--------><------|
----><----|
----><----|
--------><----|
R002
0R05 1/10W
R006
100 OHM 1/10W
C001
1UF16V
C002
NC/100P 50V
C003
100N 50V
R005
2K7 1/10W 5%
DV33SB
DV33SB
IR_in
LED_K
