LC-19LE430E/UK, LC-22LE430E/UK, LC-26LE430E/UK, LC-32LE430E/UK
48
26 TROUBLESHOOTING TABLE
Power unit operation check.
LINE_FILTER_UNIT: YES
POWER_UNIT
YES
YES
YES
YES
Are the power cord and harness in the unit properly connected?
NO
Connect the power cord and harness properly, and turn on the
ower.
Is F9901/F9902 normal?
NO
LINE_FILTER_UNIT:
Isn't NR9901, L9903, L9905, FB9902, and FB9903 out of order?
Moreover, whether the short-circuit with the circumference circuit
is checked.
POWER_UNIT:
BD9901, FB9901 etc. out of order?
Moreover, whether the short-circuit with the circumference circuit
is checked.
Is (+20V) applied to pin (6) of IC9101 output? (Set the main power
SW to ON.)
Does the IC9101 circuit operate normally?
(D9105, IC9102, IC9101, Q9105 and etc. And, the circuit around
the protection circuit etc. is checked.)
NO
Is a voltage of +5.2V applied to pin (1, 3) of connector (CN9105)?
(Set the main power SW to ON.)
Does the switching circuit operate normally?
Check circuit around the primary side (T9101, IC9101, D9105,
D9102 etc.), the secondary side (D9103, L9102, C9110, etc.)
NO
Are +24V output applied to pin (5, 6) of connector (CN9105) as for
the power on/off switch when it is on?
NO
Does the switching circuit operate normally?
Check circuit around the primary side (T9101, IC9101, D9105,
D9102, etc.), the secondary side (D9101, L9101, C9107, etc.),
and the protection circuit.
Similarly, is +12V output as for the power on/off switch when it is
on?
NO
Check IC9401 circuit of D9402, L9401 etc.
To Next Page
