LC-19LE430E/UK, LC-22LE430E/UK, LC-26LE430E/UK, LC-32LE430E/UK
94
32" WIRING DIAGRAM(LC-32LE430E/UK)
095G179J30N930
MAIN BOARD
POWER BOARD
CN409
CN701
CN601
CN9002
095G8021 4X921
CN402
095G801413X976
CN9002
CN9003
