TROUBLESHOOTING GUIDE

POWER DOES NOT TUNER ON

Is F501 broken?

Is there voltage at pin

10 of IC501 at 18.9V?

Is there voltage at pin

2 of IC503 at 5V?

Change F501.

Check IC501 and peripheral

circuit.

Change MAIN PCB.

Yes

Check IC503 and peripheral

circuit. Or change IC503.

Yes

E-1

Table of Contents1
Service Manual1
Lcd Color Television1
Sharp Corporation1
Servicing Notices on Checking2
How to Order Parts2
Important2
- To Release the Hotel Mode3
- To Set the Hotel Mode3
Hotel Mode Function3
- Distinction of Pbf PCB4
- Recommendations4
- Parental Control - Rating Level4
ABOUT LEAD FREE SOLDER (Pbf)4
General Specifications5
- Removal of Mechanical Parts and P.C. Boards11
- Cover Back/Stand Ass'y11
- Back Cabinet11
Disassembly Instructions11
- Main Pcb12
- Cover Lcd/Lcd Panel12
- Removal and Installation of Flat Package IC13
Service Mode List15
Confirmation of Initial Data16
When Replacing Eeprom (Memory) IC16
Servicing Fixtures and Tools17
Install for Writing Tools17
Re-Write for Digital Soft Firmware18
Update for Vctp Software22
Update for Eeprom Data26
- Adjustment Procedure28
- Basic Adjustments28
- White Balance28
Electrical Adjustments28
- Contrast29
- Electrical Adjustment Parts Location Guide (Wiring Connection)32
- Power Does Not Tuner on33
Troubleshooting Guide33
- The Picture Does Not Apeear34
- The Color Does Not Appear37
- On Screen Display Does Not Appear38
- The Screen Has a Vertical Line or a Horizontal Line39
- Tuner/Scart1/Scart2/Rca Audio out Block Diagram40
- Power/Regulator Block Diagram41
- Scaler/Sub Micon Block Diagram42
- Hdmi/D-Sub Block Diagram43
- Sound Amp/Headphone Jack/Component Jack Block Diagram44
- Digital Block Diagram45
- Power Block Diagram46
- Main (Top Side)47
Printed Circuit Boards47
- Printed Circuit Boards Main (Bottom Side)48
- Power/Remocon/Operation (Inserted Parts)49
- Solder Side49
- Power/Remocon/Operation (Chip Mounted Parts)50
- 21Pin Schematic Diagram51
- Power Schematic Diagram52
- Regulator Schematic Diagram53
- Av Jack / Switch Schematic Diagram54
- Sound Amp Schematic Diagram55
- Tuner Schematic Diagram56
- Scaler Schematic Diagram57
- Sub Micon/Rs-232C Schematic Diagram58
- Jack Schematic Diagram59
- Panel Interface Diagram60
- Interface_Hdmi IC Schematic Diagram61
- DVD Interface Diagram62
- Asic Schematic Diagram63
- Flash / Sdram Schematic Diagram64
- Common Interface Schematic Diagram65
- Power I/O Schematic Diagram66
- Ofdm/ Tuner Schematic Diagram67
- Power2 Schematic Diagram68
- Operation/Remocon Schematic Diagram69
- Interconnection Diagram70
Waveforms71
Mechanical Exploded View73
- Mecha Replacement Parts List75
- Electric Replacement Parts List77
