ELECTRIC REPLACEMENT PARTS LIST
NR2415 9JD110P4000M5 R,NETWORK 4D02WGJ0000TCE
NR2416 9JD110P4000M5 R,NETWORK 4D02WGJ0000TCE
NR2417 9JD110P4000M5 R,NETWORK 4D02WGJ0000TCE
NR2418 9JD110P4470M5 R,NETWORK 4D02WGJ0470TCE
NR2419 9JD110P4470M5 R,NETWORK 4D02WGJ0470TCE
NR2420 9JD110P4560M5 R,NETWORK 4D02WGJ0560TCE
NR2421 9JD110P4560M5 R,NETWORK 4D02WGJ0560TCE
NR2422 9JD110P4560M5 R,NETWORK 4D02WGJ0560TCE
NR3601 9JD110P4330M5 R,NETWORK 4D02WGJ0330TCE
NR3602 9JD110P4330M5 R,NETWORK 4D02WGJ0330TCE
NR3603 9JD110P4330M5 R,NETWORK 4D02WGJ0330TCE
NR3604 9JD110P4330M5 R,NETWORK 4D02WGJ0330TCE
NR3605 9JD110P4330M5 R,NETWORK 4D02WGJ0330TCE
NR3606 9JD110P4330M5 R,NETWORK 4D02WGJ0330TCE
NR5000 9JD110P4470M5 R,NETWORK 4D02WGJ0470TCE
NR5001 9JD110P4470M5 R,NETWORK 4D02WGJ0470TCE
NR5002 9JD110P4470M5 R,NETWORK 4D02WGJ0470TCE
NR5003 9JD110P4470M5 R,NETWORK 4D02WGJ0470TCE
NR5004 9JD110P4470M5 R,NETWORK 4D02WGJ0470TCE
NR5005 9JD110P4470M5 R,NETWORK 4D02WGJ0470TCE
NR5006 9JD110P4470M5 R,NETWORK 4D02WGJ0470TCE
NR5007 9JD110P4470M5 R,NETWORK 4D02WGJ0470TCE
NR5008 9JD110P4470M5 R,NETWORK 4D02WGJ0470TCE
NR5009 9JD110P4470M5 R,NETWORK 4D02WGJ0470TCE
NR5010 9JD110P4470M5 R,NETWORK 4D02WGJ0470TCE
NR5011 9JD110P4470M5 R,NETWORK 4D02WGJ0470TCE
*** OTHERS ***
CP4302 9JD06G2S21502 CONNECTOR PCB SIDE D229FD015S107BY or
9JD06G2S21501 CONNECTOR PCB SIDE D229FD015G107BY
CP7201 9JD06G3VWT01A CONNECTOR PCB SIDE 20389-Y30E
SH4300 9JD126D000044 TERMINAL PIN YQ-36
SH4301 9JD126D000044 TERMINAL PIN YQ-36
SH4304 9JD126D000044 TERMINAL PIN YQ-36
SH4305 9JD126D000044 TERMINAL PIN YQ-36
SH4306 9JD126D000044 TERMINAL PIN YQ-36
SH4307 9JD126D000044 TERMINAL PIN YQ-36
POWER PCB ASS'Y
*** PCB ***
PCB240 9JDA32B01E240L POWER PCB ASS'Y CEF300A
*** RESISTORS ***
! R501 9JDRC31X1155J RC 1.5M OHM 1W
R509 9JDRC31X1274J RC 270K OHM 1W
! R511 9JDR63881R22J R,FUSE 0.22 OHM 1W
! R540 9JDR3K78AR33J R,METAL OXIDE 0.33 OHM 2W
*** CAPACITORS ***
C504 9JDP2122B334M CMP 0.33 UF 275V ECQUL
C505 9JDCD39E0MQ2K CC 470 PF 250V
! C507 9JDE81GHH151D CE 150 UF 400V
C508 9JDC03L0R7U2K CC 680 PF 2KV R
! C511 9JDP332E4223J CPP 0.022 UF 400V
C512 9JDCD39E0MQ2K CC 470 PF 250V
! C518 9JDE8E1G4102M CE 1000 UF 35V
! C519 9JDE8E1G4102M CE 1000 UF 35V
C521 9JDCD39E0MQ2K CC 470 PF 250V
C528 9JDE7EYS2471M CE 470 UF 16V
C538 9JDP2122B104M CMP 0.1 UF 275V ECQUL
C558 9JDP2122B104M CMP 0.1 UF 275V ECQUL
*** DIODES ***
D501 9JDD28A10A200 DIODE SILICON FCF10A20
D502 9JDD97U02701B DIODE,ZENER MTZJ27B T-77
! D503 9JDD6C047110A DIODE VARISTA ENE471D-10A
D504 9JDD2WXN40050 DIODE SILICON 1N4005-EIC
D505 9JDD4AT01H3E0 DIODE RECTIFIER 1H3-E
K2-7
