Part names
I I
Remote control sensor POWER indicator
Volume (VOL-/+)/
,4/_,-buttons
Channel /,./A button
Channel v/T button
MENU button
INPUT/ENTER button
POWER button
1
i'£
i °
TVO
Listening with headphones
Plug the headphone mini-plug into the
headphone jack located on the back of the
main unit.
Adjust the sound volume using VOL (+)/(-)
on the remote control.
¢
AC INPUT
INPUT 2terminals
INPUT 1terminals
ANT./CABLE in
COAXIAL DIGITAL AUDIO OUTPUT terminal
-- INPUT 3 terminal
-- INPUT 4 terminals
• The illustrations in this operation manual are for explanation purposes and may vary slightly from the actual operations.
(_ = 1g • The examples used throughout this manual are based on the LC-22SB27UT model.
