TROUBLESHOOTING GUIDE
Does this display
"INCORRECT DISC"?
Does CD2001 connect
with CP2301 correctly?
Yes
No
No
Yes
DOES NOT PLAY DVD
Does this display
reading mark?
No
Does disc rotate?
No
Yes
Change IC4001.
Yes
Change DVD DECK.
Connect CD2301.
Change DVD DECK.
Is the voltage between
JG017 and JG018 less
than 0.6V?
Yes
No
Change IC4001.
E-8
36
38
Table of Contents
Table of Contents
1
Caution
2
Important Safeguards
3
When Replacing DVD Deck
6
Disc Removal Method at no Power Supply
7
Parental Control - Rating Level
7
ABOUT LEAD FREE SOLDER (Pbf)
8
General Specifications
9
Disassembly Instructions
16
Removal of DVD Deck Parts
18
Service Mode List
22
Servicing Fixtures and Tools
23
Re-Write for DVD Firmware
23
Re-Write for Digital Soft Firmware
24
When Replacing Eeprom (Memory) IC
25
Electrical Adjustments
26
Troubleshooting Guide
30
DVD Block Diagram
40
Power Block Diagram
41
D-1~D
54
G-1~G
56
H-1~H
67
Waveforms
68
Mechanical Exploded Views
70
DVD Deck Exploded View
73
Mechanical Replacement Parts List
74
DVD Deck Replacement Parts List
75
